Database for ITk Pixel Module

Serial Number	20UPGFC0094519
ProdDB ID	25031a…140f7f
LocalDB ID	6231e4ec5bf2d7000a1bac77
Component Type	fe_chip
Parents	20UPGM22110449 20UPGB42200047
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000369

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	6231e4ec5bf2d7000a1bac77
Stage	MODULE/FINAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	JennyLunde
ObjectId of this record	67604a32455090268e741424
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.9
MEASUREMENT_DATE	2024-12-16T14:29:14.000+00:00
YARR_VERSION	v1.5.2-62-gf8782608
TUNING_TUNED_NOISE_95_HIGH	130.397
TUNING_TUNED_NOISE_95_LOW	88.611
TUNING_TUNED_NOISE_MEAN	108.781
TUNING_TUNED_NOISE_SIGMA	10.995
TUNING_TUNED_TDAC_MEAN	-1.072
TUNING_TUNED_TDAC_SIGMA	4.248
TUNING_TUNED_THRESHOLD_95_HIGH	1568.778
TUNING_TUNED_THRESHOLD_95_LOW	1441.152
TUNING_TUNED_THRESHOLD_FAILED_FITS	13
TUNING_TUNED_THRESHOLD_MEAN	1506.6
TUNING_TUNED_THRESHOLD_SIGMA	34
TUNING_TUNED_TOT_95_HIGH	8
TUNING_TUNED_TOT_95_LOW	8
TUNING_TUNED_TOT_MEAN	8
TUNING_TUNED_TOT_SIGMA	0
TUNING_UNTUNED_NOISE_95_HIGH	133.588
TUNING_UNTUNED_NOISE_95_LOW	90.27
TUNING_UNTUNED_NOISE_MEAN	111.147
TUNING_UNTUNED_NOISE_SIGMA	13.024
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	3327.434
TUNING_UNTUNED_THRESHOLD_95_LOW	2017.016
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	110
TUNING_UNTUNED_THRESHOLD_MEAN	2641
TUNING_UNTUNED_THRESHOLD_SIGMA	333

Filename	Contents
0x17137_L2_warm.json	Download
output.log	Download
0x17137.log	Download
20UPGFC0094519_MODULE__FINAL_WARM_TUNING.zip	Download
