20UPGFC0094519

MODULE/COMPLETE

Component Information

Serial Number	20UPGFC0094519
ProdDB ID	25031a…140f7f
LocalDB ID	6231e4ec5bf2d7000a1bac77
Component Type	fe_chip
Parents	20UPGM22110449 20UPGB42200047
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	20UPGFW0000369

Comments

Test: SLDO QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	6231e4ec5bf2d7000a1bac77
Stage	MODULE/FINAL_WARM
Test Type	SLDO
Institute ObjectId
User Name	JennyLunde
ObjectId of this record	670f83586022d6fb891c8f90
ObjectId of RAW record	670f83546022d6fb891c8f83
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.2.8
MEASUREMENT_DATE	None
YARR_VERSION	v1.5.2
SLDO_ANALOG_OVERHEAD	0.131
SLDO_DIGITAL_OVERHEAD	0.301
SLDO_IINA	0.596
SLDO_IIND	0.846
SLDO_IREF	4
SLDO_ISHUNTA	0.069
SLDO_ISHUNTD	0.196
SLDO_LINEARITY	0.007
SLDO_NOM_INPUT_CURRENT	5.88
SLDO_VDDA	1.2
SLDO_VDDD	1.2
SLDO_VINA	1.487
SLDO_VINA_VIND	0
SLDO_VIND	1.491
SLDO_VI_OFFSET	0.969
SLDO_VI_SLOPE	0.088
SLDO_VOFFS	0.994

Attachments

Filename	Contents
output.log	Download
0x17137.log	Download

RAW Results Record

Download RAW

_id

670f83546022d6fb891c8f83

raw

serialNumber

testType

subtestType

results

stage

component

dbVersion

address

sys

20UPGFC0094519

SLDO

property

YARR_VERSION	v1.5.2
SLDO_MEASUREMENT_VERSION	2.2.7.dev15

comment

Measurements

Temperature

X	False
Unit	C
Values	22.432 23.308 23.258 23.116 23.028 23.208 22.874 22.152 21.732

SetCurrent

X	False
Unit	A
Values	7.48 7.28 7.08 6.880000000000001 6.68 6.48 6.28 6.08 5.88

Current

X	True
Unit	A
Values	7.482 7.282 7.083 6.883 6.682 6.482 6.282 6.081 5.881

Vmux30

X	False
Unit	V
Values	0.0232476 0.0227279 0.0221627 0.021579 0.0209769 0.0203713 0.0197553 0.0191351 0.0185146

Vmux33

X	False
Unit	V
Values	0.43047 0.425495 0.4205 0.415544 0.41055 0.405571 0.400449 0.395413 0.390312

Vmux37

X	False
Unit	V
Values	0.431271 0.42639 0.421472 0.41644 0.411382 0.406476 0.401258 0.396191 0.391174

Vmux34

X	False
Unit	V
Values	0.625136 0.624759 0.623751 0.62297 0.622215 0.621758 0.62017 0.619513 0.61976

Vmux38

X	False
Unit	V
Values	0.625494 0.62481 0.623676 0.623404 0.62244 0.622139 0.62048 0.620053 0.619927

Vmux36

X	False
Unit	V
Values	0.272106 0.271556 0.271063 0.270272 0.269655 0.268973 0.268271 0.267557 0.266898

Vmux32

X	False
Unit	V
Values	0.618456 0.617975 0.61745 0.616939 0.616255 0.615776 0.615305 0.614613 0.614119

Imux0

X	False
Unit	V
Values	0.0603874 0.0598476 0.0592704 0.0587006 0.0581247 0.0575575 0.0569214 0.0563675 0.0558059

Imux28

X	False
Unit	V
Values	0.3807 0.370261 0.360064 0.349645 0.339166 0.328669 0.317953 0.307372 0.29659

Imux29

X	False
Unit	V
Values	0.0960864 0.0892188 0.0822584 0.0754525 0.0685952 0.0619136 0.0555156 0.048779 0.0423775

Imux30

X	False
Unit	V
Values	0.525389 0.511305 0.497083 0.482834 0.468401 0.453816 0.43925 0.424621 0.409652

Imux31

X	False
Unit	V
Values	0.178964 0.167142 0.15598 0.144394 0.13311 0.121882 0.111393 0.100451 0.0896957

Imux63

X	False
Unit	V
Values	0.0208519 0.0203111 0.0197456 0.0191729 0.0185933 0.0180008 0.0174058 0.0168076 0.0162088

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

RD53B

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AutoRead0	137
AutoRead1	133
AutoRead2	121
AutoRead3	122
AutoRead4	124
AutoRead5	127
AutoRead6	126
AutoRead7	125
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrOverwriteLimit	0
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnEos	1
DataEnHitRemoval	0
DataEnIsoHitRemoval	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	258
DiffTh1M	190
DiffTh1R	258
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	0
EfuseReadData1	0
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	360
InjVcalMed	200
InjVcalRange	1
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	1
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixPortal	5381
PixRegionCol	199
PixRegionRow	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	1000
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	8
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	1
SerSelOut2	1
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	13
SldoTrimD	9
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	5.0 0.179 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.868000030517578
IrefTrim	9
KSenseInA	21268.6015625
KSenseInD	21499.59765625
KSenseShuntA	26332.552734375
KSenseShuntD	26618.548828125
KShuntA	1067.405029296875
KShuntD	1038.5789794921875
Name	0x17137
NfACB	1.2823511362075806
NfASLDO	1.284488558769226
NfDSLDO	1.2853635549545288
NtcCalPar	0.0007488999981433153 0.0002769000129774213 7.059500006789676e-08
VcalPar	4.63700008392334 0.19099999964237213

SoftwareType

ChipID

Name

0x17137

Institution

CERN_PIXEL_MODULES

ModuleSN

20UPGM22110449

AverageTemperature

22.789777777777775

TimeStart

1729069460

TimeEnd

1729069900

MODULE/FINAL_WARM

6231e4ec5bf2d7000a1bac77

1.01

64657cef8d79bac1f3f0056a

mts	2024-10-16 09:11:48.844000
cts	2024-10-16 09:11:48.844000
rev	0

rawHash

ea9fe750edce29082a6adfa2672701cc

stage

MODULE/FINAL_WARM
