20UPGFC0096040

MODULE/COMPLETE

Component Information

Serial Number 20UPGFC0096040
ProdDB ID  892891…9c9ec6
LocalDB ID 622cdb94be7827000a0d8360
Component Type fe_chip
Parents 20UPGM22110275  20UPGB42200117 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Wafer serial number 20UPGFW0000375

 Comments


Test: MIN_HEALTH_TEST QC Passed

(Stage: MODULE/THERMAL_CYCLES)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date a year ago
component ObjectId 622cdb94be7827000a0d8360
Stage MODULE/THERMAL_CYCLES
Test Type MIN_HEALTH_TEST
Institute ObjectId
User Name ShudhashilBharthuar
ObjectId of this record 66fd5f65e0dcee93c4d9dea2
ObjectId of RAW record None
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.2.7
YARR_VERSION None
MIN_HEALTH_BAD_ANALOG 10
MIN_HEALTH_BAD_DIGITAL 0
MIN_HEALTH_DEAD_ANALOG 46
MIN_HEALTH_DEAD_DIGITAL 0
MIN_HEALTH_HIGH_ENC 7
MIN_HEALTH_HIGH_ENC_INDEPENDENT 7
MIN_HEALTH_NOISE_MEAN 115.85
MIN_HEALTH_NOISE_SIGMA 11.84
MIN_HEALTH_THRESHOLD_FAILED_FITS 158
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT 214
MIN_HEALTH_THRESHOLD_MEAN 1854.87
MIN_HEALTH_THRESHOLD_SIGMA 117.78
MIN_HEALTH_TOT_MEAN 7
MIN_HEALTH_TOT_SIGMA 0.13

Attachments

Filename Contents
output.log Download
0x17728.log Download
20UPGFC0096040_MODULE__THERMAL_CYCLES_MIN-HEALTH-TEST.zip Download
