20UPGFC0095317

MODULE/FINAL_COLD

Component Information

Serial Number	20UPGFC0095317
ProdDB ID	bde6f4…520efe
LocalDB ID	622a85693aebf3000ac78f1c
Component Type	fe_chip
Parents	20UPGM22110325 20UPGB42200097
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	20UPGFW0000372

Comments

Test: TUNING QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	622a85693aebf3000ac78f1c
Stage	MODULE/FINAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	MatthiasSaimpert
ObjectId of this record	669a65ec867ba71bd6d7e59e
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.2.6
TUNING_TUNED_NOISE_95_HIGH	144.188
TUNING_TUNED_NOISE_95_LOW	97.447
TUNING_TUNED_NOISE_MEAN	120
TUNING_TUNED_NOISE_SIGMA	12.714
TUNING_TUNED_TDAC_MEAN	1.8
TUNING_TUNED_TDAC_SIGMA	4.8
TUNING_TUNED_THRESHOLD_95_HIGH	1552.134
TUNING_TUNED_THRESHOLD_95_LOW	1399.285
TUNING_TUNED_THRESHOLD_FAILED_FITS	15
TUNING_TUNED_THRESHOLD_MEAN	1474.1
TUNING_TUNED_THRESHOLD_SIGMA	48
TUNING_TUNED_TOT_95_HIGH	7
TUNING_TUNED_TOT_95_LOW	7
TUNING_TUNED_TOT_MEAN	7
TUNING_TUNED_TOT_SIGMA	0
TUNING_UNTUNED_NOISE_95_HIGH	144.605
TUNING_UNTUNED_NOISE_95_LOW	98.63
TUNING_UNTUNED_NOISE_MEAN	120.736
TUNING_UNTUNED_NOISE_SIGMA	12.585
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2658.673
TUNING_UNTUNED_THRESHOLD_95_LOW	1394.789
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	132
TUNING_UNTUNED_THRESHOLD_MEAN	2016
TUNING_UNTUNED_THRESHOLD_SIGMA	321

Attachments

Filename	Contents
0x17455_MODULE/FINAL_WARM_L2_warm.json	Download
output.log	Download
0x17455.log	Download
20UPGFC0095317_MODULE__FINAL_WARM_TUNING.zip	Download
