20UPGFC0095285

MODULE/FINAL_COLD

Component Information

Serial Number 20UPGFC0095285
ProdDB ID  77fe08…4df216
LocalDB ID 622a84d53aebf3000ac78e08
Component Type fe_chip
Parents 20UPGM22110325  20UPGB42200097 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Wafer serial number 20UPGFW0000372

 Comments


Test: PIXEL_FAILURE_ANALYSIS QC Failed

(Stage: MODULE/POST_PARYLENE_COLD)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date a year ago
component ObjectId 622a84d53aebf3000ac78e08
Stage MODULE/POST_PARYLENE_COLD
Test Type PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name MariannaLiberatore
ObjectId of this record 66111f0138433d408c5c2af9
ObjectId of RAW record None
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.2.4rc1
PIXEL_FAILURE_BAD_ANALOG 8
PIXEL_FAILURE_BAD_DIGITAL 0
PIXEL_FAILURE_DEAD_ANALOG 0
PIXEL_FAILURE_DEAD_DIGITAL 0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN -1
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN 0
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN 0
PIXEL_FAILURE_DISCONNECTED_PIXELS 6
PIXEL_FAILURE_ELECTRICALLY_FAILED 1732
PIXEL_FAILURE_FAILING_PIXELS 1732
PIXEL_FAILURE_HIGH_ENC 1
PIXEL_FAILURE_HIGH_NOISE 7
PIXEL_FAILURE_MERGED_BUMPS 0
PIXEL_FAILURE_SOURCE_SCAN_DONE False
