Database for ITk Pixel Module

Serial Number	20UPGFC0095269
ProdDB ID	758002…791104
LocalDB ID	622a849f3aebf3000ac78d9a
Component Type	fe_chip
Parents	20UPGM22110325 20UPGB42200097
Children	No match.
Flags

Item	Value
Wafer serial number	20UPGFW0000372

Key	Data
QC Passed	False
Date	a year ago
component ObjectId	622a849f3aebf3000ac78d9a
Stage	MODULE/THERMAL_CYCLES
Test Type	PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name	MatthiasSaimpert
ObjectId of this record	6686696bbb14878ce3bfba3e
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.2.5rc1
PIXEL_FAILURE_BAD_ANALOG	13
PIXEL_FAILURE_BAD_DIGITAL	0
PIXEL_FAILURE_DEAD_ANALOG	1
PIXEL_FAILURE_DEAD_DIGITAL	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	0
PIXEL_FAILURE_DISCONNECTED_PIXELS	0
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC	8
PIXEL_FAILURE_ELECTRICALLY_FAILED	1704
PIXEL_FAILURE_FAILING_PIXELS	1704
PIXEL_FAILURE_HIGH_ENC	7
PIXEL_FAILURE_HIGH_NOISE	11
PIXEL_FAILURE_MERGED_BUMPS	0
PIXEL_FAILURE_SOURCE_SCAN_DONE	False
PIXEL_FAILURE_TUNING_BAD	1672

Filename	Contents
output.log	Download
0x17425.log	Download
20UPGFC0095269_MODULE__THERMAL_CYCLES_PIXEL-FAILURE-ANALYSIS.zip	Download
