20UPGFC0084904

MODULE/LONG_TERM_STABILITY_TEST

Component Information

Serial Number 20UPGFC0084904
ProdDB ID  1d97a1…4464d5
LocalDB ID 6222072180e95c000a45eb92
Component Type fe_chip
Parents No match.
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Wafer serial number 20UPGFW0000331

 Comments


Test: SLDO QC Failed

(Stage: MODULE/INITIAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date 2 years ago
component ObjectId 6222072180e95c000a45eb92
Stage MODULE/INITIAL_WARM
Test Type SLDO
Institute ObjectId
User Name None
ObjectId of this record 6573928e35689ddfe79d01fc
ObjectId of RAW record 6573928a35689ddfe79d01ef
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.2.0
MEASUREMENT_VERSION 2.2.1rc1.dev27
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
SLDO_LINEARITY 0.035
SLDO_VINA_VIND -0.01
SLDO_VDDA 1.19
SLDO_VDDD 1.19
SLDO_VINA 1.474
SLDO_VIND 1.479
SLDO_VOFFS 0.98
SLDO_IINA 0.611
SLDO_IIND 0.868
SLDO_IREF 4.0
SLDO_ISHUNTA 0.042
SLDO_ISHUNTD 0.218
SLDO_ANALOG_OVERHEAD 0.073
SLDO_DIGITAL_OVERHEAD 0.336
SLDO_VI_SLOPE 0.088
SLDO_VI_OFFSET 0.961
SLDO_NOM_INPUT_CURRENT 5.88
