20UPGFC0084898

MODULE/THERMAL_CYCLES

Component Information

Serial Number 20UPGFC0084898
ProdDB ID  ef6d0d…ee5db2
LocalDB ID 6222071b80e95c000a45eb80
Component Type fe_chip
Parents 20UPGM22110394  20UPGB42300071 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Wafer serial number 20UPGFW0000331

 Comments


Test: TUNING QC Failed

(Stage: MODULE/POST_PARYLENE_COLD)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date a year ago
component ObjectId 6222071b80e95c000a45eb80
Stage MODULE/POST_PARYLENE_COLD
Test Type TUNING
Institute ObjectId
User Name JenniferOtt
ObjectId of this record 65ea2fa3447687fe331b59f2
ObjectId of RAW record None
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.2.3rc4
TUNING_TUNED_NOISE_95_HIGH 59.215
TUNING_TUNED_NOISE_95_LOW 28.456
TUNING_TUNED_NOISE_MEAN 42.746
TUNING_TUNED_NOISE_SIGMA 9.46
TUNING_TUNED_TDAC_MEAN 3.6
TUNING_TUNED_TDAC_SIGMA 5.5
TUNING_TUNED_THRESHOLD_95_HIGH 1556.334
TUNING_TUNED_THRESHOLD_95_LOW 1396.719
TUNING_TUNED_THRESHOLD_FAILED_FITS 12
TUNING_TUNED_THRESHOLD_MEAN 1495
TUNING_TUNED_THRESHOLD_SIGMA 48
TUNING_TUNED_TOT_95_HIGH -999
TUNING_TUNED_TOT_95_LOW -999
TUNING_TUNED_TOT_MEAN -999
TUNING_TUNED_TOT_SIGMA -999
TUNING_UNTUNED_NOISE_95_HIGH 62.33
TUNING_UNTUNED_NOISE_95_LOW 28.925
TUNING_UNTUNED_NOISE_MEAN 44.256
TUNING_UNTUNED_NOISE_SIGMA 9.95
TUNING_UNTUNED_TDAC_MEAN 0
TUNING_UNTUNED_TDAC_SIGMA 0
TUNING_UNTUNED_THRESHOLD_95_HIGH 2734.697
TUNING_UNTUNED_THRESHOLD_95_LOW 1375.92
TUNING_UNTUNED_THRESHOLD_FAILED_FITS 20
TUNING_UNTUNED_THRESHOLD_MEAN 1992
TUNING_UNTUNED_THRESHOLD_SIGMA 345

Attachments

Filename Contents
0x14ba2_MODULE/POST_PARYLENE_COLD_L2_cold.json Download
output.log Download
0x14ba2.log Download
20UPGFC0084898_MODULE__POST_PARYLENE_COLD_TUNING.zip Download
