20UPGM24830473 (ANL_ITkPix_192)

MODULE/UNHAPPY

View QC Summary

Component Information

Serial Number 20UPGM24830473
ProdDB ID  7ec4c2…581801
LocalDB ID 6938760e88b791b617083368
Component Type MODULE
Parents No match.
Children 20UPGB43200663 Bare Module 20UPGFC0143927 FE Chip 20UPGFC0143992 FE Chip 20UPGFC0144027 FE Chip 20UPGFC0144073 FE Chip 20UPGPQ2830473 PCB
Flags •  PROBLEMATIC_CORE_COLUMN
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal True
Alternative ID ANL_ITkPix_192
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Passed

(Stage: MODULE/INITIAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 3 months ago
component ObjectId 6938760e88b791b617083368
Stage MODULE/INITIAL_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name DanielAceves
ObjectId of this record 69cabc9840915667944af7e7
ObjectId of RAW record 69cabc9740915667944af7e0
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.8.1
TEMP 20
HUM 0
MEASUREMENT_DATE 2026-03-30T17:50:09.000+00:00
MEASUREMENT_DURATION 988
IV_ARRAY {'time': [15.898549556732178, 44.088228702545166, 68.07749009132385, 92.02656698226929, 115.98995876312256, 140.03056025505066, 163.92341566085815, 187.85733246803284, 211.6919891834259, 235.6920988559723, 259.5842890739441, 283.5675094127655, 307.4891610145569, 331.39501667022705, 355.4754252433777, 379.3639135360718, 403.251323223114, 427.10076785087585, 451.01862049102783, 475.0237760543823, 498.93053936958313, 522.853241443634, 546.747891664505, 570.7338037490845, 594.5951313972473, 618.6053669452667, 642.4506316184998, 666.2030854225159, 690.2248017787933, 714.1608963012695, 738.0739657878876, 761.9723336696625, 785.9128322601318, 809.8437192440033, 833.8182244300842, 857.6751091480255, 881.6643054485321, 905.6054689884186, 929.5225949287415, 953.4919810295105, 977.3930807113647], 'voltage': [0, 5, 10, 15.01, 20, 25, 30.01, 35, 40, 45, 50, 55, 60, 65.01, 70, 75, 80, 85, 90, 95, 100, 105, 110, 115, 120, 125, 130, 135, 140, 145, 150.01, 155, 160, 165, 170, 175, 180, 185, 190, 195, 200], 'current': [0, 0.134, 0.149, 0.158, 0.165, 0.171, 0.175, 0.179, 0.182, 0.185, 0.18800000000000003, 0.19100000000000003, 0.193, 0.19499999999999998, 0.197, 0.2, 0.202, 0.203, 0.205, 0.208, 0.21, 0.211, 0.213, 0.215, 0.217, 0.21900000000000003, 0.221, 0.223, 0.225, 0.22599999999999998, 0.22899999999999998, 0.231, 0.233, 0.234, 0.23699999999999996, 0.23899999999999996, 0.24100000000000002, 0.243, 0.245, 0.248, 0.25], 'sigma current': [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 2.6469779601696886e-17, 2.6469779601696886e-17, 0, 2.6469779601696886e-17, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 2.6469779601696886e-17, 0, 0, 0, 2.6469779601696886e-17, 2.6469779601696886e-17, 0, 0, 0, 2.6469779601696886e-17, 0, 0, 0, 0, 0, 0], 'temperature': [20, 20, 20, 20, 20, 19.97, 20.03, 20, 20, 20, 20, 20, 20, 20, 20, 20, 20.03, 20, 20, 20.03, 20.03, 20, 20, 20.03, 20, 19.97, 20, 20.06, 20, 19.97, 20, 20, 20, 20, 20, 20.03, 20.03, 20, 20, 20, 20], 'humidity': []}
BREAKDOWN_VOLTAGE -999
BREAKDOWN_REDUCTION 0
NO_BREAKDOWN_VOLTAGE_OBSERVED True
MAXIMUM_VOLTAGE 200
LEAK_CURRENT 0.217
LEAK_INCREASE_FACTOR 0.97
LEAK_PER_AREA 0.014
