20UPGM24830264 (ANL_ITkPix_188)

MODULE/POST_PARYLENE_COLD

View QC Summary

Component Information

Serial Number 20UPGM24830264
ProdDB ID  7e02bd…e6003a
LocalDB ID 690e4e7507e8852b9293c56d
Component Type MODULE
Parents No match.
Children 20UPGB43000296 Bare Module 20UPGFC0223158 FE Chip 20UPGFC0223160 FE Chip 20UPGFC0223164 FE Chip 20UPGFC0223162 FE Chip 20UPGPQ2830264 PCB
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal False
Alternative ID ANL_ITkPix_188
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 3 months ago
component ObjectId 690e4e7507e8852b9293c56d
Stage MODULE/POST_PARYLENE_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name DanielAceves
ObjectId of this record 69bc5670f97f394ea371e230
ObjectId of RAW record 69bc566ef97f394ea371e229
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.8.1
HUM 0
MEASUREMENT_DATE 2026-03-19T17:16:00.000+00:00
MEASUREMENT_DURATION 1005
TEMP 20
BREAKDOWN_REDUCTION 0
BREAKDOWN_VOLTAGE -999
IV_ARRAY {'time': [15.745126724243164, 41.65194010734558, 65.62925577163696, 89.50393581390381, 113.22526097297668, 137.0045690536499, 160.75811791419983, 184.51479411125183, 208.3463454246521, 232.08596968650818, 255.99983716011047, 279.5779507160187, 303.4214172363281, 331.88816833496094, 355.72173714637756, 381.5920424461365, 405.44749093055725, 431.0075430870056, 454.8404471874237, 480.4636507034302, 505.0883376598358, 529.0033280849457, 552.72425532341, 576.6229050159454, 603.1353597640991, 627.8748614788055, 651.5967555046082, 675.2437474727631, 700.0308830738068, 723.7667396068573, 749.7562119960785, 774.4414482116699, 798.2747855186462, 822.1029224395752, 845.9158623218536, 869.5711071491241, 896.3723163604736, 921.1966466903687, 945.1240811347961, 968.7316675186157, 992.5328514575958], 'voltage': [0.05, 5, 10, 15, 20.01, 25, 30, 35, 40, 45, 50, 55, 60, 65, 70, 75, 80, 85, 90, 95, 100, 105, 110.01, 115, 120, 125, 130, 135, 140, 145, 150, 155, 160, 165, 170, 175, 180, 185, 190, 195, 200], 'current': [0.0003333333333333334, 0.050666666666666665, 0.054000000000000006, 0.057, 0.059, 0.06, 0.062, 0.062, 0.063, 0.064, 0.065, 0.065, 0.067, 0.071, 0.076, 0.081, 0.087, 0.092, 0.098, 0.104, 0.109, 0.115, 0.121, 0.127, 0.133, 0.14, 0.147, 0.154, 0.16133333333333333, 0.16999999999999998, 0.17799999999999996, 0.18800000000000003, 0.2, 0.213, 0.22599999999999998, 0.243, 0.256, 0.276, 0.2966666666666667, 0.31, 0.338], 'sigma current': [0.00047140452079103175, 0.00047140452079102963, 6.6174449004242214e-18, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0.00047140452079102963, 2.6469779601696886e-17, 2.6469779601696886e-17, 2.6469779601696886e-17, 0, 0, 2.6469779601696886e-17, 0, 0, 0, 0.0009428090415820843, 0, 0], 'temperature': [20, 20, 20, 20, 19.97, 20, 20, 20, 20, 20, 20, 20, 20, 20, 19.97, 20.03, 20, 20, 20, 20, 20, 20, 20, 19.97, 20, 20.03, 20, 20, 20.03, 20, 20.03, 20.03, 20, 19.97, 20.03, 20, 20, 19.97, 20, 19.97, 19.97], 'humidity': []}
LEAK_CURRENT 0.115
LEAK_INCREASE_FACTOR 1.72
LEAK_PER_AREA 0.007
MAXIMUM_VOLTAGE 200
NO_BREAKDOWN_VOLTAGE_OBSERVED True

Attachments

Filename Contents
output.log Download

RAW Results Record

Download RAW
_id69bc566ef97f394ea371e229
raw
serialNumbertestTyperunNumberresultssubtestTypestagecomponentdbVersionaddresssys
20UPGM24830264IV_MEASURE69bc333c365e363c1cf20dc8
DCSdata
Measurements
time
XFalse
Units
Values
  • 15.745126724243164
  • 41.65194010734558
  • 65.62925577163696
  • 89.50393581390381
  • 113.22526097297668
  • 137.0045690536499
  • 160.75811791419983
  • 184.51479411125183
  • 208.3463454246521
  • 232.08596968650818
  • 255.99983716011047
  • 279.5779507160187
  • 303.4214172363281
  • 331.88816833496094
  • 355.72173714637756
  • 381.5920424461365
  • 405.44749093055725
  • 431.0075430870056
  • 454.8404471874237
  • 480.4636507034302
  • 505.0883376598358
  • 529.0033280849457
  • 552.72425532341
  • 576.6229050159454
  • 603.1353597640991
  • 627.8748614788055
  • 651.5967555046082
  • 675.2437474727631
  • 700.0308830738068
  • 723.7667396068573
  • 749.7562119960785
  • 774.4414482116699
  • 798.2747855186462
  • 822.1029224395752
  • 845.9158623218536
  • 869.5711071491241
  • 896.3723163604736
  • 921.1966466903687
  • 945.1240811347961
  • 968.7316675186157
  • 992.5328514575958
voltage
XTrue
UnitV
Values
  • -0.05
  • -5.0
  • -10.0
  • -15.0
  • -20.01
  • -25.0
  • -30.0
  • -35.0
  • -40.0
  • -45.0
  • -50.0
  • -55.0
  • -60.0
  • -65.0
  • -70.0
  • -75.0
  • -80.0
  • -85.0
  • -90.0
  • -95.0
  • -100.0
  • -105.0
  • -110.01
  • -115.0
  • -120.0
  • -125.0
  • -130.0
  • -135.0
  • -140.0
  • -145.0
  • -150.0
  • -155.0
  • -160.0
  • -165.0
  • -170.0
  • -175.0
  • -180.0
  • -185.0
  • -190.0
  • -195.0
  • -200.0
current
XFalse
UnitA
Values
  • 3.3333333333333337e-10
  • 5.0666666666666664e-08
  • 5.4e-08
  • 5.7e-08
  • 5.899999999999999e-08
  • 6e-08
  • 6.2e-08
  • 6.2e-08
  • 6.3e-08
  • 6.4e-08
  • 6.5e-08
  • 6.5e-08
  • 6.7e-08
  • 7.099999999999999e-08
  • 7.599999999999999e-08
  • 8.1e-08
  • 8.699999999999998e-08
  • 9.199999999999999e-08
  • 9.8e-08
  • 1.0399999999999999e-07
  • 1.09e-07
  • 1.15e-07
  • 1.2099999999999998e-07
  • 1.2699999999999999e-07
  • 1.33e-07
  • 1.4e-07
  • 1.4699999999999998e-07
  • 1.54e-07
  • 1.6133333333333332e-07
  • 1.7e-07
  • 1.7799999999999995e-07
  • 1.8800000000000002e-07
  • 2e-07
  • 2.13e-07
  • 2.2599999999999996e-07
  • 2.43e-07
  • 2.56e-07
  • 2.7600000000000004e-07
  • 2.9666666666666665e-07
  • 3.1e-07
  • 3.38e-07
sigma current
XFalse
UnitA
Values
  • 4.714045207910317e-10
  • 4.714045207910296e-10
  • 6.617444900424222e-24
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 0.0
  • 4.714045207910296e-10
  • 2.6469779601696886e-23
  • 2.6469779601696886e-23
  • 2.6469779601696886e-23
  • 0.0
  • 0.0
  • 2.6469779601696886e-23
  • 0.0
  • 0.0
  • 0.0
  • 9.428090415820843e-10
  • 0.0
  • 0.0
temperature
XFalse
UnitC
Values
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 19.97
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 19.97
  • 20.03
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 20.0
  • 19.97
  • 20.0
  • 20.03
  • 20.0
  • 20.0
  • 20.03
  • 20.0
  • 20.03
  • 20.03
  • 20.0
  • 19.97
  • 20.03
  • 20.0
  • 20.0
  • 19.97
  • 20.0
  • 19.97
  • 19.97
humidity
XFalse
Unit%
Values
Metadata
AverageTemperature19.999268292682927
SettlingTime15
TimeStart1773940560
TimeEnd1773941565
InstitutionANL_PIXEL_MODULES
ModuleSN20UPGM24830264
DepletionVoltageNone
comment
property
IV_MEASURE_MEASUREMENT_VERSION2.8.0
MODULE/POST_PARYLENE_WARM690e4e7507e8852b9293c56d1.0164657cef8d79bac1f3f00578
mts2026-03-19 20:02:54.922000
cts2026-03-19 20:02:54.922000
rev0
rawHashb15923c952b9412c0c335aaf5de3a411
stageMODULE/POST_PARYLENE_WARM
