20UPGM24830013 (ANL_ITkPix_185)

MODULE/POST_PARYLENE_COLD

View QC Summary

Component Information

Serial Number 20UPGM24830013
ProdDB ID  770a41…72090c
LocalDB ID 690e471744c06a976341e2b5
Component Type MODULE
Parents No match.
Children 20UPGB43000292 Bare Module 20UPGFC0222756 FE Chip 20UPGFC0222757 FE Chip 20UPGFC0222744 FE Chip 20UPGFC0222763 FE Chip 20UPGPQ2830013 PCB
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal False
Alternative ID ANL_ITkPix_185
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Passed

(Stage: MODULE/INITIAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 3 months ago
component ObjectId 690e471744c06a976341e2b5
Stage MODULE/INITIAL_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name DavidJiang
ObjectId of this record 69b9cef0a665fe5624623fcd
ObjectId of RAW record 692f542fd7bf966e0aafbded
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.8.1rc1
HUM 0
MEASUREMENT_DATE 2025-12-02T20:42:18.000+00:00
MEASUREMENT_DURATION 1047
TEMP 20
BREAKDOWN_REDUCTION 0
BREAKDOWN_VOLTAGE -999
IV_ARRAY {'time': [15.823298215866089, 40.73981189727783, 66.47987508773804, 92.18761682510376, 117.88942313194275, 143.576313495636, 169.24122738838196, 194.93040227890015, 220.49990487098694, 246.25404119491577, 271.85560512542725, 297.4784960746765, 322.9568245410919, 348.7157461643219, 371.959356546402, 397.0968255996704, 422.8032658100128, 448.437397480011, 473.94895696640015, 499.7072055339813, 525.3216915130615, 550.9512057304382, 576.6438875198364, 602.295524597168, 627.9771933555603, 653.6841931343079, 679.5287327766418, 705.0825757980347, 730.7859373092651, 756.3777136802673, 782.1173806190491, 807.7807312011719, 833.5280075073242, 859.2095999717712, 884.8365161418915, 910.6332266330719, 936.1734445095062, 961.9264526367188, 985.236428976059, 1010.3557131290436, 1036.186084985733], 'voltage': [0, 5, 10, 15, 20, 25, 30, 35.01, 40, 45.01, 50, 55.01, 60, 65.01, 70.01, 75.01, 80.01, 85.01, 90.01, 95.02, 100.01, 105.02, 110.01, 115.02, 120.01, 125.02, 130.01, 135.02, 140.01, 145.02, 150.01, 155.02, 160.01, 165.02, 170.01, 175.02, 180.01, 185.02, 190.02, 195.02, 200.02], 'current': [0, 0.052, 0.056, 0.057999999999999996, 0.06, 0.062, 0.063, 0.064, 0.065, 0.066, 0.067, 0.067, 0.068, 0.068, 0.069, 0.07, 0.07, 0.071, 0.071, 0.072, 0.072, 0.073, 0.074, 0.074, 0.075, 0.075, 0.076, 0.077, 0.077, 0.078, 0.078, 0.079, 0.08000000000000002, 0.08000000000000002, 0.081, 0.082, 0.083, 0.084, 0.08499999999999999, 0.08499999999999999, 0.086], 'sigma current': [0, 0, 0, 6.6174449004242214e-18, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1.3234889800848443e-17, 1.3234889800848443e-17, 0, 0, 0, 0, 1.3234889800848443e-17, 1.3234889800848443e-17, 0], 'temperature': [20.03, 20, 19.97, 20.03, 20, 20, 20, 20, 20, 20, 20, 19.97, 20, 20, 20.03, 19.97, 20, 20.03, 20.03, 19.97, 20.03, 20, 20, 20, 20, 19.97, 19.97, 20, 20.03, 20, 20, 20, 19.97, 19.97, 20, 20.03, 19.97, 20.03, 20, 19.97, 20], 'humidity': []}
LEAK_CURRENT 0.073
LEAK_INCREASE_FACTOR 1.06
LEAK_PER_AREA 0.005
MAXIMUM_VOLTAGE 200.02
NO_BREAKDOWN_VOLTAGE_OBSERVED True
