20UPGM24211761 (ANL_ITkPix_140)

MODULE/FINAL_COLD

View QC Summary

Component Information

Serial Number 20UPGM24211761
ProdDB ID  da08d9…d64efb
LocalDB ID 689ce9a34352ea8e9ff68678
Component Type MODULE
Parents No match.
Children 20UPGB43200441 Bare Module 20UPGFC0145956 FE Chip 20UPGFC0146117 FE Chip 20UPGFC0146089 FE Chip 20UPGFC0146103 FE Chip 20UPGPQ4211761 PCB
Flags •  INFO_CORE_COLUMN
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal False
Alternative ID ANL_ITkPix_140
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Passed

(Stage: MODULE/FINAL_COLD)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 2 days ago
component ObjectId 689ce9a34352ea8e9ff68678
Stage MODULE/FINAL_COLD
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 6a2a13114a7e8678e2bbb7cf
ObjectId of RAW record 6a2a130d4a7e8678e2bbb7c8
Tags ganymede_3

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.8.1.dev0
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPGM24211761
IV_ARRAY {'time': [3.049290418624878, 9.496020793914795, 15.905606031417847, 22.345670700073242, 28.781737327575684, 35.40158724784851, 41.82602262496948, 48.26071333885193, 54.67667531967163, 59.08766961097717, 65.49665021896362, 71.92467451095581, 78.34908819198608, 84.76321721076965, 91.1881172657013, 97.81466484069824, 104.25252676010132, 110.67312502861023, 117.08887648582458, 123.51641035079956, 129.93148922920227, 136.37462496757507, 142.7968373298645, 149.2153251171112, 155.649005651474, 162.28163623809814, 168.70838117599487, 175.12582302093506, 181.54436445236206, 187.95469450950623, 194.3654968738556, 200.78708243370056, 207.22283339500427, 213.6507375240326, 220.0603518486023, 226.66747450828552, 233.09755206108093, 239.54164958000183, 245.9646680355072, 252.37819576263428, 258.8097634315491], 'voltage': [0.056, 5.07, 10.01, 15.122, 19.962, 25.034, 30.026, 35.028, 40.026, 45.026, 50.024, 55.02, 60.026, 65.024, 70.024, 75.024, 80.022, 85.022, 90.02, 95.012, 100.02, 105.014, 110.02, 115.018, 120.028, 125.024, 130.034, 135.028, 140.036, 145.026, 150.03, 155.028, 160.032, 165.032, 170.03, 175.034, 180.036, 185.034, 190.034, 195.032, 200.03], 'current': [0.031, 0.0325, 0.028, 0.024, 0.025500000000000002, 0.028, 0.023, 0.024, 0.0225, 0.025500000000000002, 0.025, 0.021500000000000002, 0.0245, 0.021, 0.025, 0.027000000000000003, 0.021, 0.023500000000000004, 0.025, 0.028, 0.027500000000000004, 0.026000000000000006, 0.026000000000000006, 0.025500000000000002, 0.022, 0.0225, 0.0225, 0.021500000000000002, 0.021500000000000002, 0.021, 0.020000000000000004, 0.022, 0.024, 0.021500000000000002, 0.0195, 0.0175, 0.0205, 0.021, 0.018, 0.021500000000000002, 0.019000000000000003], 'sigma current': [0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 3.3087224502121107e-18, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 3.3087224502121107e-18, 0.0, 0.0, 0.0, 3.3087224502121107e-18, 3.3087224502121107e-18, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 3.3087224502121107e-18, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], 'temperature': [-18.597214662, -18.822269307, -18.97654212, -19.012988942, -19.031233545, -19.067765256, -19.012988942, -18.958339849, -18.89474247, -18.840366721, -18.713975379, -18.651032548, -18.552459798, -18.454296007, -18.36540783, -18.312234433, -18.215058202, -18.118277833, -18.013146413, -17.943315778, -17.821602168, -17.804265079, -17.691879697, -17.605787485, -17.537136, -17.460137518, -17.400420304, -17.332353544, -17.230613726, -17.205245914, -17.120879205, -17.078806469, -16.994880758, -16.944665195, -16.894553917, -16.802952448, -16.769728722, -16.753133962, -16.670330474, -16.653803715, -16.579572523], 'humidity': []}
BREAKDOWN_VOLTAGE -999
BREAKDOWN_REDUCTION 0
NO_BREAKDOWN_VOLTAGE_OBSERVED True
MAXIMUM_VOLTAGE 200.03
LEAK_CURRENT 0.025500000000000002
LEAK_INCREASE_FACTOR 0.06529253616694405
LEAK_PER_AREA 0.002
ANALYSIS_VERSION mqat v2.9.0
TEMP -17.88
HUM 0
MEASUREMENT_DATE 2026-06-11T01:38:02.000+00:00
MEASUREMENT_DURATION 401
