20UPGM24211761 (ANL_ITkPix_140)

MODULE/FINAL_COLD

View QC Summary

Component Information

Serial Number 20UPGM24211761
ProdDB ID  da08d9…d64efb
LocalDB ID 689ce9a34352ea8e9ff68678
Component Type MODULE
Parents No match.
Children 20UPGB43200441 Bare Module 20UPGFC0145956 FE Chip 20UPGFC0146117 FE Chip 20UPGFC0146089 FE Chip 20UPGFC0146103 FE Chip 20UPGPQ4211761 PCB
Flags •  INFO_CORE_COLUMN
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal False
Alternative ID ANL_ITkPix_140
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Passed

(Stage: MODULE/QC_CROSSCHECK)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date a week ago
component ObjectId 689ce9a34352ea8e9ff68678
Stage MODULE/QC_CROSSCHECK
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 6a1f131b57eb7e2b830e397b
ObjectId of RAW record 6a1f131857eb7e2b830e3974
Tags ganymede_3

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.8.1.dev0
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPGM24211761
IV_ARRAY {'time': [3.0515201091766357, 9.506590604782104, 15.942055702209473, 22.398887157440186, 28.854650020599365, 35.29788637161255, 41.74523591995239, 48.40022325515747, 54.87688970565796, 61.343950510025024, 67.81770014762878, 74.27684760093689, 80.7387797832489, 87.18485355377197, 93.67130446434021, 100.23897099494934, 106.70261573791504, 113.17513370513916, 119.67111778259277, 126.17084527015686, 132.58625054359436, 139.05187606811523, 145.4852478504181, 151.91989636421204, 158.38592505455017, 164.84753036499023, 171.4648516178131, 177.90476489067078, 184.3378496170044, 190.8065299987793, 197.25886988639832, 203.69684267044067, 210.16404485702515, 216.63388299942017, 223.1228437423706, 229.54594826698303, 236.14216208457947, 242.58739686012268, 249.02347707748413, 255.5058901309967, 261.96492409706116], 'voltage': [0.024, 4.928, 9.996, 15.092, 20.014, 25.002, 30.0, 35.0, 40.0, 44.998, 49.998, 54.998, 60.002, 64.998, 70.0, 75.0, 79.998, 84.998, 89.998, 94.99, 100.0, 104.996, 109.998, 114.996, 120.006, 125.004, 130.016, 135.008, 140.018, 145.006, 150.014, 155.014, 160.016, 165.014, 170.016, 175.018, 180.024, 185.024, 190.02, 195.022, 200.016], 'current': [0.036500000000000005, 0.13, 0.154, 0.1715, 0.18250000000000002, 0.186, 0.19650000000000004, 0.2015, 0.207, 0.21000000000000002, 0.2155, 0.21750000000000003, 0.22000000000000003, 0.2255, 0.22750000000000004, 0.23199999999999998, 0.2325, 0.23650000000000002, 0.238, 0.23550000000000001, 0.24050000000000002, 0.2485, 0.25050000000000006, 0.24950000000000003, 0.256, 0.2605, 0.26, 0.2635, 0.258, 0.264, 0.268, 0.2645, 0.27099999999999996, 0.2675, 0.2715, 0.2765, 0.28150000000000003, 0.276, 0.28400000000000003, 0.281, 0.283], 'sigma current': [0.0, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 2.6469779601696886e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 2.6469779601696886e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], 'temperature': [17.942945364, 17.497553436, 17.533027138, 17.731684872, 17.731684872, 17.742543851, 17.886168729, 17.902398202, 18.013137622, 18.026623159, 18.147805554, 18.134357458, 18.24182652, 18.383817876, 18.343678267, 18.450635825, 18.415903168, 18.557333959, 18.437280357, 18.367766436, 18.504017199, 18.679718605, 18.738130862, 18.716898956, 18.862663404, 18.865309241, 18.870600442, 18.994762875, 18.889114689, 19.0079513, 19.121211195, 19.013225579, 19.100161315, 19.047493198, 19.081734536, 19.205311838, 19.29449621, 19.189554993, 19.2971166, 19.202686082, 19.252549174], 'humidity': []}
BREAKDOWN_VOLTAGE -999
BREAKDOWN_REDUCTION 0
NO_BREAKDOWN_VOLTAGE_OBSERVED True
MAXIMUM_VOLTAGE 200.016
LEAK_CURRENT 0.27762522976872805
LEAK_INCREASE_FACTOR 0.7108570727659148
LEAK_PER_AREA 0.017
ANALYSIS_VERSION mqat v2.9.0
TEMP 18.55
HUM 0
MEASUREMENT_DATE 2026-06-02T17:23:24.000+00:00
MEASUREMENT_DURATION 395
