20UPGM24211639 (ANL_ITkPix_138)

MODULE/FINAL_COLD

View QC Summary

Component Information

Serial Number 20UPGM24211639
ProdDB ID  f0bafc…975230
LocalDB ID 689ce957328b0ce1c715d7d0
Component Type MODULE
Parents No match.
Children 20UPGB43200439 Bare Module 20UPGFC0146067 FE Chip 20UPGFC0146069 FE Chip 20UPGFC0146025 FE Chip 20UPGFC0146023 FE Chip 20UPGPQ4211639 PCB
Flags •  INFO_CORE_COLUMN
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal False
Alternative ID ANL_ITkPix_138
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments

Date Commented by on which Component Comment
a week ago pixel (Lawrence Berkeley National Lab - pixel modules) MODULE
20UPGM24211639 		sign-off at MODULE/QC_CROSSCHECK; appended flags: ['INFO_CORE_COLUMN']; next stage: MODULE/PARYLENE_MASKING; comment: Failed 2-1 data transmission. May just be an issue with what version of MQDBT I have. Will proceed with full QC.

Test: IV_MEASURE QC Passed

(Stage: MODULE/QC_CROSSCHECK)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 2 weeks ago
component ObjectId 689ce957328b0ce1c715d7d0
Stage MODULE/QC_CROSSCHECK
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 6a1f12da50c8114339701a9e
ObjectId of RAW record 6a1f12d650c8114339701a97
Tags ganymede_2

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.8.1.dev0
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPGM24211639
IV_ARRAY {'time': [3.0527114868164062, 9.52272653579712, 15.977704048156738, 22.424676418304443, 28.96741771697998, 33.42775011062622, 39.86971092224121, 46.316269636154175, 52.919365644454956, 59.38175654411316, 65.82927584648132, 72.28876185417175, 78.72277617454529, 85.17481565475464, 91.6488037109375, 98.10089707374573, 104.5667245388031, 111.01170659065247, 117.47771716117859, 123.96174025535583, 130.39080047607422, 136.82607197761536, 143.32092380523682, 149.77171921730042, 156.24680256843567, 162.70371532440186, 169.1723690032959, 175.78973150253296, 182.27245140075684, 188.7371790409088, 195.20772409439087, 201.6711287498474, 208.14370560646057, 214.59371709823608, 221.05529403686523, 227.5107536315918, 234.0303192138672, 240.4837565422058, 246.93474698066711, 253.40880370140076, 259.86322498321533], 'voltage': [0.032, 5.016, 10.054, 14.934, 20.11, 24.974, 29.998, 35.004, 39.992, 45.006, 49.994, 55.002, 59.996, 65.0, 70.002, 75.002, 79.998, 84.994, 89.998, 94.996, 99.998, 104.99, 109.994, 114.986, 120.004, 124.994, 130.004, 134.994, 140.0, 144.998, 150.008, 155.004, 160.014, 165.004, 170.018, 175.006, 180.01, 185.002, 190.004, 194.998, 200.006], 'current': [0.038000000000000006, 0.154, 0.19500000000000003, 0.207, 0.2195, 0.2195, 0.22600000000000003, 0.2245, 0.22750000000000004, 0.2315, 0.23199999999999998, 0.2375, 0.23600000000000004, 0.24550000000000002, 0.24450000000000002, 0.25, 0.2515, 0.2545, 0.2635, 0.258, 0.265, 0.2735, 0.27, 0.27449999999999997, 0.277, 0.2775, 0.279, 0.2785, 0.28150000000000003, 0.28900000000000003, 0.29, 0.29400000000000004, 0.2935, 0.29550000000000004, 0.29400000000000004, 0.298, 0.30100000000000005, 0.3015, 0.3055, 0.3065, 0.30250000000000005], 'sigma current': [0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 2.6469779601696886e-17, 2.6469779601696886e-17, 2.6469779601696886e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], 'temperature': [18.042800291, 17.538482035, 17.655595511, 17.652875552, 17.80764054, 17.872639529, 17.91591813, 17.972655917, 18.048191334, 18.107448827, 18.158561051, 18.193498137, 18.26597071, 18.423920832, 18.351709126, 18.48534108, 18.463987239, 18.533349398, 18.663774599, 18.557333959, 18.693000888, 18.799115989, 18.716898956, 18.825605132, 18.751395637, 18.809713543, 18.94461124, 18.846785073, 18.926120078, 19.031680644, 18.94461124, 19.021135827, 19.126472117, 19.139621716, 19.084367398, 19.18430148, 19.289254973, 19.158024666, 19.236808922, 19.320693229, 19.278770664], 'humidity': []}
BREAKDOWN_VOLTAGE -999
BREAKDOWN_REDUCTION 0
NO_BREAKDOWN_VOLTAGE_OBSERVED True
MAXIMUM_VOLTAGE 200.006
LEAK_CURRENT 0.3026806056611342
LEAK_INCREASE_FACTOR 0.7146278022928445
LEAK_PER_AREA 0.019
ANALYSIS_VERSION mqat v2.9.0
TEMP 18.58
HUM 0
MEASUREMENT_DATE 2026-06-02T17:22:18.000+00:00
MEASUREMENT_DURATION 393
