20UPGM24210397 (ANL_ITkPix_124)

MODULE/FINAL_COLD

View QC Summary

Component Information

Serial Number 20UPGM24210397
ProdDB ID  9ddb33…98b09b
LocalDB ID 689ce4b9328b0ce1c7159578
Component Type MODULE
Parents No match.
Children 20UPGB43200228 Bare Module 20UPGFC0141607 FE Chip 20UPGFC0141593 FE Chip 20UPGFC0141676 FE Chip 20UPGFC0141722 FE Chip 20UPGPQ4210397 PCB
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal False
Alternative ID ANL_ITkPix_124
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments

Date Commented by on which Component Comment
a week ago pixel (Lawrence Berkeley National Lab - pixel modules) MODULE
20UPGM24210397 		sign-off at MODULE/FINAL_WARM; appended flags: []; next stage: MODULE/FINAL_COLD; comment: Failed LP mode. Want to investigate further.

Test: IV_MEASURE QC Passed

(Stage: MODULE/FINAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date a week ago
component ObjectId 689ce4b9328b0ce1c7159578
Stage MODULE/FINAL_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 6a28953b3b97c76890e923d3
ObjectId of RAW record 6a2895383b97c76890e923cc
Tags ganymede_1

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.8.1.dev0
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPGM24210397
IV_ARRAY {'time': [3.0517988204956055, 9.460740089416504, 15.875038862228394, 24.31340217590332, 30.73440384864807, 37.15377140045166, 43.587810754776, 50.00380516052246, 56.429256200790405, 62.97375965118408, 69.37410640716553, 75.82287311553955, 82.24186491966248, 88.65526556968689, 95.05969429016113, 101.45780396461487, 107.93650197982788, 114.36066436767578, 120.7791850566864, 127.19850826263428, 133.6221103668213, 140.03988885879517, 146.44425678253174, 152.84130311012268, 159.2629270553589, 165.7035002708435, 172.11569714546204, 178.5449767112732, 185.09082293510437, 191.50971484184265, 197.9317352771759, 204.34857964515686, 210.752769947052, 217.16835856437683, 221.6040678024292, 228.04185962677002, 234.45579624176025, 240.88153553009033, 247.3007960319519, 253.70481634140015, 260.13614296913147], 'voltage': [0.02, 5.0, 9.97, 15.034, 20.068, 24.974, 30.0, 35.01, 40.004, 45.01, 49.998, 55.002, 59.986, 65.0, 69.992, 75.0, 79.994, 85.0, 89.994, 95.0, 99.998, 104.996, 109.996, 114.992, 120.0, 125.004, 130.01, 135.006, 140.006, 145.002, 150.01, 154.998, 160.01, 165.008, 170.012, 174.998, 180.0, 184.992, 190.0, 194.988, 200.002], 'current': [0.038000000000000006, 0.1215, 0.135, 0.14700000000000002, 0.159, 0.164, 0.16999999999999998, 0.1755, 0.18250000000000002, 0.184, 0.1845, 0.1905, 0.19799999999999998, 0.196, 0.202, 0.2005, 0.202, 0.21000000000000002, 0.2085, 0.21150000000000002, 0.21250000000000002, 0.21650000000000005, 0.2235, 0.21900000000000003, 0.22200000000000003, 0.22899999999999998, 0.2285, 0.23050000000000004, 0.2315, 0.2335, 0.23600000000000004, 0.24, 0.238, 0.24250000000000002, 0.24750000000000003, 0.24550000000000002, 0.24950000000000003, 0.252, 0.2585, 0.2575, 0.264], 'sigma current': [0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 2.6469779601696886e-17, 2.6469779601696886e-17, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 2.6469779601696886e-17, 2.6469779601696886e-17, 2.6469779601696886e-17, 2.6469779601696886e-17, 0.0, 2.6469779601696886e-17, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], 'temperature': [18.112831881, 18.091295679, 17.850984027, 17.991552067, 18.204242394, 18.102065109, 18.085909966, 18.263288679, 18.466657036, 18.29546221, 18.287421042, 18.447965056, 18.63186933, 18.562662091, 18.687688453, 18.67174732, 18.73017009, 18.873245807, 18.767308128, 18.889114689, 18.815011372, 18.891758952, 19.031680644, 18.939328834, 19.002676398, 19.136992106, 19.036952118, 19.100161315, 19.23418501, 19.108056181, 19.192181519, 19.299736836, 19.168537242, 19.260417229, 19.323312091, 19.226312352, 19.276149204, 19.391349042, 19.409649125, 19.320693229, 19.412262816], 'humidity': []}
BREAKDOWN_VOLTAGE -999
BREAKDOWN_REDUCTION 0
NO_BREAKDOWN_VOLTAGE_OBSERVED True
MAXIMUM_VOLTAGE 200.002
LEAK_CURRENT 0.24224075928152142
LEAK_INCREASE_FACTOR 0.7252717343758126
LEAK_PER_AREA 0.015
ANALYSIS_VERSION mqat v2.9.0
TEMP 18.79
HUM 0
MEASUREMENT_DATE 2026-06-09T22:29:02.000+00:00
MEASUREMENT_DURATION 392

Attachments
