20UPGM24210397 (ANL_ITkPix_124)

MODULE/FINAL_COLD

View QC Summary

Component Information

Serial Number 20UPGM24210397
ProdDB ID  9ddb33…98b09b
LocalDB ID 689ce4b9328b0ce1c7159578
Component Type MODULE
Parents No match.
Children 20UPGB43200228 Bare Module 20UPGFC0141607 FE Chip 20UPGFC0141593 FE Chip 20UPGFC0141676 FE Chip 20UPGFC0141722 FE Chip 20UPGPQ4210397 PCB
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal False
Alternative ID ANL_ITkPix_124
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments

Date Commented by on which Component Comment
a week ago pixel (Lawrence Berkeley National Lab - pixel modules) MODULE
20UPGM24210397 		sign-off at MODULE/FINAL_WARM; appended flags: []; next stage: MODULE/FINAL_COLD; comment: Failed LP mode. Want to investigate further.

Test: IV_MEASURE QC Failed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date 7 months ago
component ObjectId 689ce4b9328b0ce1c7159578
Stage MODULE/POST_PARYLENE_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name Simpson,Liana Rae
ObjectId of this record 6904e76164f873154cbad5a3
ObjectId of RAW record 6904e75f64f873154cbad59c
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.6.4
HUM 0
MEASUREMENT_DATE 2025-10-31T16:22:11.000+00:00
MEASUREMENT_DURATION 1039
TEMP 20
BREAKDOWN_REDUCTION 0
BREAKDOWN_VOLTAGE -999
IV_ARRAY {'time': [15.751394510269165, 45.40248918533325, 72.8945324420929, 98.38682270050049, 123.50651407241821, 148.71413230895996, 173.69414830207825, 198.84688687324524, 223.95490145683289, 249.1331069469452, 274.22244238853455, 299.3490734100342, 324.4234821796417, 349.5673303604126, 374.6772041320801, 399.84295630455017, 424.9410631656647, 450.05793857574463, 475.1815564632416, 500.35871982574463, 525.4757936000824, 550.5836486816406, 575.6987941265106, 600.8329863548279, 625.9301509857178, 651.1059470176697, 676.185076713562, 701.355452299118, 726.4343621730804, 751.5425810813904, 776.6913454532623, 801.8115346431732, 826.8905229568481, 852.0731248855591, 877.1770927906036, 902.3576567173004, 928.5741868019104, 953.6636216640472, 978.7674558162689, 1003.905205488205, 1029.058109998703], 'voltage': [0, 5.02, 9.93, 15.09, 20, 25, 30, 35, 40, 45, 50, 55, 60.01, 65, 70, 75, 80, 85, 90, 95, 100, 105, 110, 115, 120, 125, 130, 135, 140, 145, 150, 155, 160, 165, 170, 175, 180, 185, 190, 195, 200], 'current': [0.009666666666666665, 0.183, 0.2336666666666667, 0.2293333333333333, 0.2596666666666667, 0.267, 0.24466666666666662, 0.2750000000000001, 0.2783333333333334, 0.2726666666666667, 0.26866666666666666, 0.2803333333333334, 0.3046666666666667, 0.28800000000000003, 0.29433333333333334, 0.333, 0.34066666666666673, 0.3273333333333333, 0.3246666666666667, 0.3456666666666667, 0.29, 0.33533333333333337, 0.32866666666666666, 0.31533333333333335, 0.31833333333333336, 0.35766666666666663, 0.308, 0.323, 0.35999999999999993, 0.322, 0.3436666666666667, 0.3426666666666667, 0.3226666666666667, 0.3596666666666667, 0.369, 0.3433333333333334, 0.3366666666666667, 0.323, 0.3646666666666667, 0.35900000000000004, 0.36100000000000004], 'sigma current': [0.0018856180831641266, 0.001414213562373089, 0.005185449728701351, 0.00801387685344753, 0.002357022603955161, 0.016970562748477143, 0.00047140452079104216, 0.0014142135623731015, 0.014613540144521956, 0.007542472332656526, 0.00047140452079101717, 0.006128258770283374, 0.016499158227686123, 0.021213203435596423, 0.010842303978193722, 0.007071067811865458, 0.0018856180831641435, 0.01178511301977578, 0.004714045207910322, 0.00047140452079101717, 0.0014142135623731015, 0.023570226039551584, 0.010842303978193722, 0.028755675768252924, 0.008956685895029601, 0.0018856180831641185, 0.00424264068711928, 0.02828427124746188, 0.0014142135623731015, 0.009899494936611661, 0.016499158227686102, 0.02309882151876054, 0.007542472332656526, 0.014613540144521982, 0.0014142135623731015, 0.018856180831641263, 0.013670731102939898, 0.002828427124746203, 0.006599663291074441, 0.012727922061357838, 0.019798989873223347], 'temperature': [19.94, 19.91, 19.97, 19.97, 19.97, 20, 19.97, 20, 19.97, 20, 20, 20, 20.03, 20, 19.97, 19.94, 19.97, 20.03, 20, 20, 20, 20, 20, 20.03, 20, 20.03, 20.03, 20, 20, 20, 20, 20, 20, 19.97, 20, 20.03, 20.03, 20.03, 20, 20.03, 20.03], 'humidity': []}
LEAK_CURRENT 0.32866666666666666
LEAK_INCREASE_FACTOR 1258567.91
LEAK_PER_AREA 0.02
MAXIMUM_VOLTAGE 200
NO_BREAKDOWN_VOLTAGE_OBSERVED True

Attachments
