20UPGM24211150 (ANL_ITkPix_121)

MODULE/QC_STATUS

View QC Summary

Component Information

Serial Number 20UPGM24211150
ProdDB ID  32a534…d24179
LocalDB ID 689254b30f647c459cade21a
Component Type MODULE
Parents No match.
Children 20UPGB43200224 Bare Module 20UPGFC0141734 FE Chip 20UPGFC0141720 FE Chip 20UPGFC0141755 FE Chip 20UPGFC0141626 FE Chip 20UPGPQ4211150 PCB
Flags •  ANOMALOUS_IV
•  INFO_CORE_COLUMN
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal False
Alternative ID ANL_ITkPix_121
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Failed

(Stage: MODULE/FINAL_COLD)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date a month ago
component ObjectId 689254b30f647c459cade21a
Stage MODULE/FINAL_COLD
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 6a04b18e8a277601d0304064
ObjectId of RAW record 6a04b18c8a277601d030405d
Tags ganymede_3

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.8.1.dev0
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPGM24211150
IV_ARRAY {'time': [3.0475244522094727, 9.489494562149048, 15.922744512557983, 22.33937931060791, 28.770418405532837, 35.2459282875061, 41.666537284851074, 48.10044527053833, 54.54846429824829, 60.960476875305176, 67.37250471115112, 73.82137084007263, 80.36937165260315, 86.81252956390381, 93.24242115020752, 99.70745968818665, 106.1392834186554, 112.58769011497498, 119.0505998134613, 125.47743773460388, 131.93540501594543, 138.35852885246277, 144.80331754684448, 151.22548174858093, 157.70155310630798, 164.15290307998657, 170.59027361869812, 177.0209698677063, 183.45440411567688, 189.87755250930786, 196.28637838363647, 202.72040176391602, 209.1638641357422, 215.5820460319519, 221.99273228645325, 228.40945672988892, 234.8575804233551, 241.29650902748108, 247.70936584472656, 254.12083506584167, 260.5453681945801], 'voltage': [0.038, 4.962, 9.958, 15.118, 20.014, 25.066, 30.002, 35.006, 40.006, 45.004, 50.004, 55.002, 60.006, 65.0, 70.002, 75.002, 80.0, 85.004, 90.0, 94.992, 100.002, 104.998, 110.006, 115.002, 120.01, 125.008, 130.016, 135.012, 140.022, 145.01, 150.016, 155.016, 160.018, 165.018, 170.016, 175.018, 180.024, 185.024, 190.024, 195.022, 200.018], 'current': [0.03950000000000001, 0.027500000000000004, 0.028, 0.0335, 0.030500000000000003, 0.031, 0.027000000000000003, 0.028999999999999998, 0.030500000000000003, 0.027000000000000003, 0.030500000000000003, 0.026499999999999996, 0.033, 0.0285, 0.027500000000000004, 0.026499999999999996, 0.027000000000000003, 0.027000000000000003, 0.025, 0.026499999999999996, 0.025, 0.027500000000000004, 0.027500000000000004, 0.025500000000000002, 0.026000000000000006, 0.026000000000000006, 0.025, 0.029500000000000005, 0.025500000000000002, 0.025, 0.026499999999999996, 0.025, 0.0245, 0.025500000000000002, 0.025, 0.024, 0.025, 0.025500000000000002, 0.023, 0.021500000000000002, 0.020000000000000004], 'sigma current': [0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 3.3087224502121107e-18, 0.0, 0.0, 0.0, 3.3087224502121107e-18, 0.0, 0.0, 0.0, 3.3087224502121107e-18, 0.0, 0.0, 0.0, 3.3087224502121107e-18, 0.0, 0.0, 0.0007071067811865477, 0.0, 3.3087224502121107e-18, 3.3087224502121107e-18, 0.0, 3.3087224502121107e-18, 0.0, 0.0, 3.3087224502121107e-18, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 3.3087224502121107e-18, 0.0, 3.3087224502121107e-18], 'temperature': [-17.752329207, -18.215058202, -18.516716761, -18.713975379, -18.840366721, -18.912895636, -18.949243989, -18.967439225, -18.94015164, -18.89474247, -18.84942064, -18.768060224, -18.72298092, -18.62410829, -18.552459798, -18.481027614, -18.400923109, -18.321088393, -18.25917992, -18.171018273, -18.0831824, -18.030636104, -17.952033424, -17.891076736, -17.81293205, -17.760977347, -17.683256518, -17.622981161, -17.554280429, -17.494328529, -17.434526219, -17.340851342, -17.298392384, -17.239075614, -17.196795919, -17.146158178, -17.095626745, -17.045201107, -16.994880758, -16.936306087, -16.894553917], 'humidity': []}
BREAKDOWN_VOLTAGE -999
BREAKDOWN_REDUCTION -1
NO_BREAKDOWN_VOLTAGE_OBSERVED True
MAXIMUM_VOLTAGE 200.018
LEAK_CURRENT 0.027500000000000004
LEAK_INCREASE_FACTOR -999
LEAK_PER_AREA 0.002
ANALYSIS_VERSION mqat v2.8.1
TEMP -18.01
HUM 0
MEASUREMENT_DATE 2026-05-13T17:08:16.000+00:00
MEASUREMENT_DURATION 396

Attachments

Filename Contents
output.log Download

RAW Results Record

Download RAW
