20UPGM24211149 (ANL_ITkPix_120)

MODULE/QC_STATUS

View QC Summary

Component Information

Serial Number 20UPGM24211149
ProdDB ID  ea6fd4…48e5d5
LocalDB ID 6892548f0f647c459cade18e
Component Type MODULE
Parents No match.
Children 20UPGB43200223 Bare Module 20UPGFC0141718 FE Chip 20UPGFC0141704 FE Chip 20UPGFC0141739 FE Chip 20UPGFC0141610 FE Chip 20UPGPQ4211149 PCB
Flags •  INFO_CORE_COLUMN
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal False
Alternative ID ANL_ITkPix_120
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Passed

(Stage: MODULE/QC_CROSSCHECK)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date a month ago
component ObjectId 6892548f0f647c459cade18e
Stage MODULE/QC_CROSSCHECK
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 6a021fe8e2dc1a549ef7372a
ObjectId of RAW record 6a021fe6e2dc1a549ef73723
Tags ganymede_2

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.8.1.dev0
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPGM24211149
IV_ARRAY {'time': [3.0525224208831787, 9.774552345275879, 16.212858200073242, 20.639660120010376, 27.088912963867188, 33.52655482292175, 39.94379234313965, 46.36856245994568, 52.79410767555237, 59.209969997406006, 65.63368821144104, 72.2777886390686, 78.73462057113647, 85.18728017807007, 91.60750102996826, 98.02960014343262, 104.47527313232422, 110.9062876701355, 117.39357423782349, 123.89089059829712, 130.33161854743958, 136.74770879745483, 143.17684030532837, 149.59152579307556, 156.024840593338, 162.4815526008606, 168.96153116226196, 175.3716492652893, 181.77750277519226, 188.19707798957825, 194.82832741737366, 201.26190996170044, 207.70251607894897, 214.14451551437378, 220.5735583305359, 226.98356461524963, 233.39006781578064, 239.8016288280487, 246.2560715675354, 252.7035300731659, 259.37191891670227], 'voltage': [0.02, 5.112, 10.002, 14.814, 19.906, 25.006, 29.992, 35.0, 39.988, 45.0, 49.99, 54.998, 59.994, 64.998, 69.994, 74.996, 79.996, 84.994, 89.996, 94.99, 99.998, 104.986, 109.994, 114.988, 119.998, 124.99, 130.002, 134.994, 139.996, 144.996, 150.004, 155.004, 160.012, 165.002, 170.016, 175.006, 180.008, 185.0, 190.004, 194.996, 200.006], 'current': [0.037000000000000005, 0.1835, 0.2265, 0.25, 0.2765, 0.28700000000000003, 0.302, 0.3135, 0.3245, 0.335, 0.35, 0.35650000000000004, 0.372, 0.385, 0.3955, 0.40950000000000003, 0.4215, 0.43249999999999994, 0.445, 0.457, 0.47050000000000003, 0.4815, 0.496, 0.5065000000000001, 0.523, 0.5395, 0.5485000000000001, 0.5665, 0.5810000000000001, 0.5905, 0.6124999999999999, 0.627, 0.6400000000000001, 0.6620000000000001, 0.6775, 0.6910000000000002, 0.7104999999999999, 0.7260000000000001, 0.7415, 0.7675, 0.7775000000000001], 'sigma current': [0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 5.293955920339377e-17, 0.0, 5.293955920339377e-17, 0.0014142135623730766, 0.0, 5.293955920339377e-17, 5.293955920339377e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 1.0587911840678754e-16, 1.0587911840678754e-16, 0.0, 1.0587911840678754e-16, 1.0587911840678754e-16, 0.0, 0.0, 0.0, 1.0587911840678754e-16], 'temperature': [17.932136488, 17.595716756, 17.377270773, 17.483901908, 17.696374339, 17.737114702, 17.840152219, 17.875345706, 17.980755273, 17.99694946, 18.104757051, 18.091295679, 18.204242394, 18.330290235, 18.303501903, 18.381143043, 18.362414652, 18.50668457, 18.450635825, 18.570653082, 18.629209518, 18.61324728, 18.751395637, 18.661116706, 18.772611023, 18.772611023, 18.793816263, 18.91555025, 18.904977911, 18.934045802, 19.05012808, 18.986847947, 19.023772265, 19.139621716, 19.081734536, 19.126472117, 19.23418501, 19.158024666, 19.202686082, 19.310216254, 19.215813325], 'humidity': []}
BREAKDOWN_VOLTAGE -999
BREAKDOWN_REDUCTION 0
NO_BREAKDOWN_VOLTAGE_OBSERVED True
MAXIMUM_VOLTAGE 200.006
LEAK_CURRENT 0.5662313837567838
LEAK_INCREASE_FACTOR 0.81
LEAK_PER_AREA 0.036
ANALYSIS_VERSION mqat v2.8.1
TEMP 18.51
HUM 0
MEASUREMENT_DATE 2026-05-11T18:22:25.000+00:00
MEASUREMENT_DURATION 387
