20UPGM24211149 (ANL_ITkPix_120)

MODULE/QC_CROSSCHECK

View QC Summary

Component Information

Serial Number 20UPGM24211149
ProdDB ID  ea6fd4…48e5d5
LocalDB ID 6892548f0f647c459cade18e
Component Type MODULE
Parents No match.
Children 20UPGB43200223 Bare Module 20UPGFC0141718 FE Chip 20UPGFC0141704 FE Chip 20UPGFC0141739 FE Chip 20UPGFC0141610 FE Chip 20UPGPQ4211149 PCB
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal False
Alternative ID ANL_ITkPix_120
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Failed

(Stage: MODULE/INITIAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date 2 months ago
component ObjectId 6892548f0f647c459cade18e
Stage MODULE/INITIAL_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name DanielAceves
ObjectId of this record 68dd8b4912752b66da90ee8e
ObjectId of RAW record 68dd8b4712752b66da90ee87
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.6.4
HUM 0
MEASUREMENT_DATE 2025-10-01T17:43:01.000+00:00
MEASUREMENT_DURATION 1029
TEMP 20
BREAKDOWN_REDUCTION 0
BREAKDOWN_VOLTAGE -999
IV_ARRAY {'time': [15.771472215652466, 43.105687379837036, 68.5507881641388, 93.5345070362091, 118.69575619697571, 143.76449060440063, 168.80066895484924, 193.97492957115173, 219.04109954833984, 244.2016134262085, 269.2884440422058, 294.55175280570984, 319.54099130630493, 344.7187080383301, 369.7756447792053, 395.01493787765503, 420.025643825531, 445.1490957736969, 470.3137855529785, 495.414669752121, 518.2376976013184, 543.7507133483887, 568.8640789985657, 593.928863286972, 619.1199576854706, 644.1999723911285, 669.335774898529, 694.433830499649, 719.584742307663, 744.7580041885376, 769.8992221355438, 794.9643895626068, 817.7722086906433, 843.3039145469666, 868.4443492889404, 893.5449659824371, 918.6444189548492, 943.7529504299164, 968.8210401535034, 994.0578417778015, 1019.1037373542786], 'voltage': [0, 5.05, 10.01, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 65, 70, 75, 80, 85, 90, 95, 100, 105, 110, 115, 120, 125, 130, 135, 140, 145, 150, 155, 160, 165, 170, 175, 180, 185, 190, 195, 200], 'current': [0.024, 0.24, 0.2856666666666666, 0.2996666666666667, 0.3446666666666666, 0.3486666666666666, 0.36333333333333334, 0.3993333333333334, 0.37766666666666665, 0.386, 0.4083333333333333, 0.4216666666666667, 0.42633333333333334, 0.44533333333333336, 0.45199999999999996, 0.4803333333333333, 0.49933333333333335, 0.49333333333333335, 0.48533333333333334, 0.48966666666666664, 0.5106666666666666, 0.5603333333333333, 0.5423333333333334, 0.536, 0.5716666666666667, 0.562, 0.6043333333333333, 0.6110000000000001, 0.6096666666666666, 0.6296666666666666, 0.6490000000000001, 0.6389999999999999, 0.6436666666666666, 0.6503333333333334, 0.6653333333333333, 0.6993333333333333, 0.6933333333333332, 0.7116666666666667, 0.7336666666666666, 0.7476666666666667, 0.7556666666666667], 'sigma current': [0, 0, 0.014613540144521956, 0.003771236166328263, 0.004714045207910297, 0.002357022603955161, 0.008956685895029601, 0.0009428090415820593, 0.002357022603955161, 0.0014142135623731015, 0.01037089945740268, 0.006599663291074441, 0.017441967269268187, 0.015084944665313025, 0.007071067811865483, 0.006128258770283424, 0.0009428090415820843, 0.01037089945740268, 0.0009428090415820843, 0.002357022603955186, 0.015084944665313049, 0.0009428090415820343, 0.006599663291074441, 0.004242640687119305, 0.013670731102939848, 0.015556349186104018, 0.009428090415820644, 0.007071067811865457, 0.013670731102939898, 0.010842303978193746, 0.0014142135623731015, 1.0587911840678754e-16, 0.019327585352432303, 0.0009428090415820843, 0.014613540144521982, 0.010370899457402726, 0.008013876853447491, 0.013670731102939948, 0.018856180831641287, 0.008013876853447541, 0.017441967269268187], 'temperature': [19.94, 19.97, 19.94, 19.97, 20.03, 20.06, 20.09, 20.06, 20.09, 20.03, 19.88, 19.84, 19.94, 19.94, 19.97, 20.06, 20.06, 20.06, 20.03, 20.06, 20.03, 20.03, 20, 20, 20, 20, 20, 20, 20, 20, 20, 20.03, 20, 19.97, 20, 19.97, 20, 19.97, 19.97, 20, 19.97], 'humidity': []}
LEAK_CURRENT 0.536
LEAK_INCREASE_FACTOR 975231.71
LEAK_PER_AREA 0.03
MAXIMUM_VOLTAGE 200
NO_BREAKDOWN_VOLTAGE_OBSERVED True
