20UPGM24211330 (ANL_ITkPix_104)

MODULE/POST_PARYLENE_WARM

View QC Summary

Component Information

Serial Number 20UPGM24211330
ProdDB ID  6291e0…8cffff
LocalDB ID 68659ea6207cb9964861d639
Component Type MODULE
Parents No match.
Children 20UPGB43200207 Bare Module 20UPGFC0141681 FE Chip 20UPGPQ2211330 PCB 20UPGFC0141619 FE Chip 20UPGFC0141716 FE Chip 20UPGFC0141747 FE Chip
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal True
Alternative ID ANL_ITkPix_104
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Failed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date 3 months ago
component ObjectId 68659ea6207cb9964861d639
Stage MODULE/POST_PARYLENE_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 68d11799e22c0012ee3ee041
ObjectId of RAW record 68d11795e22c0012ee3ee03a
Tags ganymede_4

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.6.0
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPGM24211330
IV_ARRAY {'time': [4.164315700531006, 12.629957914352417, 19.99616312980652, 31.377251863479614, 38.17061734199524, 45.511173248291016, 52.890158891677856, 60.28914499282837, 67.53523182868958, 74.89679288864136, 82.13068389892578, 89.455801486969, 96.74226689338684, 104.06541132926941, 111.30016732215881, 118.7671480178833, 125.97479796409607, 133.3166582584381, 140.57125806808472, 147.82216095924377, 155.08116364479065, 162.33215618133545, 169.56924033164978, 176.8601884841919, 184.23198795318604, 191.4689085483551, 198.79924988746643, 205.45754551887512, 212.72915863990784, 219.89532732963562, 227.1341691017151, 234.27717328071594, 241.503276348114, 248.70533061027527, 255.9010238647461, 263.2393465042114, 267.98767352104187, 275.0832042694092, 282.2317032814026, 289.46187591552734, 296.594131231308], 'voltage': [0.004, 5.014, 9.97, 14.944, 20.036, 24.982, 29.986, 34.986, 39.986, 44.988, 49.986, 54.982, 59.988, 64.984, 69.986, 74.986, 79.984, 84.986, 89.986, 94.978, 99.986, 104.984, 109.988, 114.988, 119.994, 124.994, 130.002, 134.998, 140.006, 144.996, 150.0, 155.002, 160.006, 165.004, 170.006, 175.008, 180.014, 185.012, 190.012, 195.012, 200.008], 'current': [0.03816666666666667, 0.13, 0.1565, 0.1675, 0.17450000000000002, 0.185, 0.1905, 0.196, 0.21000000000000002, 0.213, 0.2215, 0.224, 0.23050000000000004, 0.2245, 0.2225, 0.22200000000000003, 0.2245, 0.22049999999999997, 0.21600000000000003, 0.2225, 0.225, 0.223, 0.2265, 0.2235, 0.223, 0.2285, 0.227, 0.237, 0.245, 0.23850000000000005, 0.24600000000000002, 0.2485, 0.2485, 0.24200000000000002, 0.25050000000000006, 0.2595, 0.28, 0.28500000000000003, 0.27949999999999997, 0.2915, 0.29250000000000004], 'sigma current': [0.0004714045207910329, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0042426406871192805, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 2.6469779601696886e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], 'temperature': [18.5333, 18.456, 18.3918, 18.4506, 18.5733, 18.5467, 18.7196, 18.6398, 18.8071, 18.7328, 18.8785, 18.8124, 18.9446, 18.897, 18.971, 19.1265, 19.0211, 19.1449, 19.0475, 19.1423, 19.2421, 19.1528, 19.284, 19.1948, 19.2788, 19.3861, 19.263, 19.3547, 19.4776, 19.3521, 19.4358, 19.5349, 19.4096, 19.4854, 19.5532, 19.4514, 19.5219, 19.6287, 19.4932, 19.5636, 19.6703], 'humidity': []}
BREAKDOWN_VOLTAGE -999
BREAKDOWN_REDUCTION 0
NO_BREAKDOWN_VOLTAGE_OBSERVED True
MAXIMUM_VOLTAGE 200.008
LEAK_CURRENT 0.24038260691760388
LEAK_INCREASE_FACTOR 797735.26
LEAK_PER_AREA 0.02
ANALYSIS_VERSION mqat v2.6.4
TEMP 19.11
HUM 0
MEASUREMENT_DATE 2025-09-22T09:26:09.000+00:00
MEASUREMENT_DURATION 354
