20UPGM23211302 (ANL_ITkPix_107)

MODULE/POST_PARYLENE_WARM

View QC Summary

Component Information

Serial Number 20UPGM23211302
ProdDB ID  539a4e…3d1631
LocalDB ID 685082b69092149c9f9dee2f
Component Type MODULE
Parents No match.
Children 20UPGB43200210 Bare Module 20UPGFC0141682 FE Chip 20UPGPQ2211302 PCB 20UPGFC0141683 FE Chip 20UPGFC0141764 FE Chip 20UPGFC0141652 FE Chip
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal True
Alternative ID ANL_ITkPix_107
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Failed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date 4 months ago
component ObjectId 685082b69092149c9f9dee2f
Stage MODULE/POST_PARYLENE_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 68a4de95939a6ce3378e44d6
ObjectId of RAW record 68a4de93939a6ce3378e44cf
Tags ganymede_4

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.6.0
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPGM23211302
IV_ARRAY {'time': [3.1145403385162354, 11.34815502166748, 20.82406997680664, 28.838134050369263, 36.21754813194275, 44.15545701980591, 52.057902097702026, 60.12607932090759, 68.02505254745483, 75.93228507041931, 83.91359615325928, 91.75809717178345, 99.63935256004333, 107.49507999420166, 115.42454195022583, 123.4750862121582, 131.2660629749298, 139.045081615448, 146.95245385169983, 154.72109365463257, 162.54290437698364, 170.34111881256104, 178.10607767105103, 186.011376619339, 193.82112622261047, 201.65569615364075, 209.41431307792664, 217.1761999130249, 224.91130089759827, 232.6364884376526, 240.27052927017212, 248.2090287208557, 255.918274641037, 303.9970178604126, 311.1663484573364, 318.25149297714233, 325.4000782966614, 332.4630751609802, 339.63807487487793, 346.7751045227051, 353.9283781051636], 'voltage': [0.036, 4.924, 10.054, 15.14, 19.91, 25.008, 29.996, 34.994, 39.986, 44.986, 49.984, 54.982, 59.982, 64.986, 69.986, 74.986, 79.99, 84.986, 89.994, 94.992, 100.002, 105.004, 110.01, 115.008, 120.018, 125.022, 130.026, 135.026, 140.026, 145.028, 150.024, 155.024, 160.016, 165.024, 170.026, 175.03, 180.026, 185.028, 190.022, 195.02, 200.01], 'current': [0.04000000000000001, 0.1055, 0.11750000000000001, 0.13549999999999998, 0.1315, 0.1525, 0.1565, 0.1515, 0.1585, 0.155, 0.17650000000000002, 0.18050000000000002, 0.1635, 0.17450000000000002, 0.19500000000000003, 0.168, 0.1915, 0.19650000000000004, 0.16999999999999998, 0.20900000000000002, 0.18, 0.18250000000000002, 0.2085, 0.17633333333333334, 0.2155, 0.1975, 0.17400000000000004, 0.21250000000000002, 0.218, 0.19650000000000004, 0.17950000000000002, 0.18800000000000003, 0.20883333333333334, 0.2, 0.186, 0.1855, 0.21400000000000002, 0.23550000000000001, 0.238, 0.24250000000000002, 0.24], 'sigma current': [6.6174449004242214e-18, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 0.0025927248643506694, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 2.6469779601696886e-17, 0.00023570226039552108, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], 'temperature': [17.5903, 17.3334, 17.5821, 17.6474, 17.851, 17.897, 17.9024, 17.9808, 18.1317, 18.1236, 18.223, 18.3035, 18.3999, 18.2257, 18.4106, 18.5866, 18.568, 18.701, 18.685, 18.8203, 18.7726, 18.9473, 18.7169, 18.7779, 18.9605, 19.1107, 19.0264, 19.1712, 19.0712, 19.2001, 19.158, 19.2342, 19.3076, 19.4541, 19.339, 19.4358, 19.5506, 19.441, 19.5141, 19.6027, 19.4776], 'humidity': []}
BREAKDOWN_VOLTAGE 95.0
BREAKDOWN_REDUCTION -1094.0
NO_BREAKDOWN_VOLTAGE_OBSERVED False
MAXIMUM_VOLTAGE 200.01
LEAK_CURRENT 0
LEAK_INCREASE_FACTOR 0.0
LEAK_PER_AREA 0.0
ANALYSIS_VERSION mqat v2.6.4
TEMP 18.69
HUM 0
MEASUREMENT_DATE 2025-08-19T20:22:09.000+00:00
MEASUREMENT_DURATION 417
