20UPGM23211141 (ANL_ITkPix_100)

MODULE/POST_PARYLENE_WARM

View QC Summary

Component Information

Serial Number 20UPGM23211141
ProdDB ID  8e8a13…247162
LocalDB ID 6850820b9092149c9f9deb77
Component Type MODULE
Parents No match.
Children 20UPGB43200202 Bare Module 20UPGFC0142426 FE Chip 20UPGFC0142553 FE Chip 20UPGFC0142445 FE Chip 20UPGFC0142412 FE Chip 20UPGPQ2211141 PCB
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal True
Is preproduction module True
Alternative ID ANL_ITkPix_100
Wirebond protection roof presence None
Rank None

 Comments


Test: IV_MEASURE QC Failed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date 5 days ago
component ObjectId 6850820b9092149c9f9deb77
Stage MODULE/POST_PARYLENE_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 693a06c831b71a9bc19a8a44
ObjectId of RAW record 693a06c531b71a9bc19a8a3d
Tags ganymede_4

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.7.2.dev0
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPGM23211141
IV_ARRAY {'time': [3.0593464374542236, 9.800053358078003, 16.514370679855347, 23.312392711639404, 30.035040616989136, 36.74534821510315, 43.439396381378174, 50.180421113967896, 56.965373039245605, 63.82941770553589, 70.54373598098755, 101.4273591041565], 'voltage': [0.0, 5.142, 10.002, 15.362, 20.076, 25.006, 30.0, 35.002, 40.002, 45.002, 50.004, 54.918], 'current': [0.0345, 2.0315, 3.54, 5.609500000000001, 9.2325, 15.356, 23.5255, 34.962, 49.303000000000004, 65.0525, 85.947, 98.5125], 'sigma current': [0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], 'temperature': [17.0171, 17.0447, 17.2704, 17.4265, 17.4921, 17.5685, 17.4566, 17.6801, 17.8862, 17.8699, 18.0401, 18.2257], 'humidity': []}
BREAKDOWN_VOLTAGE 30.0
BREAKDOWN_REDUCTION -1029.0
NO_BREAKDOWN_VOLTAGE_OBSERVED False
MAXIMUM_VOLTAGE 54.918
LEAK_CURRENT -999
LEAK_INCREASE_FACTOR -999
LEAK_PER_AREA -999
ANALYSIS_VERSION mqat v2.7.0
TEMP 17.58
HUM 0
MEASUREMENT_DATE 2025-12-10T23:45:23.000+00:00
MEASUREMENT_DURATION 174
