20UPGM23211141 (ANL_ITkPix_100)

MODULE/POST_PARYLENE_WARM

View QC Summary

Component Information

Serial Number 20UPGM23211141
ProdDB ID  8e8a13…247162
LocalDB ID 6850820b9092149c9f9deb77
Component Type MODULE
Parents No match.
Children 20UPGB43200202 Bare Module 20UPGFC0142426 FE Chip 20UPGFC0142553 FE Chip 20UPGFC0142445 FE Chip 20UPGFC0142412 FE Chip 20UPGPQ2211141 PCB
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal True
Is preproduction module True
Alternative ID ANL_ITkPix_100
Wirebond protection roof presence None
Rank None

 Comments


Test: IV_MEASURE QC Failed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date a month ago
component ObjectId 6850820b9092149c9f9deb77
Stage MODULE/POST_PARYLENE_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 690144d7fb15341973b89f4e
ObjectId of RAW record 690144d3fb15341973b89f47
Tags ganymede_4

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.7.0rc1.dev3
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPGM23211141
IV_ARRAY {'time': [3.0961503982543945, 11.765012979507446, 18.385894298553467, 24.971145391464233, 31.576988697052002, 38.19621157646179, 44.80615544319153, 51.40991163253784, 58.1114387512207, 64.6621720790863, 71.23894262313843, 77.83832025527954, 84.45750164985657, 91.05314707756042, 97.66619992256165, 104.2717764377594, 110.88517189025879, 117.52680015563965, 124.13431787490845, 130.81126832962036, 137.3832368850708, 143.97005081176758, 150.55014824867249, 157.17293787002563, 163.73864459991455, 170.3022220134735], 'voltage': [0.002, 5.054, 9.998, 15.292, 19.904, 24.998, 29.99, 34.994, 39.98, 44.992, 49.98, 54.994, 59.988, 64.992, 69.99, 74.992, 79.99, 84.986, 89.986, 94.99, 99.992, 104.984, 109.988, 114.98, 119.994, 124.986], 'current': [0.037000000000000005, 1.5915, 2.7705, 3.878, 5.077500000000001, 6.6625000000000005, 8.277166666666668, 9.5585, 11.691, 13.481000000000002, 16.363, 18.8745, 22.549000000000003, 25.794, 30.687500000000004, 34.315, 39.897000000000006, 43.915000000000006, 49.238499999999995, 55.194, 60.490500000000004, 68.5575, 73.608, 81.80050000000001, 88.044, 94.00200000000001], 'sigma current': [0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.04360491817317102, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.24960869375885236, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], 'temperature': [16.6734, 16.7402, 17.0171, 17.2676, 17.5439, 17.5303, 17.5657, 17.6964, 17.7208, 17.8699, 17.8456, 17.9916, 17.9646, 18.1344, 18.1424, 18.2391, 18.2123, 18.3035, 18.4266, 18.3972, 18.56, 18.496, 18.6186, 18.6425, 18.6638, 18.7965], 'humidity': []}
BREAKDOWN_VOLTAGE 60.0
BREAKDOWN_REDUCTION -1059.0
NO_BREAKDOWN_VOLTAGE_OBSERVED False
MAXIMUM_VOLTAGE 124.986
LEAK_CURRENT 82.58179371234964
LEAK_INCREASE_FACTOR 301172979.45
LEAK_PER_AREA 5.187
ANALYSIS_VERSION mqat v2.7.0rc3
TEMP 17.96
HUM 0
MEASUREMENT_DATE 2025-10-28T22:30:17.000+00:00
MEASUREMENT_DURATION 215
