20UPGM23210791 (ANL_ITkPix_95)

MODULE/FINAL_METROLOGY

View QC Summary

Component Information

Serial Number 20UPGM23210791
ProdDB ID  32dad6…065c70
LocalDB ID 68507fd8e85f5d0f12b3413c
Component Type MODULE
Parents No match.
Children 20UPGB43200170 Bare Module 20UPGFC0142123 FE Chip 20UPGFC0142156 FE Chip 20UPGFC0142120 FE Chip 20UPGFC0142214 FE Chip 20UPGPQ2210791 PCB
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal True
Is preproduction module True
Alternative ID ANL_ITkPix_95
Wirebond protection roof presence None
Rank None

 Comments


Test: IV_MEASURE QC Failed

(Stage: MODULE/INITIAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date 3 months ago
component ObjectId 68507fd8e85f5d0f12b3413c
Stage MODULE/INITIAL_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name DanielAceves
ObjectId of this record 68c209fb8428c598c033bff4
ObjectId of RAW record 68c209fa8428c598c033bfed
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.6.4
HUM 0
MEASUREMENT_DATE 2025-09-10T20:48:46.000+00:00
MEASUREMENT_DURATION 1044
TEMP 18.93
BREAKDOWN_REDUCTION 0
BREAKDOWN_VOLTAGE -999
IV_ARRAY {'time': [18.190385341644287, 48.36919069290161, 73.37285709381104, 98.47411847114563, 123.64878106117249, 148.75021362304688, 173.84122681617737, 199.1494529247284, 224.204345703125, 249.37973165512085, 274.4011170864105, 299.53639960289, 323.28960132598877, 348.838582277298, 373.9555993080139, 399.0010871887207, 424.06077671051025, 449.3068630695343, 474.3151288032532, 499.4328143596649, 524.6063120365143, 549.6558780670166, 574.6726422309875, 598.5408470630646, 624.016116142273, 649.1551034450531, 674.1942002773285, 700.2394213676453, 726.3138225078583, 751.3917047977448, 776.4956409931183, 801.591032743454, 826.7134900093079, 851.8702623844147, 876.8640716075897, 902.0060968399048, 927.1369733810425, 952.2187206745148, 977.3762135505676, 1002.4582378864288, 1027.6255321502686], 'voltage': [0.07, 5.14, 10.01, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 65, 70, 75, 80, 85, 90, 95, 100, 105, 110, 115, 120, 125, 130, 135, 140, 145, 150, 155, 160, 165, 170, 175, 180, 185, 190, 195, 200], 'current': [0.024, 0.207, 0.2576666666666667, 0.272, 0.316, 0.321, 0.317, 0.35, 0.323, 0.36433333333333334, 0.35433333333333333, 0.352, 0.35466666666666663, 0.3646666666666667, 0.384, 0.4033333333333334, 0.36666666666666664, 0.4056666666666667, 0.3753333333333333, 0.388, 0.3936666666666666, 0.42833333333333334, 0.391, 0.4206666666666667, 0.4343333333333334, 0.41233333333333333, 0.4343333333333333, 0.41466666666666663, 0.413, 0.41466666666666663, 0.42633333333333334, 0.42633333333333334, 0.42, 0.4476666666666667, 0.44633333333333336, 0.45533333333333337, 0.448, 0.43366666666666664, 0.4633333333333334, 0.4343333333333334, 0.45666666666666667], 'sigma current': [0, 0.004242640687119267, 0.010842303978193746, 0, 0.008485281374238585, 0.016970562748477143, 0, 0.002828427124746203, 0.002828427124746203, 0.0032998316455372205, 0.016499158227686102, 0.011313708498984764, 0.009428090415820644, 0.01932758535243233, 0.01555634918610404, 0.0018856180831641185, 0.0018856180831641185, 0.008956685895029601, 0.00047140452079101717, 0.007071067811865483, 0.015084944665312999, 0.003771236166328263, 0.002828427124746178, 0.0009428090415820593, 0.002357022603955161, 0.014613540144521956, 0.0018856180831641185, 0.016499158227686102, 0.011313708498984764, 0.012256517540566796, 0.017441967269268187, 0.018856180831641287, 0.0014142135623731015, 0.01602775370689511, 0.017913371790059227, 0.0018856180831641185, 0.015556349186104067, 0.004714045207910322, 0.001885618083164144, 0.00047140452079101717, 0.007542472332656499], 'temperature': [19.32, 19.22, 19.22, 19.19, 19.16, 19.13, 19.1, 19.04, 19.04, 19.01, 18.98, 18.98, 18.89, 18.92, 18.86, 18.82, 18.86, 18.82, 18.82, 18.86, 18.86, 18.86, 18.86, 18.82, 18.82, 18.82, 18.82, 18.79, 18.82, 18.86, 18.86, 18.86, 18.86, 18.86, 18.89, 18.92, 18.92, 18.86, 18.86, 18.86, 18.82], 'humidity': []}
LEAK_CURRENT 0.46407026728794215
LEAK_INCREASE_FACTOR 1216149.28
LEAK_PER_AREA 0.03
MAXIMUM_VOLTAGE 200
NO_BREAKDOWN_VOLTAGE_OBSERVED True
