20UPGM23210545 (ANL_ITkPix_90)

MODULE/FINAL_METROLOGY

View QC Summary

Component Information

Serial Number 20UPGM23210545
ProdDB ID  5ab7d0…20c931
LocalDB ID 68507ed36734e5702671eb39
Component Type MODULE
Parents No match.
Children 20UPGB43200165 Bare Module 20UPGFC0142186 FE Chip 20UPGFC0142219 FE Chip 20UPGFC0142265 FE Chip 20UPGFC0142268 FE Chip 20UPGPQ2210545 PCB
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal True
Alternative ID ANL_ITkPix_90
Is preproduction module True
Wirebond protection roof presence None
Rank None

 Comments


Test: IV_MEASURE QC Failed

(Stage: MODULE/FINAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date 2 months ago
component ObjectId 68507ed36734e5702671eb39
Stage MODULE/FINAL_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name SamuelRoberts
ObjectId of this record 68cc4f2b4620977c2530f0cd
ObjectId of RAW record 68cc4f2a4620977c2530f0c6
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.6.4
HUM 0
MEASUREMENT_DATE 2025-09-18T18:06:07.000+00:00
MEASUREMENT_DURATION 1109
TEMP 24.97
BREAKDOWN_REDUCTION -1069
BREAKDOWN_VOLTAGE 70
IV_ARRAY {'time': [12.073177576065063, 38.020973920822144, 62.6293671131134, 92.22266721725464, 116.80339169502258, 141.40233826637268, 166.01125478744507, 190.67329001426697, 215.30605030059814, 239.94824934005737, 264.53993034362793, 289.10653614997864, 313.72103786468506, 338.3171555995941, 362.91381311416626, 387.4899709224701, 412.09548926353455, 436.7068393230438, 461.3037168979645, 485.9481244087219, 510.5704483985901, 535.2131867408752, 559.8424847126007, 584.438136100769, 609.0459108352661, 633.6373906135559, 658.2280232906342, 682.8301413059235, 707.5109083652496, 732.115362405777, 756.7554023265839, 781.3082995414734, 805.8871984481812, 830.4945194721222, 855.1544642448425, 879.7803194522858, 904.4109432697296, 929.0095541477203, 953.6350636482239, 978.2664322853088, 1002.8797221183777], 'voltage': [0.042, 5.07, 10.032, 15.06, 19.982, 24.988, 30.004, 34.998, 40.002, 45.006, 50.004, 55.004, 60.01, 65.002, 70.006, 74.998, 80.006, 84.998, 90.002, 95, 100.004, 105.002, 110.012, 115.014, 120.012, 125.016, 130.014, 135.014, 140.014, 145.012, 150.016, 155.018, 160.016, 165.014, 170.012, 175.01, 180.008, 185.008, 190.01, 195.002, 200], 'current': [0.026000000000000006, 0.23683333333333334, 0.18733333333333332, 0.0115, 0.06933333333333333, 0.0026666666666666687, 0.035833333333333335, 0.008166666666666666, 0.04833333333333333, 0.07583333333333334, 0.12116666666666667, 0.14133333333333334, 0.16533333333333333, 0.14583333333333334, 0.26816666666666666, 0.31383333333333335, 0.4168333333333334, 0.425, 0.4545, 0.4858333333333334, 0.5698333333333334, 0.6193333333333334, 0.6175, 0.6845, 0.6880000000000001, 0.7205, 0.7383333333333333, 0.7703333333333334, 0.7945000000000001, 0.8408333333333334, 0.8728333333333333, 0.8493333333333334, 0.8796666666666667, 0.8875000000000001, 0.8631666666666666, 0.9361666666666667, 0.8715, 0.911, 0.9266666666666666, 0.9503333333333335, 0.9931666666666668], 'sigma current': [3.3087224502121107e-18, 0.13639485164607773, 0.14545579702744366, 0.00248327740429189, 0.0040892813821284315, 0.053182599493526904, 0.06093758190877688, 0.0027182510717166817, 0.08181313396325121, 0.0779244648504064, 0.10912556478153454, 0.08911073011833212, 0.1158535953501468, 0.0715312674445394, 0.06919336833990829, 0.09986018002965724, 0.054901932773102104, 0.03442624967472736, 0.05861313845888137, 0.06436527704351849, 0.0020548046676563485, 0.055403569880970296, 0.06895771651285057, 0.0556162446293047, 0.04951262465270856, 0.055867402540897414, 0.002624669291337239, 0.002656229575084854, 0.0008164965809277442, 0.0034237730973623367, 0.0027182510717166696, 0.0014337208778404144, 0.05925416066029084, 0.0021602468994693183, 0.003965125751123474, 0.003922867431979971, 0.0038944404818492743, 0.0014142135623731015, 0.0016499158227686029, 0.06033287292642011, 0.003274480450731408], 'temperature': [24.95489501953125, 24.951141357421875, 24.953155517578125, 24.95196533203125, 24.951934814453125, 24.952423095703125, 24.952850341796875, 24.95361328125, 24.953277587890625, 24.951019287109375, 24.952667236328125, 24.953399658203125, 24.95465087890625, 24.956939697265625, 24.9569091796875, 24.959686279296875, 24.96099853515625, 24.963104248046875, 24.964111328125, 24.969879150390625, 24.96978759765625, 24.967071533203125, 24.96923828125, 24.972686767578125, 24.9744873046875, 24.9727783203125, 24.975860595703125, 24.97540283203125, 24.97467041015625, 24.977294921875, 24.97979736328125, 24.97991943359375, 24.980621337890625, 24.979400634765625, 24.9814453125, 24.9833984375, 24.984619140625, 24.98358154296875, 24.9833984375, 24.985565185546875, 24.985809326171875], 'humidity': []}
LEAK_CURRENT 0
LEAK_INCREASE_FACTOR 0
LEAK_PER_AREA 0
MAXIMUM_VOLTAGE 200
NO_BREAKDOWN_VOLTAGE_OBSERVED False
