20UPGM23211410 (Si030)

MODULE/PARYLENE_COATING

View QC Summary

Component Information

Serial Number 20UPGM23211410
ProdDB ID  7cdbe0…ca1002
LocalDB ID 6824678b9f4d7e6edeb37146
Component Type MODULE
Parents No match.
Children 20UPGB43200264 Bare Module 20UPGPQ4211410 PCB 20UPGFC0147514 FE Chip 20UPGFC0147643 FE Chip 20UPGFC0147828 FE Chip 20UPGFC0147810 FE Chip
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal True
Alternative ID Si030
Wirebond protection roof presence None
Rank None
Is preproduction module None

 Comments


Test: IV_MEASURE QC Passed

(Stage: MODULE/INITIAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 5 months ago
component ObjectId 6824678b9f4d7e6edeb37146
Stage MODULE/INITIAL_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name LeonieKrippendorf
ObjectId of this record 686f86f68226200df76d5e91
ObjectId of RAW record 686f86f28226200df76d5e8a
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.6.2
HUM 0
MEASUREMENT_DATE 2025-07-08T14:26:40.000+00:00
MEASUREMENT_DURATION 972
TEMP 14.54
BREAKDOWN_REDUCTION 0
BREAKDOWN_VOLTAGE -999
IV_ARRAY {'time': [4.934700965881348, 26.559580326080322, 46.934213638305664, 70.94211387634277, 91.94324922561646, 112.9501097202301, 133.97357940673828, 154.9541630744934, 175.96034812927246, 196.95426869392395, 217.9564950466156, 238.98772406578064, 259.9594581127167, 283.959424495697, 304.96484208106995, 325.9674127101898, 346.9710862636566, 364.97286796569824, 385.9688243865967, 406.97140622138977, 427.97651267051697, 448.98387837409973, 466.98378133773804, 490.98223781585693, 511.9852683544159, 532.9851427078247, 554.0010809898376, 574.9881224632263, 595.9899392127991, 616.9913218021393, 637.9965846538544, 658.9974474906921, 680.0251166820526, 704.0286483764648, 725.0288999080658, 746.0100061893463, 767.0297009944916, 788.0429155826569, 809.0330231189728, 830.0257453918457, 851.0426313877106], 'voltage': [0.00465852, 4.99685, 9.995557, 14.99729, 19.99929, 24.99796, 29.99925, 34.99771, 39.99883, 44.99672, 49.99878, 54.99667, 59.99832, 65.00047, 69.99838, 74.99996, 79.99749, 84.99908, 89.99734, 94.99826, 99.99599, 104.9983, 109.999, 114.9978, 119.9992, 124.9968, 129.9977, 134.9958, 139.9975, 144.9963, 149.9974, 154.9995, 159.9977, 164.998, 169.996, 174.9974, 179.9951, 184.9975, 189.995, 194.9967, 199.9982], 'current': [9.0274226e-05, 0.14863916666666668, 0.17023586666666668, 0.18436766666666665, 0.1951687666666667, 0.2042788, 0.21289396666666668, 0.22211123333333332, 0.2296161, 0.23831273333333333, 0.24693496666666667, 0.2556452, 0.26436460000000006, 0.27538736666666674, 0.28738276666666673, 0.30045360000000004, 0.31373789999999996, 0.32830553333333334, 0.34268060000000006, 0.35805810000000005, 0.3745720333333334, 0.39047396666666667, 0.4084175333333333, 0.42559536666666675, 0.44481830000000006, 0.4642591, 0.48478839999999995, 0.5060599333333333, 0.5280677666666668, 0.5513530333333333, 0.5746877666666667, 0.5970499333333333, 0.6224072333333334, 0.6480410333333334, 0.6745305666666667, 0.7018348333333335, 0.7309456999999999, 0.7618968666666667, 0.7945974333333333, 0.8262163666666668, 0.8612939666666667], 'sigma current': [7.456039099727482e-05, 0.0003792550710127546, 0.0003024441582984938, 0.0002650786843352179, 0.00027494011873294534, 0.0002546084444789651, 0.00031584762500646386, 0.00010058509940454449, 0.00011430943384806988, 6.340474920873179e-05, 5.1853725892043095e-05, 0.00021651138538191436, 0.00013950529261166602, 2.9634364436509393e-05, 2.8026931492576292e-05, 3.905415044097204e-05, 0.00017512060605954518, 0.0002004905040699565, 7.04714126437078e-05, 5.426865270730211e-05, 0.00011359848394918265, 5.6402147319263e-05, 0.00012458813034242692, 0.0002804874368349121, 0.00023926196243169976, 0.00028192844245776794, 0.00026215836180957836, 0.0005328991295003589, 8.038989709879668e-05, 0.0003088971169966949, 0.00021421650003884506, 0.00020273768492534044, 0.00024725892411714206, 7.965744716525455e-05, 0.0003019676840693742, 0.00010651977385550874, 0.0005844634975770494, 0.0006504992971214979, 0.00010739287168564159, 0.0010759079462895052, 0.0007645043376084974], 'temperature': [14.809, 14.705, 14.659, 14.611, 14.543, 14.486, 14.457, 14.466, 14.473, 14.491, 14.498, 14.504, 14.506, 14.511, 14.519, 14.523, 14.524, 14.523, 14.524, 14.525, 14.527, 14.53, 14.532, 14.532, 14.535, 14.54, 14.54, 14.54, 14.54, 14.543, 14.543, 14.545, 14.55, 14.552, 14.546, 14.545, 14.548, 14.549, 14.551, 14.549, 14.548], 'humidity': []}
LEAK_CURRENT 0.6481997811671488
LEAK_INCREASE_FACTOR 0.76
LEAK_PER_AREA 0.04
MAXIMUM_VOLTAGE 199.9982
NO_BREAKDOWN_VOLTAGE_OBSERVED True
