20UPIM13710365 (ANL_ITkPix_76)

MODULE/FINAL_COLD

View QC Summary

Component Information

Serial Number 20UPIM13710365
ProdDB ID  7b574a…f50428
LocalDB ID 681b94de5e18790b00d24d00
Component Type MODULE
Parents No match.
Children 20UPGB43000044 Bare Module 20UPGPQ3710365 PCB 20UPGFC0156329 FE Chip 20UPGFC0156330 FE Chip 20UPGFC0156332 FE Chip 20UPGFC0156331 FE Chip
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal True
Alternative ID ANL_ITkPix_76
Is preproduction module True
Wirebond protection roof presence None
Rank None

 Comments


Test: IV_MEASURE QC Failed

(Stage: MODULE/THERMAL_CYCLES)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date 3 months ago
component ObjectId 681b94de5e18790b00d24d00
Stage MODULE/THERMAL_CYCLES
Test Type IV_MEASURE
Institute ObjectId
User Name Simpson,Liana Rae
ObjectId of this record 68811e3d78676c4714513b34
ObjectId of RAW record 68811e3178676c4714513b2d
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.6.2
HUM 0
MEASUREMENT_DATE 2025-07-23T17:33:33.000+00:00
MEASUREMENT_DURATION 323
TEMP 18.58
BREAKDOWN_REDUCTION -5.3
BREAKDOWN_VOLTAGE 20
IV_ARRAY {'time': [3.130833864212036, 9.99898386001587, 16.766039609909058, 23.47881269454956, 30.2546226978302, 36.939476013183594, 43.69848012924194, 50.434372901916504, 57.199933767318726, 64.12110042572021, 70.90693640708923, 77.65546298027039, 84.41848134994507, 91.14947867393494, 97.83248090744019, 104.55312776565552, 111.27940249443054, 118.02574872970581, 124.87947463989258, 131.64455938339233, 138.33928990364075, 145.04765939712524, 151.78548049926758, 158.52671241760254, 165.25363111495972, 171.981929063797, 178.67649292945862, 185.5414218902588, 192.3434534072876, 199.01838278770447, 205.6885576248169, 212.34649324417114, 219.0078489780426, 225.6974802017212, 232.26847314834595, 238.93784475326538, 243.73878502845764, 250.42348861694336, 257.1356108188629, 263.8412983417511, 270.5200002193451], 'voltage': [0, 5.046, 10.054, 14.946, 19.996, 24.996, 29.98, 34.974, 39.972, 44.972, 49.97, 54.966, 59.966, 64.97, 69.97, 74.968, 79.974, 84.968, 89.98, 94.978, 99.988, 104.994, 109.996, 114.996, 120.004, 125.01, 130.012, 135.014, 140.016, 145.018, 150.014, 155.014, 160.004, 165.008, 170.012, 175.018, 180.016, 185.016, 190.012, 195.014, 200.002], 'current': [0.0315, 0.0225, 0.007, 0.0075, 0.015, 0.0225, 0.037000000000000005, 0.049499999999999995, 0.0465, 0.052500000000000005, 0.054000000000000006, 0.051000000000000004, 0.05900000000000001, 0.05900000000000001, 0.062, 0.0685, 0.069, 0.06949999999999999, 0.065, 0.15050000000000002, 0.2435, 0.35300000000000004, 0.4345, 0.33649999999999997, 0.314, 0.293, 0.2685, 0.234, 0.2595, 0.264, 0.30250000000000005, 0.23850000000000005, 0.274, 0.3295, 0.413, 0.4375, 0.6475000000000001, 0.671, 0.7305, 0.8205, 0.9375000000000001], 'sigma current': [0, 0, 0, 0, 0, 0, 0, 6.6174449004242214e-18, 0, 0, 0, 0, 6.6174449004242214e-18, 6.6174449004242214e-18, 0, 0, 0, 0, 0, 0, 0, 0, 0, 5.293955920339377e-17, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 5.293955920339377e-17, 0, 0, 0, 0, 0, 0], 'temperature': [18.9605, 18.3303, 17.9862, 17.7588, 17.6148, 17.7887, 17.9267, 17.786, 17.9213, 18.0185, 18.0131, 18.2874, 18.1397, 18.1881, 18.3196, 18.44, 18.4693, 18.4239, 18.56, 18.4506, 18.6611, 18.6265, 18.762, 18.5893, 18.8018, 18.7196, 18.8918, 18.8944, 18.942, 19.0159, 18.9684, 19.0791, 18.9974, 19.1685, 19.0422, 19.1948, 19.0633, 19.2368, 19.1238, 19.2499, 19.1659], 'humidity': []}
LEAK_CURRENT 0
LEAK_INCREASE_FACTOR 0
LEAK_PER_AREA 0
MAXIMUM_VOLTAGE 200.002
NO_BREAKDOWN_VOLTAGE_OBSERVED False
