20UPGFC0223316

MODULE/POST_PARYLENE_WARM

Component Information

Serial Number	20UPGFC0223316
ProdDB ID	3d9ed2…e74950
LocalDB ID	67a21f5989d864a1f4115bed
Component Type	fe_chip
Parents	20UPGM24220303 20UPGB43000389
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	10
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/INITIAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	67a21f5989d864a1f4115bed
Stage	MODULE/INITIAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	Simpson,Liana Rae
ObjectId of this record	69dff882d697fe9f34e8f396
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.8.1
YARR_VERSION	v1.5.6
MEASUREMENT_DATE	2026-04-15T19:11:33.000+00:00
MEASUREMENT_DURATION	1582
TUNING_UNTUNED_THRESHOLD_MEAN	2078.24
TUNING_UNTUNED_THRESHOLD_95_LOW	1505.423
TUNING_UNTUNED_THRESHOLD_95_HIGH	2697.758
TUNING_UNTUNED_THRESHOLD_SIGMA	305.006
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_NOISE_MEAN	105.465
TUNING_UNTUNED_NOISE_SIGMA	10.805
TUNING_UNTUNED_NOISE_95_LOW	86.392
TUNING_UNTUNED_NOISE_95_HIGH	125.781
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	550
TUNING_TUNED_THRESHOLD_MEAN	1506.3
TUNING_TUNED_THRESHOLD_95_LOW	1437.783
TUNING_TUNED_THRESHOLD_95_HIGH	1567.427
TUNING_TUNED_THRESHOLD_SIGMA	35
TUNING_TUNED_TDAC_MEAN	-1.3
TUNING_TUNED_TDAC_SIGMA	4.215
TUNING_TUNED_NOISE_MEAN	108.777
TUNING_TUNED_NOISE_SIGMA	12.333
TUNING_TUNED_NOISE_95_LOW	87.913
TUNING_TUNED_NOISE_95_HIGH	136.46
TUNING_TUNED_TOT_MEAN	7.5
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_TUNED_TOT_95_LOW	5.4
TUNING_TUNED_TOT_95_HIGH	10.19
TUNING_TUNED_THRESHOLD_FAILED_FITS	148802
TUNING_ANY_ERRORS	{'tune_globalthreshold': 0, 'thresholdscan_hr': 0, 'tune_pixelthreshold': 0, 'thresholdscan_hd': 0, 'totscan': 0, 'all': 0}

Attachments

Filename	Contents
0x36854_L2_warm.json	Download
output.log	Download
0x36854.log	Download
20UPGFC0223316_MODULE__INITIAL_WARM_TUNING.zip	Download
