20UPGFC0223176

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number	20UPGFC0223176
ProdDB ID	59d2d3…a869cb
LocalDB ID	67a21eb3d7e33319cc6ba157
Component Type	fe_chip
Parents	20UPGM24830256 20UPGB43000294
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	10
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	3 months ago
component ObjectId	67a21eb3d7e33319cc6ba157
Stage	MODULE/POST_PARYLENE_WARM
Test Type	TUNING
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	69bc4dcff97f394ea371d485
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.8.1
MEASUREMENT_DATE	2026-03-19T18:49:14.000+00:00
MEASUREMENT_DURATION	679
YARR_VERSION	v1.5.6
TUNING_ANY_ERRORS	{'tune_globalthreshold': 0, 'thresholdscan_hr': 0, 'tune_pixelthreshold': 0, 'thresholdscan_hd': 0, 'totscan': 0, 'all': 0}
TUNING_TUNED_NOISE_95_HIGH	128.076
TUNING_TUNED_NOISE_95_LOW	86.043
TUNING_TUNED_NOISE_MEAN	106.479
TUNING_TUNED_NOISE_SIGMA	11.083
TUNING_TUNED_TDAC_MEAN	-1.1
TUNING_TUNED_TDAC_SIGMA	4.029
TUNING_TUNED_THRESHOLD_95_HIGH	1566.293
TUNING_TUNED_THRESHOLD_95_LOW	1434.295
TUNING_TUNED_THRESHOLD_FAILED_FITS	4
TUNING_TUNED_THRESHOLD_MEAN	1502.6
TUNING_TUNED_THRESHOLD_SIGMA	35
TUNING_TUNED_TOT_95_HIGH	10.06
TUNING_TUNED_TOT_95_LOW	5.41
TUNING_TUNED_TOT_MEAN	7.4
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	125.645
TUNING_UNTUNED_NOISE_95_LOW	85.183
TUNING_UNTUNED_NOISE_MEAN	104.958
TUNING_UNTUNED_NOISE_SIGMA	11.011
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2905.002
TUNING_UNTUNED_THRESHOLD_95_LOW	1696.015
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	62
TUNING_UNTUNED_THRESHOLD_MEAN	2278.785
TUNING_UNTUNED_THRESHOLD_SIGMA	306.816

Attachments

Filename	Contents
0x367c8_L2_warm.json	Download
output.log	Download
0x367c8.log	Download
20UPGFC0223176_MODULE__POST_PARYLENE_WARM_TUNING.zip	Download
