20UPGFC0223175

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number	20UPGFC0223175
ProdDB ID	a30fda…2f3f88
LocalDB ID	67a21eb2d7e33319cc6ba151
Component Type	fe_chip
Parents	20UPGM24830256 20UPGB43000294
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	11
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	3 months ago
component ObjectId	67a21eb2d7e33319cc6ba151
Stage	MODULE/POST_PARYLENE_WARM
Test Type	TUNING
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	69bc4dd1f97f394ea371d4e0
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.8.1
MEASUREMENT_DATE	2026-03-19T18:49:14.000+00:00
MEASUREMENT_DURATION	679
YARR_VERSION	v1.5.6
TUNING_ANY_ERRORS	{'tune_globalthreshold': 0, 'thresholdscan_hr': 0, 'tune_pixelthreshold': 0, 'thresholdscan_hd': 0, 'totscan': 0, 'all': 0}
TUNING_TUNED_NOISE_95_HIGH	124.434
TUNING_TUNED_NOISE_95_LOW	83.996
TUNING_TUNED_NOISE_MEAN	103.69
TUNING_TUNED_NOISE_SIGMA	10.684
TUNING_TUNED_TDAC_MEAN	-1
TUNING_TUNED_TDAC_SIGMA	3.96
TUNING_TUNED_THRESHOLD_95_HIGH	1566.91
TUNING_TUNED_THRESHOLD_95_LOW	1434.683
TUNING_TUNED_THRESHOLD_FAILED_FITS	0
TUNING_TUNED_THRESHOLD_MEAN	1503.1
TUNING_TUNED_THRESHOLD_SIGMA	35
TUNING_TUNED_TOT_95_HIGH	10.05
TUNING_TUNED_TOT_95_LOW	5.24
TUNING_TUNED_TOT_MEAN	7.4
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	122.116
TUNING_UNTUNED_NOISE_95_LOW	83.173
TUNING_UNTUNED_NOISE_MEAN	102.101
TUNING_UNTUNED_NOISE_SIGMA	10.786
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2868.501
TUNING_UNTUNED_THRESHOLD_95_LOW	1667.077
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	99
TUNING_UNTUNED_THRESHOLD_MEAN	2244.033
TUNING_UNTUNED_THRESHOLD_SIGMA	305.246

Attachments

Filename	Contents
0x367c7_L2_warm.json	Download
output.log	Download
0x367c7.log	Download
20UPGFC0223175_MODULE__POST_PARYLENE_WARM_TUNING.zip	Download
