20UPGFC0222763

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number	20UPGFC0222763
ProdDB ID	2c3ab3…ea0942
LocalDB ID	67a21dc989d864a1f41131c0
Component Type	fe_chip
Parents	20UPGM24830013 20UPGB43000292
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	6
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	67a21dc989d864a1f41131c0
Stage	MODULE/POST_PARYLENE_WARM
Test Type	TUNING
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	69bb45d027d3ddc5179dc3bd
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.8.0rc1
MEASUREMENT_DATE	2026-03-19T00:00:40.000+00:00
MEASUREMENT_DURATION	678
YARR_VERSION	v1.5.6
TUNING_TUNED_NOISE_95_HIGH	129.25
TUNING_TUNED_NOISE_95_LOW	86.645
TUNING_TUNED_NOISE_MEAN	107.272
TUNING_TUNED_NOISE_SIGMA	11.35
TUNING_TUNED_TDAC_MEAN	-1.2
TUNING_TUNED_TDAC_SIGMA	4.087
TUNING_TUNED_THRESHOLD_95_HIGH	1564.39
TUNING_TUNED_THRESHOLD_95_LOW	1428.401
TUNING_TUNED_THRESHOLD_FAILED_FITS	17
TUNING_TUNED_THRESHOLD_MEAN	1498.9
TUNING_TUNED_THRESHOLD_SIGMA	36
TUNING_TUNED_TOT_95_HIGH	10.16
TUNING_TUNED_TOT_95_LOW	5.15
TUNING_TUNED_TOT_MEAN	7.4
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	126.36
TUNING_UNTUNED_NOISE_95_LOW	85.424
TUNING_UNTUNED_NOISE_MEAN	105.255
TUNING_UNTUNED_NOISE_SIGMA	11.103
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2841.949
TUNING_UNTUNED_THRESHOLD_95_LOW	1598.97
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	145
TUNING_UNTUNED_THRESHOLD_MEAN	2202.38
TUNING_UNTUNED_THRESHOLD_SIGMA	316.029
