20UPGFC0222756

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number	20UPGFC0222756
ProdDB ID	d1139a…eff226
LocalDB ID	67a21dc789d864a1f4113198
Component Type	fe_chip
Parents	20UPGM24830013 20UPGB43000292
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	10
Target Iref trim version	1
Wafer serial number	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	67a21dc789d864a1f4113198
Stage	MODULE/POST_PARYLENE_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	69bb346827d3ddc5179dbc3a
ObjectId of RAW record	69bb346427d3ddc5179dbc17
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.8.0rc1
MEASUREMENT_DATE	2026-03-18T22:50:14.000+00:00
MEASUREMENT_DURATION	254
MEASUREMENT_VERSION	2.8.0
YARR_VERSION	v1.5.6
AR_IREF_TRIM	10
AR_IREF	3.9e-06
AR_GADC	0.811
AR_NOMINAL_SETTINGS	[3.9e-06, 8.71e-05, 4.86e-05, 4.1e-06, 4.05e-05, 2.02e-05, 0, 3.87e-05, 7.28e-05, -999, 0, 0, 4.75e-05, 6.46e-05, 5.29e-05, 8.76e-05, 7.3e-05, 7.71e-05, 8.27e-05, 8.76e-05, 7.68e-05, 4.91e-05, 4.9e-05, 7.66e-05, 4.79e-05, 4.81e-05, -999, -999, 0.6409677, 0.0677247, 0.9022532, 0.2415839, 0.8109171, -999, -999, 0.818713, 1.2016404, 0.1197669, 0.1302401, 0.1644174, 0.0397202, 0.0435486, 0.1704984, 0.1764795, 0.1788232, 0.638213, -999, 0.6376478, -999, 0.5943431, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0173207, 0.4569134, 1.9519128, 1.5182728, 1.2063262, 0.5982367, 0.9999272, 1.5237204, 1.2111478, 0.6006061]
AR_ROSC_MAX_RESIDUAL	[3.2124313465980987, 5.166419920749339, 3.054200546946007, 4.94719868844805, 2.086688670595994, 3.3637606516726652, 2.096644169700724, 3.448471965042811, 4.640782409903109, 4.5891655007114815, 5.156449366662243, 5.1722867954790726, 4.2981628317644995, 4.390836942636224, 5.012665386578709, 4.977045859835651, 3.401545555153323, 3.3634519552343156, 3.480210120700773, 3.4531400500250604, 2.750796079838468, 2.991690416600329, 3.6681268740056128, 3.656355190250811, 2.399212517202439, 2.3761696759887996, 2.64095296004186, 2.72607652975429, 2.8665621118080504, 2.9446836486562797, 5.826697914954375, 6.1955452892526965, 4.534000933886148, 4.648941208844629, 3.4200659612334734, 3.337099273186644, 3.311970493548919, 3.2275217955001825, 3.2662031997052705, 3.3022035011651805, 3.2843805488219076, 3.2940802997296865]
AR_ROSC_OFFSET	[-415.88671321534, -631.7680086493731, -434.9810707898764, -634.0098204630133, -536.9587012211289, -870.0213012119442, -677.9008892605333, -940.7138907668792, -670.9221090381328, -678.7863578920193, -769.3786568866899, -778.5029338739079, -719.453968488292, -720.186673066846, -784.7145451737966, -782.662060983211, -901.6752514742403, -908.2369967078486, -1031.4078089096365, -1034.7939041503992, -938.0605801129805, -939.2535457858376, -1108.970224859297, -1111.7329284085347, -513.5712828352029, -520.6424561261949, -633.9664180122039, -630.3100114538971, -619.1354515152013, -614.7191963721741, -511.4962216118272, -516.4583544223603, -607.2903020029054, -603.9187503321854, -997.7005791537279, -996.7425901706292, -1006.2896230752153, -997.4259145896334, -1003.6861404913427, -994.6302359895155, -997.4285153979977, -993.5324194580941]
AR_ROSC_SLOPE	[751.9063960144156, 1117.9499659543794, 747.9200308742319, 1116.3784969694361, 818.3720041790781, 1332.7963549262774, 971.0364904892385, 1376.5479560849285, 1168.9822221130344, 1160.7918905651557, 1314.3082677642942, 1316.340020771575, 1187.532716084311, 1196.4125084336304, 1317.69932054479, 1319.9745673560265, 1378.823996421609, 1364.7445926879932, 1553.9833030853194, 1559.4434309650198, 1346.9723716587578, 1357.6435202737928, 1623.5233199189192, 1621.5014710992152, 814.2403955448428, 823.6596834250943, 990.5246246696198, 989.7421883871616, 977.6305010613474, 983.8316916551377, 1138.9688627281605, 1155.5733976027527, 1132.1324886049917, 1147.7652640751724, 1508.9038774194476, 1502.2020839304564, 1510.8726464585222, 1499.5778661833772, 1501.402840220724, 1503.787222324196, 1499.4324707327075, 1504.6755292383964]
AR_TEMP_ACB	24.098
AR_TEMP_ASLDO	24.773
AR_TEMP_DSLDO	26.22
AR_TEMP_EXT	19.88
AR_TEMP_NF_ACB	1.255
AR_TEMP_NF_ASLDO	1.256
AR_TEMP_NF_BOTTOM	-999
AR_TEMP_NF_DSLDO	1.256
AR_TEMP_NF_TOP	-999
AR_TEMP_NTC	19.181
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_POLY_TOP	-999
AR_VCALDAC	0.819
AR_VDDA_SATURATION	-1
AR_VDDA_TRIM	10
AR_VDDA_VS_TRIM	[0.977, 1.002, 1.025, 1.05, 1.071, 1.095, 1.118, 1.142, 1.161, 1.185, 1.207, 1.231, 1.252, 1.276, 1.298, 1.322]
AR_VDDD_SATURATION	-1
AR_VDDD_TRIM	7
AR_VDDD_VS_TRIM	[1.038, 1.063, 1.087, 1.112, 1.139, 1.165, 1.187, 1.213, 1.231, 1.257, 1.28, 1.304, 1.333, 1.358, 1.382, 1.408]
AR_VREFCORE	0.457
AR_VREFOVP	1.952

Attachments

Filename	Contents
output.log	Download
0x36624.log	Download

RAW Results Record

Download RAW

_id

69bb346427d3ddc5179dbc17

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0222756

ANALOG_READBACK

69bb344662c0d164752fdb78

DCSdata

SensorVoltage	-120.0
SensorCurrent	7.299999999999999e-08
ModuleNTC	19.66

Measurements

Vmux0

X	False
Unit	V
Values	0.8282378

Vmux3

X	False
Unit	V
Values	0.4266772

Vmux4

X	False
Unit	V
Values	0.6181409

Vmux5

X	False
Unit	V
Values	0.1370876

Vmux6

X	False
Unit	V
Values	0.1475608

Vmux7

X	False
Unit	V
Values	0.1817381

Vmux8

X	False
Unit	V
Values	0.0570409

Vmux9

X	False
Unit	V
Values	0.06086929

Vmux10

X	False
Unit	V
Values	0.1878191

Vmux11

X	False
Unit	V
Values	0.1938002

Vmux12

X	False
Unit	V
Values	0.1961439

Vmux13

X	False
Unit	V
Values	0.6555337

Vmux15

X	False
Unit	V
Values	0.6549685

Vmux17

X	False
Unit	V
Values	0.6116638

Vmux31

X	False
Unit	V
Values	0.4742341

Vmux32

X	False
Unit	V
Values	0.6034807

Vmux33

X	False
Unit	V
Values	0.3968889

Vmux34

X	False
Unit	V
Values	0.6204838

Vmux35

X	False
Unit	V
Values	0.6155574

Vmux36

X	False
Unit	V
Values	0.2673025

Vmux37

X	False
Unit	V
Values	0.3982508

Vmux38

X	False
Unit	V
Values	0.6228946

Vmux39

X	False
Unit	V
Values	0.6179268

Vmux63

X	False
Unit	V
Values	0.0587182

Vmux30

X	False
Unit	V
Values	0.01732069

Imux0

X	False
Unit	V
Values	0.05424043

Imux1

X	False
Unit	V
Values	0.8863048

Imux2

X	False
Unit	V
Values	0.5005905

Imux3

X	False
Unit	V
Values	0.05615214

Imux4

X	False
Unit	V
Values	0.420174

Imux5

X	False
Unit	V
Values	0.2173378

Imux6

X	False
Unit	V
Values	0.01494287

Imux7

X	False
Unit	V
Values	0.4020394

Imux8

X	False
Unit	V
Values	0.7428275

Imux10

X	False
Unit	V
Values	0.01495133

Imux11

X	False
Unit	V
Values	0.01495237

Imux12

X	False
Unit	V
Values	0.4900773

Imux13

X	False
Unit	V
Values	0.6606755

Imux14

X	False
Unit	V
Values	0.5436526

Imux15

X	False
Unit	V
Values	0.891245

Imux16

X	False
Unit	V
Values	0.7453204

Imux17

X	False
Unit	V
Values	0.7859792

Imux18

X	False
Unit	V
Values	0.841577

Imux19

X	False
Unit	V
Values	0.4917707

Imux20

X	False
Unit	V
Values	0.7831723

Imux21

X	False
Unit	V
Values	0.505692

Imux22

X	False
Unit	V
Values	0.504608

Imux23

X	False
Unit	V
Values	0.781257

Imux24

X	False
Unit	V
Values	0.494118

Imux25

X	False
Unit	V
Values	0.4960093

Imux28

X	False
Unit	V
Values	0.3148891

Imux29

X	False
Unit	V
Values	0.04574051

Imux30

X	False
Unit	V
Values	0.4351728

Imux31

X	False
Unit	V
Values	0.1243253

Imux63

X	False
Unit	V
Values	0.01492716

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	228
DiffTh1M	228
DiffTh1R	228
DiffTh2	50
DiffVff	104
EfuseConfig	3855
EfuseReadData0	9232
EfuseReadData1	9062
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	832
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	32157
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	10
SldoTrimD	7
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	11.0 0.189 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.6
IrefTrim	10
KSenseInA	21368.3
KSenseInD	21469.662
KSenseShuntA	21979.0
KSenseShuntD	22083.0
KShuntA	997.011
KShuntD	968.07
Name	0x36624
NfACB	1.2551885
NfASLDO	1.2562025
NfDSLDO	1.2556312
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-1.0 0.2

SoftwareType

ChipID

Name

0x36624

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24830013

TimeStart

1773874214

TimeEnd

1773874468

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.6
ANALOG_READBACK_MEASUREMENT_VERSION	2.8.0

AR_VMEAS

MODULE/POST_PARYLENE_WARM

67a21dc789d864a1f4113198

1.01

64657cef8d79bac1f3f00578

mts	2026-03-18 23:25:24.020000
cts	2026-03-18 23:25:24.020000
rev	0

20UPGFC0222756

ANALOG_READBACK

69bb344662c0d164752fdb79

DCSdata

SensorVoltage	-120.0
SensorCurrent	7.399999999999999e-08
ModuleNTC	20.06

Measurements

Vmux2

X	False
Unit	V
Values	0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338 0.1471338

Vmux30

X	False
Unit	V
Values	0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517 0.01733517

Imux9

X	False
Unit	V
Values	0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023 0.1186023

Imux63

X	False
Unit	V
Values	0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527 0.01493527

Vmux14

X	False
Unit	V
Values	0.2253546 0.2265157 0.2260796 0.2253856 0.2260607 0.2263672 0.224899 0.2243029 0.2252492 0.2255818 0.2261741 0.2263441 0.2254236 0.2266299 0.2247248 0.225227 0.3131033 0.3130054 0.3129718 0.312987 0.3128972 0.3128635 0.3129621 0.31303 0.3130761 0.3130339 0.3129848 0.3129303 0.3129795 0.312871 0.3130204 0.3131318

Vmux16

X	False
Unit	V
Values	0.2272955 0.2277583 0.2256317 0.2268198 0.226817 0.227619 0.227649 0.2270296 0.2277796 0.2272722 0.2267304 0.2269864 0.2270824 0.2274914 0.2273925 0.2271596 0.3149649 0.3148993 0.3149986 0.3148976 0.3148439 0.3148277 0.3147858 0.3148036 0.3147495 0.3147791 0.3149583 0.3149824 0.3149768 0.3149298 0.314895 0.3148985

Vmux18

X	False
Unit	V
Values	0.232704 0.2330992 0.2326553 0.2328103 0.2315967 0.2329408 0.2334441 0.232835 0.2330889 0.2328621 0.2326653 0.2331155 0.2328108 0.2332492 0.2321275 0.2333039 0.3199721 0.3199112 0.3199036 0.3198891 0.3199636 0.3198385 0.3198089 0.3198669 0.3200112 0.3199992 0.3199537 0.3199089 0.319897 0.319827 0.3198792 0.3199173

MonSensSldoAnaSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoDigSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensAcbSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoAnaDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensSldoDigDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensAcbDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

TExtExtNTC

X	False
Unit	C
Values	19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88 19.88

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	228
DiffTh1M	228
DiffTh1R	228
DiffTh2	50
DiffVff	104
EfuseConfig	3855
EfuseReadData0	9232
EfuseReadData1	9062
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	832
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	32157
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	10
SldoTrimD	7
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	11.0 0.189 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.6
IrefTrim	10
KSenseInA	21368.3
KSenseInD	21469.662
KSenseShuntA	21979.0
KSenseShuntD	22083.0
KShuntA	997.011
KShuntD	968.07
Name	0x36624
NfACB	1.2551885
NfASLDO	1.2562025
NfDSLDO	1.2556312
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-1.0 0.2

SoftwareType

ChipID

Name

0x36624

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24830013

TimeStart

1773875824

TimeEnd

1773876295

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.6
ANALOG_READBACK_MEASUREMENT_VERSION	2.8.0

AR_TEMP

MODULE/POST_PARYLENE_WARM

67a21dc789d864a1f4113198

1.01

64657cef8d79bac1f3f00578

mts	2026-03-18 23:25:24.020000
cts	2026-03-18 23:25:24.020000
rev	0

20UPGFC0222756

ANALOG_READBACK

69bb344662c0d164752fdb7a

DCSdata

SensorVoltage	-120.0
SensorCurrent	7.299999999999999e-08
ModuleNTC	19.94

Measurements

Vmux34

X	False
Unit	V
Values	0.5058977 0.5184931 0.5295796 0.5420955 0.5527719 0.5647582 0.5762135 0.5881113 0.5978711 0.6096468 0.6206047 0.632693 0.6432442 0.6553771 0.6661165 0.6785065

Vmux38

X	False
Unit	V
Values	0.5365499 0.5489184 0.5606625 0.5733613 0.5868719 0.5995894 0.6107458 0.6235901 0.632958 0.6458419 0.6572115 0.6692925 0.6838103 0.6964991 0.7081206 0.7212019

Vmux30

X	False
Unit	V
Values	0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934 0.01731934

Vmux33

X	False
Unit	V
Values	0.3968064 0.3969904 0.397097 0.3970772 0.3971259 0.3971037 0.3970643 0.3971442 0.3971307 0.3970365 0.3970445 0.3969361 0.3968442 0.3968355 0.3967618 0.3966196

Vmux37

X	False
Unit	V
Values	0.398137 0.3982217 0.3982977 0.3982567 0.3983155 0.3983432 0.3983977 0.3984447 0.3983548 0.3981846 0.3980973 0.3978307 0.3973028 0.3964824 0.3953646 0.3930164

Imux63

X	False
Unit	V
Values	0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557 0.01492557

Imux28

X	False
Unit	V
Values	0.3129367 0.3133911 0.3137986 0.3140404 0.314237 0.3144657 0.3146706 0.3148013 0.3147831 0.3148996 0.3150513 0.3150736 0.315103 0.3151068 0.3149983 0.3148582

Imux29

X	False
Unit	V
Values	0.07594951 0.07059432 0.0667038 0.06266999 0.05985748 0.05674044 0.05425389 0.05149817 0.04976583 0.0475906 0.04575013 0.04391029 0.04289876 0.04198802 0.04184561 0.04332736

Imux30

X	False
Unit	V
Values	0.4326925 0.433522 0.4341283 0.4344356 0.4346625 0.4349966 0.4351414 0.4352241 0.4352133 0.4350204 0.4345437 0.433487 0.4315696 0.4283357 0.4241544 0.415568

Imux31

X	False
Unit	V
Values	0.1706319 0.1637273 0.157594 0.1506253 0.1436119 0.1368561 0.130804 0.1243701 0.1195963 0.1144401 0.1107555 0.1091747 0.1116374 0.1202638 0.1354682 0.1710142

SldoTrimA

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

SldoTrimD

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

ROSC0

X	False
Unit	MHz
Values	359.267 380.6 399.8 420.333 441.467 461.6 479.067 498.933 513.8 532.267 549.267 567.933 586.4 604.267 619.2 636.067

ROSC1

X	False
Unit	MHz
Values	520.2 552.067 580.067 611.733 643.333 673.4 699.4 728.867 750.8 778.6 803.533 830.867 858.533 885.0 906.467 931.733

ROSC2

X	False
Unit	MHz
Values	336.533 357.333 376.0 397.067 417.933 437.667 455.267 474.733 489.4 508.067 524.933 543.667 561.867 580.0 594.6 611.733

ROSC3

X	False
Unit	MHz
Values	516.667 548.267 576.333 607.8 639.267 669.2 695.133 724.4 746.6 774.133 798.733 826.6 853.933 880.6 902.733 927.6

ROSC4

X	False
Unit	MHz
Values	309.867 331.667 350.867 373.067 395.267 417.0 435.8 457.333 473.333 493.533 512.133 533.133 553.867 574.333 591.133 610.6

ROSC5

X	False
Unit	MHz
Values	509.333 544.333 576.2 611.933 648.267 683.667 714.067 749.067 774.867 808.533 838.533 873.0 906.333 939.667 967.6 998.733

ROSC6

X	False
Unit	MHz
Values	327.933 353.067 375.8 401.8 428.067 453.333 475.933 501.333 520.2 544.733 566.867 591.533 616.267 641.0 661.267 684.267

ROSC7

X	False
Unit	MHz
Values	484.2 520.0 553.067 589.867 627.467 663.667 694.867 731.267 758.6 793.0 824.267 859.133 894.533 928.4 956.933 989.4

ROSC8

X	False
Unit	MHz
Values	535.0 567.733 596.8 628.6 662.267 693.6 720.4 751.4 774.0 803.4 828.333 857.733 887.2 915.467 939.0 965.2

ROSC9

X	False
Unit	MHz
Values	518.667 551.067 580.4 611.667 644.933 676.2 702.8 733.333 755.933 785.0 810.267 839.333 868.267 896.333 920.133 945.8

ROSC10

X	False
Unit	MHz
Values	586.533 623.4 656.133 691.933 729.333 764.4 794.933 829.4 855.067 888.133 916.4 949.533 982.4 1014.2 1041.13 1069.93

ROSC11

X	False
Unit	MHz
Values	579.6 616.333 649.267 684.933 722.4 757.8 788.267 822.8 848.467 881.267 910.133 942.933 976.333 1007.87 1034.6 1063.6

ROSC12

X	False
Unit	MHz
Values	506.667 539.267 568.8 600.6 634.4 666.133 693.467 724.533 748.133 777.667 803.667 833.4 863.733 892.4 916.467 943.067

ROSC13

X	False
Unit	MHz
Values	514.733 547.867 577.733 610.0 643.8 675.8 703.667 734.6 758.267 788.4 814.2 844.333 874.533 903.533 928.067 954.8

ROSC14

X	False
Unit	MHz
Values	575.067 611.8 644.533 680.333 717.8 752.867 783.467 817.733 843.867 877.0 905.533 938.333 971.867 1003.67 1030.13 1059.8

ROSC15

X	False
Unit	MHz
Values	579.467 616.333 649.2 685.133 722.2 757.533 788.2 822.6 848.6 881.8 910.133 943.533 976.733 1009.07 1035.8 1064.8

ROSC16

X	False
Unit	MHz
Values	525.133 562.133 594.933 630.733 668.933 705.6 737.133 772.8 800.533 835.333 865.533 900.8 936.333 970.6 999.667 1031.6

ROSC17

X	False
Unit	MHz
Values	504.267 540.4 573.133 608.467 646.533 682.4 713.933 749.133 776.533 810.733 840.667 875.667 911.533 945.533 973.667 1004.87

ROSC18

X	False
Unit	MHz
Values	577.4 618.667 655.4 695.733 738.867 779.6 815.267 855.467 886.467 925.6 959.867 999.867 1040.4 1079.13 1111.8 1148.0

ROSC19

X	False
Unit	MHz
Values	579.8 621.0 658.067 698.533 741.667 782.067 818.333 858.867 890.067 929.2 963.333 1003.6 1043.93 1083.0 1116.27 1152.4

ROSC20

X	False
Unit	MHz
Values	457.267 492.6 524.4 558.667 595.867 631.333 662.267 697.333 723.867 758.067 787.533 822.733 857.8 891.333 920.267 951.4

ROSC21

X	False
Unit	MHz
Values	466.667 502.267 534.533 569.4 607.4 642.6 673.933 709.467 736.2 770.667 800.333 835.267 870.867 904.533 933.467 964.733

ROSC22

X	False
Unit	MHz
Values	572.067 614.933 653.467 695.067 740.4 783.067 820.133 862.4 894.667 935.733 971.8 1013.2 1055.47 1095.87 1130.67 1167.53

ROSC23

X	False
Unit	MHz
Values	567.067 610.067 648.333 690.2 735.4 777.933 815.467 857.267 889.267 930.067 966.333 1007.87 1049.93 1090.6 1124.8 1162.13

ROSC24

X	False
Unit	MHz
Values	328.2 350.267 370.133 391.333 414.4 435.8 454.667 475.867 492.067 512.333 530.2 550.933 572.0 592.133 608.867 627.133

ROSC25

X	False
Unit	MHz
Values	330.933 353.2 373.2 394.667 418.133 439.8 459.0 480.133 496.467 517.267 535.067 556.2 577.333 597.6 614.8 633.6

ROSC26

X	False
Unit	MHz
Values	390.533 416.933 441.2 467.0 494.733 521.067 543.733 569.4 588.867 613.867 635.6 660.867 686.533 710.933 731.667 754.533

ROSC27

X	False
Unit	MHz
Values	393.333 419.8 443.733 469.733 497.467 523.667 546.533 572.333 591.8 616.867 638.467 663.467 689.067 713.067 734.333 757.0

ROSC28

X	False
Unit	MHz
Values	391.467 418.0 441.667 467.533 495.067 520.867 543.667 568.867 588.2 612.733 634.333 658.733 684.0 708.067 728.667 750.733

ROSC29

X	False
Unit	MHz
Values	402.133 428.867 452.933 478.667 506.667 532.667 555.533 581.0 600.333 624.933 646.6 671.133 696.867 721.067 741.4 763.733

ROSC30

X	False
Unit	MHz
Values	660.6 693.8 723.333 755.0 788.267 819.0 845.933 875.533 897.667 925.933 950.133 978.6 1006.73 1033.47 1055.67 1080.33

ROSC31

X	False
Unit	MHz
Values	672.267 706.067 736.467 768.267 802.4 833.6 860.733 891.2 913.667 942.333 966.733 995.333 1024.13 1050.87 1073.53 1097.73

ROSC32

X	False
Unit	MHz
Values	560.533 592.4 620.667 651.067 683.933 713.933 740.333 769.8 792.4 820.467 844.933 873.2 902.067 928.8 952.2 976.867

ROSC33

X	False
Unit	MHz
Values	579.933 612.267 641.067 672.0 704.933 735.667 762.267 792.333 814.867 843.533 868.133 897.333 926.6 953.667 976.733 1001.93

ROSC34

X	False
Unit	MHz
Values	564.333 604.267 640.4 679.267 721.133 761.0 795.267 834.8 864.6 902.6 935.667 974.6 1014.13 1051.4 1083.4 1118.4

ROSC35

X	False
Unit	MHz
Values	558.6 598.133 634.133 672.667 714.333 754.067 788.4 827.4 857.267 895.067 928.0 966.733 1006.2 1043.27 1075.13 1110.13

ROSC36

X	False
Unit	MHz
Values	557.867 597.667 634.067 673.0 714.8 754.867 789.067 828.4 858.267 896.333 929.533 968.333 1008.07 1045.67 1077.47 1112.93

ROSC37

X	False
Unit	MHz
Values	555.133 594.8 630.6 669.467 710.867 750.2 784.467 823.4 853.067 890.8 923.733 962.533 1001.87 1039.47 1071.07 1105.8

ROSC38

X	False
Unit	MHz
Values	550.8 590.533 626.2 665.0 706.667 745.933 780.733 819.467 849.2 886.933 919.667 958.6 998.0 1035.73 1067.27 1102.07

ROSC39

X	False
Unit	MHz
Values	562.333 602.0 637.667 676.8 718.467 757.867 792.4 831.667 861.333 899.133 931.867 970.733 1010.2 1047.8 1079.53 1114.53

ROSC40

X	False
Unit	MHz
Values	555.4 594.8 629.933 668.933 710.6 750.067 784.2 823.4 852.933 890.733 923.6 962.733 1001.73 1039.07 1070.73 1105.53

ROSC41

X	False
Unit	MHz
Values	564.4 604.2 639.867 678.533 720.467 760.2 794.4 833.8 863.267 901.467 934.333 973.2 1012.53 1049.8 1081.8 1117.0

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	228
DiffTh1M	228
DiffTh1R	228
DiffTh2	50
DiffVff	104
EfuseConfig	3855
EfuseReadData0	9232
EfuseReadData1	9062
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	832
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	32157
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	10
SldoTrimD	7
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	11.0 0.189 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.6
IrefTrim	10
KSenseInA	21368.3
KSenseInD	21469.662
KSenseShuntA	21979.0
KSenseShuntD	22083.0
KShuntA	997.011
KShuntD	968.07
Name	0x36624
NfACB	1.2551885
NfASLDO	1.2562025
NfDSLDO	1.2556312
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-1.0 0.2

SoftwareType

ChipID

Name

0x36624

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24830013

TimeStart

1773874468

TimeEnd

1773875823

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.6
ANALOG_READBACK_MEASUREMENT_VERSION	2.8.0

AR_VDD

MODULE/POST_PARYLENE_WARM

67a21dc789d864a1f4113198

1.01

64657cef8d79bac1f3f00578

mts	2026-03-18 23:25:24.020000
cts	2026-03-18 23:25:24.020000
rev	0

20UPGFC0222756

ANALOG_READBACK

69bb344662c0d164752fdb7b

DCSdata

Measurements

IrefTrimSense

X	False
Unit	-
Values	10.0

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	228
DiffTh1M	228
DiffTh1R	228
DiffTh2	50
DiffVff	104
EfuseConfig	3855
EfuseReadData0	9232
EfuseReadData1	9062
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	832
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	32157
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	10
SldoTrimD	7
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	11.0 0.189 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.6
IrefTrim	10
KSenseInA	21368.3
KSenseInD	21469.662
KSenseShuntA	21979.0
KSenseShuntD	22083.0
KShuntA	997.011
KShuntD	968.07
Name	0x36624
NfACB	1.2551885
NfASLDO	1.2562025
NfDSLDO	1.2556312
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-1.0 0.2

SoftwareType

ChipID

Name

0x36624

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24830013

TimeStart

1773875823

TimeEnd

1773875824

comment

property

YARR_VERSION	v1.5.6
ANALOG_READBACK_MEASUREMENT_VERSION	2.8.0

AR_REGISTER

MODULE/POST_PARYLENE_WARM

67a21dc789d864a1f4113198

1.01

64657cef8d79bac1f3f00578

mts	2026-03-18 23:25:24.020000
cts	2026-03-18 23:25:24.020000
rev	0

rawHash

f9cec67de3862e01c286f44bf49c6376

stage

MODULE/POST_PARYLENE_WARM

ProductionDB Record

Expand ProductionDB Record

69d71809ffb99db4b68dd0ce

state

ready

stateTs

2026-04-09T03:07:53.498Z

stateUserIdentity

4728-7541-1

date

2026-03-18T23:25:00.000Z

testType

id	6393a07c15838700361eebef
code	ANALOG_READBACK
name	Analog Readback
state	active

institution

id	5d318624df98f200097386d5
code	ANL
name	Argonne National Laboratory

user

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

runNumber

69bb346827d3ddc5179dbc3a

passed

True

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	Analog Readback Analysis Version	string	None	True	2.8.0rc1	None	None
MEASUREMENT_DATE	Date measurement performed	datetime	None	False	2026-03-18T22:50:14.000+00:00	None	None
MEASUREMENT_DURATION	Measurement duration	integer	None	False	254	None	None
MEASUREMENT_VERSION	Measurement version	string	None	False	2.8.0	None	None
YARR_VERSION	Yarr Version	string	None	False	v1.5.6	None	None

results

code AR_IREF_TRIM
name Wirebonded Iref trim on ITkPix v2 chip
order 23
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 10
associateChild None
code AR_IREF
name AR_IREF (A)
order 24
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 3.9e-06
associateChild None
code AR_GADC
name AR_GADC (V)
order 25
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.811
associateChild None

code	AR_NOMINAL_SETTINGS
name	Analog readback at nominal settings
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	3.9e-06 8.71e-05 4.86e-05 4.1e-06 4.05e-05 2.02e-05 0 3.87e-05 7.28e-05 -999 0 0 4.75e-05 6.46e-05 5.29e-05 8.76e-05 7.3e-05 7.71e-05 8.27e-05 8.76e-05 7.68e-05 4.91e-05 4.9e-05 7.66e-05 4.79e-05 4.81e-05 -999 -999 0.6409677 0.0677247 0.9022532 0.2415839 0.8109171 -999 -999 0.818713 1.2016404 0.1197669 0.1302401 0.1644174 0.0397202 0.0435486 0.1704984 0.1764795 0.1788232 0.638213 -999 0.6376478 -999 0.5943431 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 0.0173207 0.4569134 1.9519128 1.5182728 1.2063262 0.5982367 0.9999272 1.5237204 1.2111478 0.6006061
associateChild	None

code	AR_ROSC_MAX_RESIDUAL
name	Ring Oscillator Max Residual
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	3.2124313465980987 5.166419920749339 3.054200546946007 4.94719868844805 2.086688670595994 3.3637606516726652 2.096644169700724 3.448471965042811 4.640782409903109 4.5891655007114815 5.156449366662243 5.1722867954790726 4.2981628317644995 4.390836942636224 5.012665386578709 4.977045859835651 3.401545555153323 3.3634519552343156 3.480210120700773 3.4531400500250604 2.750796079838468 2.991690416600329 3.6681268740056128 3.656355190250811 2.399212517202439 2.3761696759887996 2.64095296004186 2.72607652975429 2.8665621118080504 2.9446836486562797 5.826697914954375 6.1955452892526965 4.534000933886148 4.648941208844629 3.4200659612334734 3.337099273186644 3.311970493548919 3.2275217955001825 3.2662031997052705 3.3022035011651805 3.2843805488219076 3.2940802997296865
associateChild	None

code	AR_ROSC_OFFSET
name	Ring Oscillator Offset
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	-415.88671321534 -631.7680086493731 -434.9810707898764 -634.0098204630133 -536.9587012211289 -870.0213012119442 -677.9008892605333 -940.7138907668792 -670.9221090381328 -678.7863578920193 -769.3786568866899 -778.5029338739079 -719.453968488292 -720.186673066846 -784.7145451737966 -782.662060983211 -901.6752514742403 -908.2369967078486 -1031.4078089096365 -1034.7939041503992 -938.0605801129805 -939.2535457858376 -1108.970224859297 -1111.7329284085347 -513.5712828352029 -520.6424561261949 -633.9664180122039 -630.3100114538971 -619.1354515152013 -614.7191963721741 -511.4962216118272 -516.4583544223603 -607.2903020029054 -603.9187503321854 -997.7005791537279 -996.7425901706292 -1006.2896230752153 -997.4259145896334 -1003.6861404913427 -994.6302359895155 -997.4285153979977 -993.5324194580941
associateChild	None

code	AR_ROSC_SLOPE
name	Ring Oscillator Slope
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	751.9063960144156 1117.9499659543794 747.9200308742319 1116.3784969694361 818.3720041790781 1332.7963549262774 971.0364904892385 1376.5479560849285 1168.9822221130344 1160.7918905651557 1314.3082677642942 1316.340020771575 1187.532716084311 1196.4125084336304 1317.69932054479 1319.9745673560265 1378.823996421609 1364.7445926879932 1553.9833030853194 1559.4434309650198 1346.9723716587578 1357.6435202737928 1623.5233199189192 1621.5014710992152 814.2403955448428 823.6596834250943 990.5246246696198 989.7421883871616 977.6305010613474 983.8316916551377 1138.9688627281605 1155.5733976027527 1132.1324886049917 1147.7652640751724 1508.9038774194476 1502.2020839304564 1510.8726464585222 1499.5778661833772 1501.402840220724 1503.787222324196 1499.4324707327075 1504.6755292383964
associateChild	None

code AR_TEMP_ACB
name Temperature ACB
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 24.098
associateChild None
code AR_TEMP_ASLDO
name Temperature Ana SLDO
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 24.773
associateChild None
code AR_TEMP_DSLDO
name Temperature Dig SLDO
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 26.22
associateChild None
code AR_TEMP_EXT
name Control temperature (external NTC from the FE)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 19.88
associateChild None
code AR_TEMP_NF_ACB
name Temperature calibration constant (ACB)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.255
associateChild None
code AR_TEMP_NF_ASLDO
name Temperature calibration constant (ana SLDO)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.256
associateChild None
code AR_TEMP_NF_BOTTOM
name Temperature calibration constant (poly bottom)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_NF_DSLDO
name Temperature calibration constant (dig SLDO)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.256
associateChild None
code AR_TEMP_NF_TOP
name Temperature calibration constant (poly top)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_NTC
name Temperature NTC
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 19.181
associateChild None
code AR_TEMP_POLY_BOTTOM
name Temperature poly bottom
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_POLY_TOP
name Temperature poly top
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_VCALDAC
name AR_VCALDAC (V)
order 26
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.819
associateChild None
code AR_VDDA_SATURATION
name VDDA saturation trim value
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -1
associateChild None
code AR_VDDA_TRIM
name VDDA Trim
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 10
associateChild None

code	AR_VDDA_VS_TRIM
name	VDDA vs trim
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	0.977 1.002 1.025 1.05 1.071 1.095 1.118 1.142 1.161 1.185 1.207 1.231 1.252 1.276 1.298 1.322
associateChild	None

code AR_VDDD_SATURATION
name VDDD saturation trim value
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -1
associateChild None
code AR_VDDD_TRIM
name VDDD Trim
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 7
associateChild None

code	AR_VDDD_VS_TRIM
name	VDDD vs trim
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	1.038 1.063 1.087 1.112 1.139 1.165 1.187 1.213 1.231 1.257 1.28 1.304 1.333 1.358 1.382 1.408
associateChild	None

code AR_VREFCORE
name AR_VREFCORE (V)
order 27
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.457
associateChild None
code AR_VREFOVP
name AR_VREFOVP (V)
order 28
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 1.952
associateChild None

cts

2026-04-09T03:07:53.498Z

sys

cts	2026-04-09T03:07:53.498Z
mts	2026-04-09T03:08:04.506Z
rev	2

defects

comments

None

attachments

code

50faf5c40a9c3a8594f57f45d2c26137

dateTime

2026-04-09T03:07:53.868Z

title

TestRun_69d71809ffb99db4b68dd0ce_Attachment_Pack.zip

description

/home/data/viewer/static/cache/thumbnail/TestRun_69d71809ffb99db4b68dd0ce_Attachment_Pack.zip

contentType

None

type

eos

url

https://eosatlas.cern.ch/eos/atlas/atlascerngroupdisk/det-itk/prod-db/5/0/f/50faf5c40a9c3a8594f57f45d2c26137?authz=zteos64:MDAwMDAyZjR4nO1RMUvDQBilBR06iaPThziIkOYuuUuTb3K1TkpxKRmuubs2tOZCegHpqEPdHIoIzk5uDv4GB0EQB3cF6SK4uBvFwcHZyW_4hve99_Eer_Fcb9SKpZfjo_vFlYXUDnO5Wp_k6zWv4yozdoUdie-dqCLrF6bMZToeulJZp6K7eWGkI3sud4mrXU600DxhRESJL0IeMc1bmnHpJV5A_VZ7LVSBT6SfOFyLyKFUUyfkHncE62lCW1FFjXbvat3OoIR2mQEwIB6SEFkAHvGCGMpUImU0CGn3y28M_U_EJ63uJI_BplJlFgtjbJMSEjL0A0Y2u4i6GuS0SWnQjMLqGEMm9hV-fQGZIVRhLA6LHgeR5wgDM7b4u1CafZFm-APpK4MwLqVBArYQiUIwWU8NxEjjMjzQp_ne8Oxtevm6MTp5v7o-mM03nuLT9u3F4c7j9tbKfw9_0APMbs6n9Q-Hjuwk

urlCernbox

https://cernbox.cern.ch/files/spaces/eos/atlas/atlascerngroupdisk/det-itk/prod-db/5/0/f/50faf5c40a9c3a8594f57f45d2c26137

filename

50faf5c40a9c3a8594f57f45d2c26137

user

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

code

6aef118a6f922459f3425509190e7729

dateTime

2026-04-09T03:08:03.815Z

title

RAW

description

RAW

contentType

text/plain

type

file

binaryStoreg02

True

filename

data

user

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

components

code

state

stateTs

stateUserIdentity

dummy

completed

completedTs

completedUserIdentity

trashed

trashedTs

trashedUserIdentity

serialNumber

alternativeIdentifier

ancestorMap

project

subproject

componentType

type

properties

testedAtStage

institution

67a21dc789d864a1f4113198

d1139a1de02ba67cd0289a599ceff226

ready

2025-02-04T14:01:43.833Z

5310-2637-1

False

None

False

None

20UPGFC0222756

None

parent

component

68d2c40aecbbcc3f84460799

code

d6d322de7c8dabc1ed8458a204b44fb9

state

ready

stateTs

2025-09-23T16:00:10.443Z

stateUserIdentity

23-6780-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGB43000292

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	BARE_MODULE
name	Bare Module

type

code	QUAD_BARE_MODULE
name	Quad bare module

testedAtStage

code	MODULE/POST_PARYLENE_WARM
name	Post-Parylene Warm

highestLevelParent

component

690e471744c06a976341e2b5

code

770a41435a1cab05da0418534872090c

state

ready

stateTs

2025-11-07T19:23:03.781Z

stateUserIdentity

4561-2270-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGM24830013

alternativeIdentifier

ANL_ITkPix_185

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	MODULE
name	Module

type

code	OUTER_SYSTEM_QUAD_MODULE
name	Outer system quad module

testedAtStage

code	MODULE/POST_PARYLENE_WARM
name	Post-Parylene Warm

code	P
name	Pixels

code	PG
name	Pixel general

code	FE_CHIP
name	Front-end Chip

code	ITKPIX_V2
name	ITkpix_V2

code	name	dataType	required	default	value
TARGET_IREF_TRIM	Target Iref trim	integer	False	False	10
TARGET_IREF_TRIM_VERSION	Target Iref trim version	string	False	False	1

code	MODULE/POST_PARYLENE_WARM
name	Post-Parylene Warm
order	15
initial	False
final	False

code	GL
name	Glasgow University

Current Stage: Post-Parylene Cold

Test Type	Local Result
ADC Calibration (ADC_CALIBRATION)	No TestRun!
Analog Readback (ANALOG_READBACK)	No TestRun!
VCAL Calibration (VCAL_CALIBRATION)	No TestRun!
Low Power Mode (LP_MODE)	No TestRun!
Data Transmission (DATA_TRANSMISSION)	No TestRun!
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No TestRun!
Undershunt Protection (UNDERSHUNT_PROTECTION)	No TestRun!
SLDO (SLDO)	No TestRun!
Minimal Health Test (MIN_HEALTH_TEST)	No TestRun!
Tuning (TUNING)	No TestRun!
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No TestRun!
Injection Capacitance (INJECTION_CAPACITANCE)	No TestRun!

Candidate TestRuns of this Stage

LDB ID	TestRun Code	QC Passed	Inspector	Measurement Date	Analysis Date	Analysis Version	Tags	QC Registration
69bb3a…9dbf30	LP_MODE	Pass	DanielAceves	3 months ago	2 months ago	2.8.0rc1	No tags	Selected
69bb46…9dc54a	PIXEL_FAILURE_ANALYSIS	Pass	DanielAceves	N/A	2 months ago	2.8.0rc1	No tags	Selected
69bb45…9dc3be	TUNING	Pass	DanielAceves	N/A	2 months ago	2.8.0rc1	No tags	Selected
69bb45…9dc2ad	MIN_HEALTH_TEST	Pass	DanielAceves	N/A	2 months ago	2.8.0rc1	No tags	Selected
69bb39…9dbefa	INJECTION_CAPACITANCE	Pass	DanielAceves	3 months ago	2 months ago	2.8.0rc1	No tags	Selected
69bb39…9dbe8a	DATA_TRANSMISSION	Pass	DanielAceves	3 months ago	2 months ago	2.8.0rc1	No tags	Selected
69bb38…9dbe42	VCAL_CALIBRATION	Pass	DanielAceves	3 months ago	2 months ago	2.8.0rc1	No tags	Selected
69bb37…9dbd44	SLDO	Pass	DanielAceves	3 months ago	2 months ago	2.8.0rc1	No tags	Selected
69bb34…9dbc3a	ANALOG_READBACK	Pass	DanielAceves	3 months ago	2 months ago	2.8.0rc1	No tags	Selected
69bb2c…9dbab4	ADC_CALIBRATION	Pass	DanielAceves	3 months ago	2 months ago	2.8.0rc1	No tags	Selected

Past QC Stages and Results

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Cold (MODULE/INITIAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Warm (MODULE/INITIAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wire Bonding (MODULE/WIREBONDING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Test	Local Result	ProdDB Record
Analog Readback (ANALOG_READBACK)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

Test	Local Result	ProdDB Record
Electrical FE chip tests (FECHIP_TEST)	Registered	Registered

LocalDB Test ID	Stage	Test Name	Inspector	Measurement Date	Analysis Date	Tags	QC Registration
69bb3a…9dbf30	MODULE/POST_PARYLENE_WARM	LP_MODE	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bb46…9dc54a	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	DanielAceves	N/A	2 months ago	No tags	Selected
69bb45…9dc3be	MODULE/POST_PARYLENE_WARM	TUNING	DanielAceves	N/A	2 months ago	No tags	Selected
69bb45…9dc2ad	MODULE/POST_PARYLENE_WARM	MIN_HEALTH_TEST	DanielAceves	N/A	2 months ago	No tags	Selected
69bb39…9dbefa	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bb39…9dbe8a	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bb38…9dbe42	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bb37…9dbd44	MODULE/POST_PARYLENE_WARM	SLDO	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bb34…9dbc3a	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bb2c…9dbab4	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	DanielAceves	3 months ago	2 months ago	No tags	Selected
692f6d…afd087	MODULE/INITIAL_WARM	PIXEL_FAILURE_ANALYSIS	DavidJiang	N/A	3 months ago	No tags	Selected
692f6d…afcf83	MODULE/INITIAL_WARM	TUNING	DavidJiang	N/A	3 months ago	No tags	Selected
692f6c…afcef6	MODULE/INITIAL_WARM	MIN_HEALTH_TEST	DavidJiang	N/A	3 months ago	No tags	Selected
692f61…afc855	MODULE/INITIAL_WARM	DATA_TRANSMISSION	DavidJiang	6 months ago	3 months ago	No tags	Selected
692f62…afc8e4	MODULE/INITIAL_WARM	LP_MODE	DavidJiang	N/A	3 months ago	No tags	Selected
692f61…afc829	MODULE/INITIAL_WARM	VCAL_CALIBRATION	DavidJiang	6 months ago	3 months ago	No tags	Selected
692f5f…afc7c5	MODULE/INITIAL_WARM	SLDO	DavidJiang	6 months ago	3 months ago	No tags	Selected
692f5d…afc4f0	MODULE/INITIAL_WARM	ANALOG_READBACK	DavidJiang	6 months ago	3 months ago	No tags	Selected
692f55…afbe0e	MODULE/INITIAL_WARM	ADC_CALIBRATION	DavidJiang	6 months ago	3 months ago	No tags	Selected
67a21d…df0972	TESTONWAFER	FECHIP_TEST	DimaManeuski	N/A	a year ago	No tags	Selected

Stage	Tests
TESTONWAFER	Electrical FE chip tests (FECHIP_TEST)
HYBRIDISATION
UNUSABLE
BAREMODULEASSEMBLY
BAREMODULERECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK)
MODULE/INIT
MODULE/ASSEMBLY
MODULE/WIREBONDING	ADC Calibration (ADC_CALIBRATION) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO) Low Power Mode (LP_MODE) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/INITIAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/QC_CROSSCHECK	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/INITIAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_MASKING	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Low Power Mode (LP_MODE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_COATING
MODULE/PARYLENE_UNMASKING	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE)
MODULE/WIREBOND_PROTECTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) Low Power Mode (LP_MODE) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/POST_PARYLENE_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE)
MODULE/POST_PARYLENE_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/THERMAL_CYCLES	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Cold startup (COLD_STARTUP)
MODULE/LONG_TERM_STABILITY_TEST	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Undershunt Protection (UNDERSHUNT_PROTECTION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Data Transmission (DATA_TRANSMISSION) Cold startup (COLD_STARTUP)
MODULE/FINAL_METROLOGY	Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE) Analog Readback (ANALOG_READBACK)
MODULE/QC_STATUS
MODULE/UNHAPPY	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/NOTCONSIDEREDINYIELDS	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Undershunt Protection (UNDERSHUNT_PROTECTION) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/GRAVEYARD
MODULE/COMPLETE
MODULE/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION) Tuning (TUNING)
MODULE/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
LLS/PRE_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Low Power Mode (LP_MODE) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/PRE_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/INIT
OB_LOADED_MODULE_CELL/ASSEMBLY
OB_LOADED_MODULE_CELL/WIREBOND_PROTECTION
OB_LOADED_MODULE_CELL/THERMAL_CYCLES
OB_LOADED_MODULE_CELL/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/THERMAL_COLD
OB_LOADED_MODULE_CELL/THERMAL_WARM
OB_LOADED_MODULE_CELL/ENVELOPE_CHECK
OB_LOADED_MODULE_CELL/QC_STATUS
OB_LOADED_MODULE_CELL/UNHAPPY
OB_LOADED_MODULE_CELL/GRAVEYARD
OB_LOADED_MODULE_CELL/COMPLETE
OB_LOADED_MODULE_CELL/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO)
OB_LOADED_MODULE_CELL/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
OB_LOADED_MODULE_CELL/PIGTAIL_INSERTION
TEST_AFTER_LOADED_LOCAL_SUPPORT_ASSEMBLY	OB:Loaded local support QC electrical connectivity (OBLoadedLocalSupportQC_ElectricalConnectivity) OB:Loaded local support QC electrical performance (OBLoadedLocalSupportQC_ElectricalPerformance) OB:Loaded local support reception at the integration site (OBLoadedLocalSupport_IntegrationSite) OB:Loaded local support QC electrical low power (OBLoadedLocalSupport_QCElectricalLowPower)
TEST_JM_OEC_FE

20UPGFC0222756

MODULE/POST_PARYLENE_COLD

Component Information

Wafer

Properties

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Results

Attachments

RAW Results Record

ProductionDB Record

Current Stage: Post-Parylene Cold

Candidate TestRuns of this Stage

Past QC Stages and Results

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Initial Cold (MODULE/INITIAL_COLD)

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Initial Warm (MODULE/INITIAL_WARM)

Wire Bonding (MODULE/WIREBONDING)

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

All Registered QC Tests

Check QC Flow

Back to top page of this component
