20UPIM02202116

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPIM02202116
ProdDB ID	0dc63f…04be35
LocalDB ID	670e23c0e1231800423a16e2
Component Type	MODULE
Parents	No match.
Children	20UPGB12200114 Bare Module 20UPGB12200115 Bare Module 20UPGFC0096394 FE Chip 20UPGB12200116 Bare Module 20UPIP03252116 PCB 20UPGFC0096410 FE Chip 20UPGFC0096426 FE Chip
Flags

Distribution of chips on wafer

Properties

Item	Value
FE chip version	2
PCB-Bare Orientation isNormal	True
IREFTRIM_FE1 deleted	4
IREFTRIM_FE2 deleted	8
IREFTRIM_FE3 deleted	9
Wirebond protection roof presence	None
Alternative ID	None
Rank	None

Comments

Test: IV_MEASURE QC Failed

(Stage: MODULE/INITIAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	False
Date	11 months ago
component ObjectId	670e23c0e1231800423a16e2
Stage	MODULE/INITIAL_WARM
Test Type	IV_MEASURE
Institute ObjectId
User Name	SimenHellesund
ObjectId of this record	678f8559f34390fa40d80055
ObjectId of RAW record	678f8557f34390fa40d8004e
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.2.9rc4
HUM	0
MEASUREMENT_DATE	2025-01-21T11:25:59.000+00:00
MEASUREMENT_DURATION	None
TEMP	18.62
BREAKDOWN_REDUCTION	-4.5
BREAKDOWN_VOLTAGE	39
IV_ARRAY	{'time': [2.974400281906128, 8.453735113143921, 14.143447160720825, 20.20949125289917, 25.27088475227356, 30.504056930541992, 35.695162534713745, 40.867700815200806, 46.12405228614807, 51.37932801246643, 56.41055917739868, 61.41846799850464, 66.3943932056427, 71.41173124313354, 76.44807934761047, 81.94805932044983, 87.23095726966858, 92.21450328826904, 97.39906764030457, 102.61934185028076, 107.75706028938293, 112.97565126419067, 118.231614112854, 123.70847702026367, 128.7969512939453, 133.79136490821838, 139.21926021575928, 144.37473058700562, 149.56598544120789, 155.26335287094116, 160.52975630760193, 165.89242267608643, 171.14546060562134, 176.17703127861023, 181.5332293510437, 186.96975302696228, 192.0603642463684, 196.99035906791687, 202.07766461372375, 207.22279238700867, 212.62511682510376], 'voltage': [3.545682e-06, 0.9999979, 1.999985, 3.000007, 3.999974, 4.999936, 5.999882, 6.999859, 7.999886, 8.999878, 9.99983, 10.99972, 11.99981, 12.99972, 13.99973, 14.99996, 15.9999, 17, 17.99989, 18.99994, 19.99986, 20.99983, 22.00003, 22.99961, 23.99807, 25.00069, 25.9993, 26.99907, 27.99854, 28.99784, 29.99994, 30.99927, 31.99858, 32.99823, 34.00079, 34.99965, 35.99896, 36.99834, 37.99757, 38.99986, 39.99842], 'current': [0.00018553366666666668, 4.348303333333333, 7.897131333333332, 11.584856666666667, 15.354230000000003, 19.04149333333333, 22.010223333333332, 24.09943, 25.33646, 25.958090000000002, 26.217900000000004, 26.310700000000004, 26.34277, 26.37575, 26.450129999999998, 26.575943333333335, 26.776833333333332, 27.03552, 27.34767666666667, 27.723723333333332, 28.11517, 28.518376666666665, 28.927663333333335, 29.34720666666667, 29.77584666666667, 30.206190000000003, 30.635026666666665, 31.05932333333333, 31.482640000000007, 31.951530000000005, 32.41185000000001, 32.88582666666667, 33.39318, 33.93422666666667, 34.51088333333333, 35.131499999999996, 35.98852333333333, 36.86809333333334, 43.847496666666665, 62.25168000000001, 78.26161666666667], 'sigma current': [3.54406284899439e-05, 0.016546681647857893, 0.1392457577865675, 0.17055240374214053, 0.18270975233960549, 0.17536705930387594, 0.13635721844560328, 0.07583277963167735, 0.03485133091671892, 0.0008809464607252742, 0.013458249019342793, 0.023570613059485913, 0.02169933332309226, 0.02239918450896441, 0.016330807287659312, 0.01087579677796332, 0.005955397178657031, 0.00283356077518535, 0.0019948990506349373, 0.004930458621896382, 0.005165984901255251, 0.00563291714438914, 0.005806601606982594, 0.006463953038883669, 0.0050615039486517025, 0.005050247518686141, 0.0036206291657065507, 0.004677209519455388, 0.004361062561653856, 0.007645198929174033, 0.0052610328517013576, 0.00736127857251823, 0.009701010256668032, 0.009788702104409056, 0.03529402247155061, 0.011799740110132784, 0.04487976926064679, 0.016563015694275564, 0.027283062307755384, 0.017953458348372812, 0.011626184049616883], 'temperature': [10.490753173828125, 9.441619873046875, 10.857025146484375, 13.163421630859375, 15.4825439453125, 17.297607421875, 18.561614990234375, 19.482421875, 19.83416748046875, 19.87347412109375, 19.87347412109375, 19.75567626953125, 19.677398681640625, 19.560272216796875, 19.482421875, 19.404754638671875, 19.365966796875, 19.327239990234375, 19.288543701171875, 19.404754638671875, 19.404754638671875, 19.521331787109375, 19.44354248046875, 19.521331787109375, 19.599273681640625, 19.560272216796875, 19.716522216796875, 19.599273681640625, 19.6383056640625, 19.75567626953125, 19.794891357421875, 19.75567626953125, 19.794891357421875, 19.794891357421875, 19.794891357421875, 19.75567626953125, 19.794891357421875, 19.83416748046875, 19.87347412109375, 19.794891357421875, 19.87347412109375], 'humidity': []}
LEAK_CURRENT	31.329039575711327
LEAK_INCREASE_FACTOR	1.33
LEAK_PER_AREA	2.46
MAXIMUM_VOLTAGE	39.99842
NO_BREAKDOWN_VOLTAGE_OBSERVED	False

Attachments
