20UPGFC0156310

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0156310
ProdDB ID	32e4b2…635792
LocalDB ID	661469dd64ba440035c0cceb
Component Type	fe_chip
Parents	20UPIM13710377 20UPGB43000042
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: SLDO QC Passed

(Stage: MODULE/QC_CROSSCHECK)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	4 months ago
component ObjectId	661469dd64ba440035c0cceb
Stage	MODULE/QC_CROSSCHECK
Test Type	SLDO
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	68a3675f8428c598c032f7d7
ObjectId of RAW record	68a3675e8428c598c032f7cc
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-07-08T19:26:02.000+00:00
MEASUREMENT_DURATION	601
MEASUREMENT_VERSION	2.6.0
YARR_VERSION	v1.5.5
SLDO_ANALOG_OVERHEAD	0.148
SLDO_D_MIN_IIN	5.145
SLDO_A_MIN_IIN	5.887
SLDO_D_SLOPE	0.135
SLDO_A_SLOPE	0.126
SLDO_D_OFFSET	-0.572
SLDO_A_OFFSET	-0.732
SLDO_A_CHI2	0
SLDO_DIGITAL_OVERHEAD	0.533
SLDO_D_CHI2	0
SLDO_IINA	0.702
SLDO_IIND	0.907
SLDO_IREF	3.6155180000000002
SLDO_ISHUNTA	0.09
SLDO_ISHUNTD	0.315
SLDO_LINEARITY	0.025
SLDO_NOM_INPUT_CURRENT	6.5
SLDO_VDDA	1.2
SLDO_VDDD	1.21
SLDO_VINA	1.444
SLDO_VINA_VIND	-0.01
SLDO_VIND	1.451
SLDO_VI_OFFSET	0.896
SLDO_VI_SLOPE	0.084
SLDO_VOFFS	0.961

Attachments

Filename	Contents
output.log	Download
