Database for ITk Pixel Module

Serial Number	20UPGFC0156300
ProdDB ID	249513…9a3af1
LocalDB ID	661469cb64ba440035c0ccd4
Component Type	fe_chip
Parents	20UPIM13602053 20UPGB43000051
Children	No match.
Flags

Item	Value
Wafer serial number	None

Key	Data
QC Passed	True
Date	8 months ago
component ObjectId	661469cb64ba440035c0ccd4
Stage	MODULE/INITIAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	AnnaRaquel Petri
ObjectId of this record	67fe88facdcf6da2aa9c462e
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.4.1
MEASUREMENT_DATE	2025-04-15T14:02:13.000+00:00
MEASUREMENT_DURATION	1169
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.4
TUNING_TUNED_NOISE_95_HIGH	63.506
TUNING_TUNED_NOISE_95_LOW	33.129
TUNING_TUNED_NOISE_MEAN	47.867
TUNING_TUNED_NOISE_SIGMA	8.476
TUNING_TUNED_TDAC_MEAN	-1.4
TUNING_TUNED_TDAC_SIGMA	3.3
TUNING_TUNED_THRESHOLD_95_HIGH	1559.145
TUNING_TUNED_THRESHOLD_95_LOW	1438.608
TUNING_TUNED_THRESHOLD_FAILED_FITS	43
TUNING_TUNED_THRESHOLD_MEAN	1499.3
TUNING_TUNED_THRESHOLD_SIGMA	32
TUNING_TUNED_TOT_95_HIGH	8.97
TUNING_TUNED_TOT_95_LOW	5
TUNING_TUNED_TOT_MEAN	6.6
TUNING_TUNED_TOT_SIGMA	0.2
TUNING_UNTUNED_NOISE_95_HIGH	83.04
TUNING_UNTUNED_NOISE_95_LOW	42.047
TUNING_UNTUNED_NOISE_MEAN	60.823
TUNING_UNTUNED_NOISE_SIGMA	11.298
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	3675.138
TUNING_UNTUNED_THRESHOLD_95_LOW	2037.361
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	493
TUNING_UNTUNED_THRESHOLD_MEAN	2761.089
TUNING_UNTUNED_THRESHOLD_SIGMA	415

Filename	Contents
0x2628c_L1_warm.json	Download
output.log	Download
0x2628c.log	Download
20UPGFC0156300_MODULE__INITIAL_WARM_TUNING.zip	Download
