Database for ITk Pixel Module

Serial Number	20UPGFC0156298
ProdDB ID	6a7bb7…52d43b
LocalDB ID	661469c8ec873d00355a586c
Component Type	fe_chip
Parents	20UPIM13602053 20UPGB43000051
Children	No match.
Flags

Item	Value
Wafer serial number	None

Key	Data
QC Passed	True
Date	8 months ago
component ObjectId	661469c8ec873d00355a586c
Stage	MODULE/INITIAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	AnnaRaquel Petri
ObjectId of this record	67fe88facdcf6da2aa9c4613
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.4.1
MEASUREMENT_DATE	2025-04-15T14:02:13.000+00:00
MEASUREMENT_DURATION	1169
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.4
TUNING_TUNED_NOISE_95_HIGH	63.449
TUNING_TUNED_NOISE_95_LOW	32.879
TUNING_TUNED_NOISE_MEAN	47.497
TUNING_TUNED_NOISE_SIGMA	8.375
TUNING_TUNED_TDAC_MEAN	-0.8
TUNING_TUNED_TDAC_SIGMA	3.486
TUNING_TUNED_THRESHOLD_95_HIGH	1557.336
TUNING_TUNED_THRESHOLD_95_LOW	1439.409
TUNING_TUNED_THRESHOLD_FAILED_FITS	4
TUNING_TUNED_THRESHOLD_MEAN	1499.2
TUNING_TUNED_THRESHOLD_SIGMA	31
TUNING_TUNED_TOT_95_HIGH	9
TUNING_TUNED_TOT_95_LOW	5
TUNING_TUNED_TOT_MEAN	6.7
TUNING_TUNED_TOT_SIGMA	0.2
TUNING_UNTUNED_NOISE_95_HIGH	83.759
TUNING_UNTUNED_NOISE_95_LOW	41.776
TUNING_UNTUNED_NOISE_MEAN	60.883
TUNING_UNTUNED_NOISE_SIGMA	11.389
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	3667.845
TUNING_UNTUNED_THRESHOLD_95_LOW	2029.922
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	423
TUNING_UNTUNED_THRESHOLD_MEAN	2750.94
TUNING_UNTUNED_THRESHOLD_SIGMA	416

Filename	Contents
0x2628a_L1_warm.json	Download
output.log	Download
0x2628a.log	Download
20UPGFC0156298_MODULE__INITIAL_WARM_TUNING.zip	Download

Expand ProductionDB Record

680a117ad10b377693782337

state

ready

stateTs

2025-04-24T10:24:58.554Z

stateUserIdentity

3182-7646-1

date

2025-04-15T16:27:00.000Z

testType

id	6393a09015838700361eecc5
code	TUNING
name	Tuning
state	active

institution

id	5d41d8ddf6e07b000a559aee
code	INFN_MILANO
name	INFN Milano

user

id	60e59f40049e18000a3aec94
userIdentity	3182-7646-1
firstName	Anna
middleName	Raquel
lastName	Petri

runNumber

67fe88facdcf6da2aa9c4613

passed

True

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	Tuning analysis version	string	None	True	2.4.1	None	None
MEASUREMENT_DATE	Date measurement performed	datetime	None	False	2025-04-15T14:02:13.000+00:00	None	None
MEASUREMENT_DURATION	Measurement duration	integer	None	False	1169	None	None
MEASUREMENT_VERSION	Measurement version	string	None	False	None	None	None
YARR_VERSION	Yarr Version	string	None	False	v1.5.4	None	None

results

code	name	dataType	valueType	arrayDimensions	additional	rangeMin	rangeMax	value	associateChild
TUNING_TUNED_NOISE_95_HIGH	Tuned noise 95% high	float	single	None	None	None	None	63.449	None
TUNING_TUNED_NOISE_95_LOW	Tuned noise 95% low	float	single	None	None	None	None	32.879	None
TUNING_TUNED_NOISE_MEAN	Tuned noise mean	float	single	None	None	None	None	47.497	None
TUNING_TUNED_NOISE_SIGMA	Tuned noise sigma	float	single	None	None	None	None	8.375	None
TUNING_TUNED_TDAC_MEAN	Tuned TDAC mean	float	single	None	None	None	None	-0.8	None
TUNING_TUNED_TDAC_SIGMA	Tuned TDAC sigma	float	single	None	None	None	None	3.486	None
TUNING_TUNED_THRESHOLD_95_HIGH	Tuned threshold 95% high	float	single	None	None	None	None	1557.336	None
TUNING_TUNED_THRESHOLD_95_LOW	Tuned threshold 95% low	float	single	None	None	None	None	1439.409	None
TUNING_TUNED_THRESHOLD_FAILED_FITS	Number of failed fits from the tuned threshold scan	integer	single	None	None	None	None	4	None
TUNING_TUNED_THRESHOLD_MEAN	Mean of the tuned threshold distribution	float	single	None	None	None	None	1499.2	None
TUNING_TUNED_THRESHOLD_SIGMA	Sigma of the tuned threshold distribution	float	single	None	None	None	None	31	None
TUNING_TUNED_TOT_95_HIGH	Tuned ToT 95% high	float	single	None	None	None	None	9	None
TUNING_TUNED_TOT_95_LOW	Tuned ToT 95% low	float	single	None	None	None	None	5	None
TUNING_TUNED_TOT_MEAN	Mean of tuned ToT distribution	float	single	None	None	None	None	6.7	None
TUNING_TUNED_TOT_SIGMA	Sigma of tuned ToT distribution	float	single	None	None	None	None	0.2	None
TUNING_UNTUNED_NOISE_95_HIGH	Untuned noise 95% high	float	single	None	None	None	None	83.759	None
TUNING_UNTUNED_NOISE_95_LOW	Noise 95% low	float	single	None	None	None	None	41.776	None
TUNING_UNTUNED_NOISE_MEAN	Untuned noise mean	float	single	None	None	None	None	60.883	None
TUNING_UNTUNED_NOISE_SIGMA	Untuned noise sigma	float	single	None	None	None	None	11.389	None
TUNING_UNTUNED_TDAC_MEAN	Untuned TDAC mean	float	single	None	None	None	None	0	None
TUNING_UNTUNED_TDAC_SIGMA	Untuned TDAC sigma	float	single	None	None	None	None	0	None
TUNING_UNTUNED_THRESHOLD_95_HIGH	Untuned threshold 95% high	float	single	None	None	None	None	3667.845	None
TUNING_UNTUNED_THRESHOLD_95_LOW	Untuned threshold 95% low	float	single	None	None	None	None	2029.922	None
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	Number of failed fits from the untuned threshold scan	integer	single	None	None	None	None	423	None
TUNING_UNTUNED_THRESHOLD_MEAN	Mean of the untuned threshold distribution	float	single	None	None	None	None	2750.94	None
TUNING_UNTUNED_THRESHOLD_SIGMA	Sigma of the untuned threshold distribution	float	single	None	None	None	None	416	None
