20UPGFC0146793

MODULE/UNHAPPY

Component Information

Serial Number	20UPGFC0146793
ProdDB ID	ab8af8…15da67
LocalDB ID	661003502fc9f2003515abd1
Component Type	fe_chip
Parents	20UPGM24211489 20UPGB43200370
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: MIN_HEALTH_TEST QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	5 months ago
component ObjectId	661003502fc9f2003515abd1
Stage	MODULE/POST_PARYLENE_WARM
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	69090e89963d030a15da1bd9
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
YARR_VERSION	v1.5.5
MEASUREMENT_DATE	2025-11-03T18:07:09.000+00:00
MEASUREMENT_DURATION	410
MIN_HEALTH_THRESHOLD_MEAN	1481.5
MIN_HEALTH_THRESHOLD_SIGMA	41.03
MIN_HEALTH_NOISE_MEAN	102.42
MIN_HEALTH_NOISE_SIGMA	10.99
MIN_HEALTH_TOT_MEAN	7.91
MIN_HEALTH_TOT_SIGMA	1.41
MIN_HEALTH_COLUMN_DISABLED	0
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_DEAD_ANALOG	0
MIN_HEALTH_BAD_ANALOG	0
MIN_HEALTH_THRESHOLD_FAILED_FITS	0
MIN_HEALTH_HIGH_ENC	0
MIN_HEALTH_BAD_ANALOG_INTEGRATED	0
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	0
MIN_HEALTH_HIGH_ENC_INDEPENDENT	0

Attachments
