Database for ITk Pixel Module

Serial Number	20UPGFC0146745
ProdDB ID	39715b…88bc4a
LocalDB ID	661002fe2fc9f2003515aaee
Component Type	fe_chip
Parents	20UPGM24210580 20UPGB43200367
Children	No match.
Flags

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Key	Data
QC Passed	True
Date	3 months ago
component ObjectId	661002fe2fc9f2003515aaee
Stage	MODULE/POST_PARYLENE_WARM
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	690b82504f9fcd332811990a
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-11-04T15:05:05.000+00:00
MEASUREMENT_DURATION	1547
YARR_VERSION	v1.5.5
MIN_HEALTH_BAD_ANALOG	0
MIN_HEALTH_BAD_ANALOG_INTEGRATED	3
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_COLUMN_DISABLED	0
MIN_HEALTH_DEAD_ANALOG	3
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_HIGH_ENC	0
MIN_HEALTH_HIGH_ENC_INDEPENDENT	0
MIN_HEALTH_NOISE_MEAN	27.84
MIN_HEALTH_NOISE_SIGMA	2.98
MIN_HEALTH_THRESHOLD_FAILED_FITS	361
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	364
MIN_HEALTH_THRESHOLD_MEAN	591.94
MIN_HEALTH_THRESHOLD_SIGMA	97.21
MIN_HEALTH_TOT_MEAN	15
MIN_HEALTH_TOT_SIGMA	0.08

Filename	Contents
output.log	Download
0x23d39.log	Download
20UPGFC0146745_MODULE__POST_PARYLENE_WARM_MIN-HEALTH-TEST.zip	Download

Expand ProductionDB Record

695ecc4f443fc79a1e2dacfe

state

ready

stateTs

2026-01-07T21:12:47.139Z

stateUserIdentity

4728-7541-1

date

2025-11-05T16:58:00.000Z

testType

id	6393a08a15838700361eec84
code	MIN_HEALTH_TEST
name	Minimal Health Test
state	active

institution

id	5d318624df98f200097386d5
code	ANL
name	Argonne National Laboratory

user

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

runNumber

690b82504f9fcd332811990a

passed

True

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	Min Health Test Analysis Version	string	None	True	2.6.4	None	None
MEASUREMENT_DATE	Date measurement performed	datetime	None	False	2025-11-04T15:05:05.000+00:00	None	None
MEASUREMENT_DURATION	Measurement duration	integer	None	False	1547	None	None
YARR_VERSION	Yarr Version	string	None	False	v1.5.5	None	None

results

code MIN_HEALTH_BAD_ANALOG
name Number of bad pixels from analog scan
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0
associateChild None
code MIN_HEALTH_BAD_ANALOG_INTEGRATED
name MIN_HEALTH_BAD_ANALOG_INTEGRATED
order 16
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 3
associateChild None
code MIN_HEALTH_BAD_DIGITAL
name Number of bad pixels from digital scan
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0
associateChild None
code MIN_HEALTH_COLUMN_DISABLED
name Number of pixels in disabled core columns
order 1
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0
associateChild None
code MIN_HEALTH_DEAD_ANALOG
name Number of dead pixels from analog scan
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 3
associateChild None
code MIN_HEALTH_DEAD_DIGITAL
name Number of dead pixels from digital scan
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0
associateChild None
code MIN_HEALTH_HIGH_ENC
name Number of pixels with High ENC
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0
associateChild None
code MIN_HEALTH_HIGH_ENC_INDEPENDENT
name Number of pixels with High ENC
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0
associateChild None
code MIN_HEALTH_NOISE_MEAN
name Noise mean
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 27.84
associateChild None
code MIN_HEALTH_NOISE_SIGMA
name Noise sigma
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 2.98
associateChild None
code MIN_HEALTH_THRESHOLD_FAILED_FITS
name Number of failed fits from threshold scan
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 361
associateChild None

code	MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT
name	Number of failed fits from threshold scan
dataType	integer
valueType	single
arrayDimensions	None
additional	None
rangeMin	None
rangeMax	None
value	364
associateChild	None

code MIN_HEALTH_THRESHOLD_MEAN
name Mean of threshold distribution
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 591.94
associateChild None
code MIN_HEALTH_THRESHOLD_SIGMA
name Sigma of threshold distribution
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 97.21
associateChild None
code MIN_HEALTH_TOT_MEAN
name Mean of ToT distribution
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 15
associateChild None
code MIN_HEALTH_TOT_SIGMA
name Sigma of ToT distribution
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0.08
associateChild None

cts

2026-01-07T21:12:47.139Z

sys

cts	2026-01-07T21:12:47.139Z
mts	2026-01-07T21:12:47.790Z
rev	1

defects

comments

None

attachments

code

dateTime

title

description

contentType

type

url

urlCernbox

filename

user

e6a84bed6a1087e0cc44143ab14a7d7a

2026-01-07T21:12:47.790Z

TestRun_695ecc4f443fc79a1e2dacfe_Attachment_Pack.zip

/home/data/viewer/static/cache/thumbnail/TestRun_695ecc4f443fc79a1e2dacfe_Attachment_Pack.zip

None

eos

https://eosatlas.cern.ch/eos/atlas/atlascerngroupdisk/det-itk/prod-db/e/6/a/e6a84bed6a1087e0cc44143ab14a7d7a?authz=zteos64:MDAwMDAyZjd4nO1RsUrEUBDkBC2sRAvBQha1sMklm0tekhXBWr1Gz-q4YpP37gyneSF5B3Kl2PkNNhaCpd-glSAoaGOjFv6AtiJGsbCwtnKLKWZnlxlm_HlkvFZMnB8cXY3NjKamn8u5kWG-WHNbttKlzWaHvzFRRdYr9CCXadm3pTJWJbfzQktLxrayhc22Ehx6sZKC0QkD5SSJ56HX4Bg9DmTAqwuShYh9xRYGjcRC7KLFXhx_QtfBIPKlG21c19qtgYImFwANcJGciNAH13FFBwapJPRQhNj-8tuB3ifTcIL2MO-ASaXKDBVam3rkChH61a5Sr7SJutWQj3VEUY_COjodyHhX0dcfkBlBFcdQv4h94Dwn2Nalod8Ppd7lNKMfTE9pgnIgNTlgCk4Ugc5itc07XZqEh9rh_frb1nTz6PF4bf_yffNluTzd35tdmnq6nT87uZj5b-JPmoCbu9fJD6qM7hE%3d

https://cernbox.cern.ch/files/spaces/eos/atlas/atlascerngroupdisk/det-itk/prod-db/e/6/a/e6a84bed6a1087e0cc44143ab14a7d7a

e6a84bed6a1087e0cc44143ab14a7d7a

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

components

code

state

stateTs

stateUserIdentity

dummy

completed

completedTs

completedUserIdentity

trashed

trashedTs

trashedUserIdentity

serialNumber

alternativeIdentifier

ancestorMap

project

subproject

componentType

type

properties

testedAtStage

institution

661002fe2fc9f2003515aaee

39715ba237e6e512d68a2fc55288bc4a

ready

2024-04-05T13:56:14.518Z

5310-2637-1

False

None

False

None

20UPGFC0146745

None

parent

component

6810f23ea61e7625af0608b6

code

7a90d45988477ed61ba93d41456e6358

state

ready

stateTs

2025-04-29T15:37:34.558Z

stateUserIdentity

23-6780-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGB43200367

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	BARE_MODULE
name	Bare Module

type

code	QUAD_BARE_MODULE
name	Quad bare module

testedAtStage

code	MODULE/WIREBOND_PROTECTION
name	Wirebond Protection (alt)

highestLevelParent

component

689ce5b7e945399df1ed7ade

code

7597d42fb96e97ed06bdc49ec535251d

state

ready

stateTs

2025-08-13T19:21:27.142Z

stateUserIdentity

1294-8027-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGM24210580

alternativeIdentifier

ANL_ITkPix_129

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	MODULE
name	Module

type

code	OUTER_SYSTEM_QUAD_MODULE
name	Outer system quad module

testedAtStage

code	MODULE/WIREBOND_PROTECTION
name	Wirebond Protection (alt)

code	P
name	Pixels

code	PG
name	Pixel general

code	FE_CHIP
name	Front-end Chip

code	ITKPIX_V2
name	ITkpix_V2

None

code	MODULE/POST_PARYLENE_WARM
name	Post-Parylene Warm
order	15
initial	False
final	False

code	GL
name	Glasgow University

Past QC Stages and Results

Post-Parylene Cold (MODULE/POST_PARYLENE_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Cold (MODULE/INITIAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Warm (MODULE/INITIAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wire Bonding (MODULE/WIREBONDING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Test	Local Result	ProdDB Record
Analog Readback (ANALOG_READBACK)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

Test	Local Result	ProdDB Record
Electrical FE chip tests (FECHIP_TEST)	Registered	Registered

LocalDB Test ID	Stage	Test Name	Inspector	Measurement Date	Analysis Date	Tags	QC Registration
69052c…bae5db	MODULE/POST_PARYLENE_WARM	LP_MODE	DanielAceves	6 months ago	3 months ago	No tags	Selected
690b82…119ad1	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	DanielAceves	N/A	3 months ago	No tags	Selected
690b82…1199d8	MODULE/POST_PARYLENE_WARM	TUNING	DanielAceves	N/A	3 months ago	No tags	Selected
690b82…11990a	MODULE/POST_PARYLENE_WARM	MIN_HEALTH_TEST	DanielAceves	N/A	3 months ago	No tags	Selected
69052b…bae5b0	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	DanielAceves	6 months ago	3 months ago	No tags	Selected
69052a…bae55f	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	DanielAceves	6 months ago	3 months ago	No tags	Selected
69052a…bae51e	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	DanielAceves	6 months ago	3 months ago	No tags	Selected
690529…bae4bd	MODULE/POST_PARYLENE_WARM	SLDO	DanielAceves	6 months ago	3 months ago	No tags	Selected
690527…bae34d	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	DanielAceves	6 months ago	3 months ago	No tags	Selected
69051f…badd24	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	DanielAceves	6 months ago	3 months ago	No tags	Selected
68e015…91120b	MODULE/INITIAL_WARM	PIXEL_FAILURE_ANALYSIS	DanielAceves	N/A	6 months ago	No tags	Selected
68e015…911168	MODULE/INITIAL_WARM	TUNING	DanielAceves	N/A	6 months ago	No tags	Selected
68e015…91106a	MODULE/INITIAL_WARM	MIN_HEALTH_TEST	DanielAceves	N/A	6 months ago	No tags	Selected
68e00a…910f89	MODULE/INITIAL_WARM	INJECTION_CAPACITANCE	DanielAceves	6 months ago	6 months ago	No tags	Selected
68e009…910f55	MODULE/INITIAL_WARM	DATA_TRANSMISSION	DanielAceves	6 months ago	6 months ago	No tags	Selected
68e00b…910fad	MODULE/INITIAL_WARM	LP_MODE	DanielAceves	6 months ago	6 months ago	No tags	Selected
68e009…910f31	MODULE/INITIAL_WARM	VCAL_CALIBRATION	DanielAceves	6 months ago	6 months ago	No tags	Selected
68e008…910eed	MODULE/INITIAL_WARM	SLDO	DanielAceves	6 months ago	6 months ago	No tags	Selected
68e005…910eb9	MODULE/INITIAL_WARM	ANALOG_READBACK	DanielAceves	6 months ago	6 months ago	No tags	Selected
68dffd…910e25	MODULE/INITIAL_WARM	ADC_CALIBRATION	DanielAceves	6 months ago	6 months ago	No tags	Selected
661004…15b25d	TESTONWAFER	FECHIP_TEST	DimaManeuski	N/A	a year ago	No tags	Selected

Stage	Tests
TESTONWAFER	Electrical FE chip tests (FECHIP_TEST)
HYBRIDISATION
UNUSABLE
BAREMODULEASSEMBLY
BAREMODULERECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK)
MODULE/INIT
MODULE/ASSEMBLY
MODULE/WIREBONDING	ADC Calibration (ADC_CALIBRATION) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO) Low Power Mode (LP_MODE) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/INITIAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/QC_CROSSCHECK	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/INITIAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_MASKING	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Low Power Mode (LP_MODE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_COATING
MODULE/PARYLENE_UNMASKING	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE)
MODULE/WIREBOND_PROTECTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) Low Power Mode (LP_MODE) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/POST_PARYLENE_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE)
MODULE/POST_PARYLENE_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/THERMAL_CYCLES	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Cold startup (COLD_STARTUP)
MODULE/LONG_TERM_STABILITY_TEST	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Undershunt Protection (UNDERSHUNT_PROTECTION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Data Transmission (DATA_TRANSMISSION) Cold startup (COLD_STARTUP)
MODULE/FINAL_METROLOGY	Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE) Analog Readback (ANALOG_READBACK)
MODULE/QC_STATUS
MODULE/UNHAPPY	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/NOTCONSIDEREDINYIELDS	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Undershunt Protection (UNDERSHUNT_PROTECTION) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/GRAVEYARD
MODULE/COMPLETE
MODULE/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION) Tuning (TUNING)
MODULE/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
LLS/PRE_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Low Power Mode (LP_MODE) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/PRE_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/INIT
OB_LOADED_MODULE_CELL/ASSEMBLY
OB_LOADED_MODULE_CELL/WIREBOND_PROTECTION
OB_LOADED_MODULE_CELL/THERMAL_CYCLES
OB_LOADED_MODULE_CELL/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/THERMAL_COLD
OB_LOADED_MODULE_CELL/THERMAL_WARM
OB_LOADED_MODULE_CELL/ENVELOPE_CHECK
OB_LOADED_MODULE_CELL/QC_STATUS
OB_LOADED_MODULE_CELL/UNHAPPY
OB_LOADED_MODULE_CELL/COMPLETE
OB_LOADED_MODULE_CELL/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO)
OB_LOADED_MODULE_CELL/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
OB_LOADED_MODULE_CELL/PIGTAIL_INSERTION
TEST_AFTER_LOADED_LOCAL_SUPPORT_ASSEMBLY	OB:Loaded local support QC electrical connectivity (OBLoadedLocalSupportQC_ElectricalConnectivity) OB:Loaded local support QC electrical performance (OBLoadedLocalSupportQC_ElectricalPerformance) OB:Loaded local support reception at the integration site (OBLoadedLocalSupport_IntegrationSite) OB:Loaded local support QC electrical low power (OBLoadedLocalSupport_QCElectricalLowPower)
TEST_JM_OEC_FE

20UPGFC0146745

MODULE/THERMAL_CYCLES

Component Information

Wafer

Properties

Comments

Test: MIN_HEALTH_TEST QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Results

Attachments

ProductionDB Record

Current Stage: Thermal Cycles

Candidate TestRuns of this Stage

Past QC Stages and Results

Post-Parylene Cold (MODULE/POST_PARYLENE_COLD)

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Initial Cold (MODULE/INITIAL_COLD)

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Initial Warm (MODULE/INITIAL_WARM)

Wire Bonding (MODULE/WIREBONDING)

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

All Registered QC Tests

Check QC Flow

Back to top page of this component

Test Type	Local Result
Minimal Health Test (MIN_HEALTH_TEST)	No TestRun!
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No TestRun!
Tuning (TUNING)	No TestRun!
Data Transmission (DATA_TRANSMISSION)	No TestRun!
SLDO (SLDO)	No TestRun!
ADC Calibration (ADC_CALIBRATION)	No TestRun!
VCAL Calibration (VCAL_CALIBRATION)	No TestRun!
Analog Readback (ANALOG_READBACK)	No TestRun!
Injection Capacitance (INJECTION_CAPACITANCE)	No TestRun!
Low Power Mode (LP_MODE)	No TestRun!
Cold startup (COLD_STARTUP)	No TestRun!

LDB ID	TestRun Code	QC Passed	Inspector	Measurement Date	Analysis Date	Analysis Version	Tags	QC Registration
69052c…bae5db	LP_MODE	Fail	DanielAceves	6 months ago	3 months ago	2.6.4	No tags	Selected
690b82…119ad1	PIXEL_FAILURE_ANALYSIS	Fail	DanielAceves	N/A	3 months ago	2.6.4	No tags	Selected
690b82…1199d8	TUNING	Fail	DanielAceves	N/A	3 months ago	2.6.4	No tags	Selected
690b82…11990a	MIN_HEALTH_TEST	Pass	DanielAceves	N/A	3 months ago	2.6.4	No tags	Selected
69052b…bae5b0	INJECTION_CAPACITANCE	Fail	DanielAceves	6 months ago	3 months ago	2.6.4	No tags	Selected
69052a…bae55f	DATA_TRANSMISSION	Pass	DanielAceves	6 months ago	3 months ago	2.6.4	No tags	Selected
69052a…bae51e	VCAL_CALIBRATION	Fail	DanielAceves	6 months ago	3 months ago	2.6.4	No tags	Selected
690529…bae4bd	SLDO	Fail	DanielAceves	6 months ago	3 months ago	2.6.4	No tags	Selected
690527…bae34d	ANALOG_READBACK	Fail	DanielAceves	6 months ago	3 months ago	2.6.4	No tags	Selected
69051f…badd24	ADC_CALIBRATION	Fail	DanielAceves	6 months ago	3 months ago	2.6.4	No tags	Selected
