20UPGFC0146087

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number 20UPGFC0146087
ProdDB ID  aad1cc…2001ef
LocalDB ID 660fbe902fc9f20035147e4b
Component Type fe_chip
Parents 20UPGM24211640  20UPGB43200440 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 9
Target Iref trim version 1
Wafer serial number None

 Comments


Test: TUNING QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 3 weeks ago
component ObjectId 660fbe902fc9f20035147e4b
Stage MODULE/POST_PARYLENE_WARM
Test Type TUNING
Institute ObjectId
User Name DanielAceves
ObjectId of this record 69ab28f2c1ad7885109219e8
ObjectId of RAW record None
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.8.0rc1
MEASUREMENT_DATE 2026-03-06T18:38:37.000+00:00
MEASUREMENT_DURATION 647
YARR_VERSION v1.5.5
TUNING_TUNED_NOISE_95_HIGH 123.286
TUNING_TUNED_NOISE_95_LOW 36.901
TUNING_TUNED_NOISE_MEAN 94.514
TUNING_TUNED_NOISE_SIGMA 23.277
TUNING_TUNED_TDAC_MEAN -1.2
TUNING_TUNED_TDAC_SIGMA 4.704
TUNING_TUNED_THRESHOLD_95_HIGH 1566.394
TUNING_TUNED_THRESHOLD_95_LOW 1437.945
TUNING_TUNED_THRESHOLD_FAILED_FITS 3077
TUNING_TUNED_THRESHOLD_MEAN 1504.1
TUNING_TUNED_THRESHOLD_SIGMA 34
TUNING_TUNED_TOT_95_HIGH 10.23
TUNING_TUNED_TOT_95_LOW 4.86
TUNING_TUNED_TOT_MEAN 7.2
TUNING_TUNED_TOT_SIGMA 0.3
TUNING_UNTUNED_NOISE_95_HIGH 119.907
TUNING_UNTUNED_NOISE_95_LOW 31.906
TUNING_UNTUNED_NOISE_MEAN 91.614
TUNING_UNTUNED_NOISE_SIGMA 23.944
TUNING_UNTUNED_TDAC_MEAN 0
TUNING_UNTUNED_TDAC_SIGMA 0
TUNING_UNTUNED_THRESHOLD_95_HIGH 2656.881
TUNING_UNTUNED_THRESHOLD_95_LOW 1441.37
TUNING_UNTUNED_THRESHOLD_FAILED_FITS 3197
TUNING_UNTUNED_THRESHOLD_MEAN 2029.435
TUNING_UNTUNED_THRESHOLD_SIGMA 310.48

Attachments

Filename Contents
0x23aa7_L2_warm.json Download
output.log Download
0x23aa7.log Download
20UPGFC0146087_MODULE__POST_PARYLENE_WARM_TUNING.zip Download
