20UPGFC0146073

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number	20UPGFC0146073
ProdDB ID	ec360c…7ad618
LocalDB ID	660fbe6eec873d00354e2282
Component Type	fe_chip
Parents	20UPGM24211640 20UPGB43200440
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	5
Target Iref trim version	1
Wafer serial number	None

Comments

Test: SLDO QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	3 weeks ago
component ObjectId	660fbe6eec873d00354e2282
Stage	MODULE/POST_PARYLENE_WARM
Test Type	SLDO
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	69ab2856c1ad788510921768
ObjectId of RAW record	69ab2853c1ad78851092175d
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.8.0rc1
MEASUREMENT_DATE	2026-03-06T18:10:42.000+00:00
MEASUREMENT_DURATION	600
MEASUREMENT_VERSION	2.7.1
YARR_VERSION	v1.5.5
SLDO_ANALOG_OVERHEAD	0.09
SLDO_D_MIN_IIN	5.167
SLDO_A_MIN_IIN	5.832
SLDO_D_SLOPE	0.143
SLDO_A_SLOPE	0.109
SLDO_D_OFFSET	-0.614
SLDO_A_OFFSET	-0.63
SLDO_D_CHI2	0
SLDO_A_CHI2	0
SLDO_CORE_COL_DISABLED	0
SLDO_DIGITAL_OVERHEAD	0.451
SLDO_IINA	0.65
SLDO_IIND	0.909
SLDO_IREF	3.8921140000000003
SLDO_ISHUNTA	0.053
SLDO_ISHUNTD	0.283
SLDO_LINEARITY	0.011
SLDO_NOM_INPUT_CURRENT	6.25
SLDO_VDDA	1.21
SLDO_VDDD	1.19
SLDO_VINA	1.514
SLDO_VINA_VIND	-0.01
SLDO_VIND	1.52
SLDO_VI_OFFSET	0.983
SLDO_VI_SLOPE	0.085
SLDO_VOFFS	0.991

Attachments

Filename	Contents
output.log	Download

RAW Results Record

Download RAW

_id

69ab2853c1ad78851092175d

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0146073

SLDO

69ab1af9af3c76eec3196bc3

DCSdata

SensorVoltage	-120.0
SensorCurrent	4.49e-07
ModuleNTC	20.03

Measurements

Temperature

X	False
Unit	C
Values	20.03 20.0 19.97 20.0 20.06 20.06 19.97 19.88 20.12 19.91

SetCurrent

X	False
Unit	A
Values	7.6 7.433333333333333 7.266666666666666 7.1 6.933333333333333 6.766666666666667 6.6 6.433333333333333 6.266666666666667 6.1

Current

X	True
Unit	A
Values	7.599 7.432 7.265 7.098 6.93 6.764 6.601 6.434 6.265 6.1

Vmux30

X	False
Unit	V
Values	0.02074308 0.02013205 0.0197027 0.01927119 0.01883718 0.01840621 0.01797508 0.01752921 0.01711173 0.01670333

Vmux33

X	False
Unit	V
Values	0.4274385 0.4234656 0.4194292 0.4155628 0.4116793 0.4076312 0.4036887 0.3997437 0.3956892 0.3915483

Vmux37

X	False
Unit	V
Values	0.4291285 0.4251114 0.4211512 0.4170983 0.4132063 0.4092022 0.4052149 0.401147 0.3972126 0.3930188

Vmux34

X	False
Unit	V
Values	0.6228994 0.6229579 0.6218903 0.6218512 0.6218145 0.6209575 0.6210852 0.6205174 0.620732 0.6199969

Vmux38

X	False
Unit	V
Values	0.6181284 0.6178257 0.617326 0.616568 0.6161086 0.615464 0.6155289 0.6145336 0.6141115 0.6133733

Vmux36

X	False
Unit	V
Values	0.2686615 0.2681351 0.267667 0.2671731 0.2667413 0.2662859 0.2658256 0.2653018 0.2648195 0.2643619

Vmux32

X	False
Unit	V
Values	0.6278863 0.6275061 0.627184 0.6268204 0.6265562 0.626344 0.6260089 0.6256359 0.6252724 0.6250746

Imux0

X	False
Unit	V
Values	0.05692091 0.0564785 0.05607869 0.05566601 0.05526201 0.05484397 0.05444576 0.05401298 0.05364596 0.05321196

Imux28

X	False
Unit	V
Values	0.3891288 0.3805687 0.372082 0.3636681 0.3550589 0.346542 0.3379112 0.3293131 0.320692 0.3121148

Imux29

X	False
Unit	V
Values	0.1086748 0.09986187 0.09104003 0.082815 0.0738831 0.06528954 0.05665777 0.0477959 0.03917778 0.03085232

Imux30

X	False
Unit	V
Values	0.5441404 0.5324296 0.5206461 0.5089137 0.4970147 0.4850546 0.473053 0.4610669 0.4489436 0.4365655

Imux31

X	False
Unit	V
Values	0.238232 0.2267013 0.2152969 0.2034295 0.1923069 0.1804239 0.1689251 0.1573481 0.145966 0.1342988

Imux63

X	False
Unit	V
Values	0.01805184 0.01763129 0.0172081 0.01679737 0.01638391 0.01596135 0.01554593 0.01511804 0.01472482 0.01430221

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	2
DataMergeOutMux1	3
DataMergeOutMux2	0
DataMergeOutMux3	1
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	253
DiffTh1M	253
DiffTh1R	253
DiffTh2	50
DiffVff	92
EfuseConfig	3855
EfuseReadData0	39187
EfuseReadData1	8762
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	431
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	40229
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	1
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	8
SldoTrimD	7
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	5.0 0.19 10000.0
ChipId	12
EnforceNameIdCheck	True
InjCap	6.93
IrefTrim	4
KSenseInA	21244.234
KSenseInD	20931.805
KSenseShuntA	21851.0
KSenseShuntD	21530.0
KShuntA	1001.906
KShuntD	971.102
Name	0x23a99
NfACB	1.2581841
NfASLDO	1.2595696
NfDSLDO	1.2587698
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-5.0 0.2

SoftwareType

ChipID

Name

0x23a99

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24211640

AverageTemperature

20.0

BOMCode

TimeStart

1772820642

TimeEnd

1772821242

comment

property

YARR_VERSION	v1.5.5
SLDO_MEASUREMENT_VERSION	2.7.1

MODULE/POST_PARYLENE_WARM

660fbe6eec873d00354e2282

1.01

64657cef8d79bac1f3f00578

mts	2026-03-06 19:17:39.249000
cts	2026-03-06 19:17:39.249000
rev	0

rawHash

f3df880a072892003416a499757e8e4c

stage

MODULE/POST_PARYLENE_WARM

ProductionDB Record

Expand ProductionDB Record

69ab2a09f29e2a5bf96037c4

state

ready

stateTs

2026-03-06T19:24:57.906Z

stateUserIdentity

4728-7541-1

date

2026-03-06T19:17:00.000Z

testType

id	6393a07115838700361eeb71
code	SLDO
name	SLDO
state	active

institution

id	5d318624df98f200097386d5
code	ANL
name	Argonne National Laboratory

user

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

runNumber

69ab2856c1ad788510921768

passed

True

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	SLDO Analysis Version	string	None	True	2.8.0rc1	None	None
MEASUREMENT_DATE	Date measurement performed	datetime	None	False	2026-03-06T18:10:42.000+00:00	None	None
MEASUREMENT_DURATION	Measurement duration	integer	None	False	600	None	None
MEASUREMENT_VERSION	Measurement version	string	None	False	2.7.1	None	None
YARR_VERSION	Yarr Version	string	None	False	v1.5.5	None	None

results

code SLDO_ANALOG_OVERHEAD
name Analog Overhead
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0.09
associateChild None
code SLDO_D_MIN_IIN
name SLDO D min input current
order 18
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 5.167
associateChild None
code SLDO_A_MIN_IIN
name SLDO A min input current
order 19
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 5.832
associateChild None
code SLDO_D_SLOPE
name SLDO D slope
order 20
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.143
associateChild None
code SLDO_A_SLOPE
name SLDO A slope
order 21
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.109
associateChild None
code SLDO_D_OFFSET
name SLDO D offset
order 22
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value -0.614
associateChild None
code SLDO_A_OFFSET
name SLDO A offset
order 23
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value -0.63
associateChild None
code SLDO_D_CHI2
name SLDO D chi square
order 24
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0
associateChild None
code SLDO_A_CHI2
name SLDO A chi square
order 25
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0
associateChild None
code SLDO_CORE_COL_DISABLED
name Core col disabled
order 26
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0
associateChild None
code SLDO_DIGITAL_OVERHEAD
name Digital Overhead
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0.451
associateChild None
code SLDO_IINA
name IinA
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0.65
associateChild None
code SLDO_IIND
name IinD
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0.909
associateChild None
code SLDO_IREF
name Iref
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 3.8921140000000003
associateChild None
code SLDO_ISHUNTA
name IshuntA
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0.053
associateChild None
code SLDO_ISHUNTD
name IshuntD
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.283
associateChild None
code SLDO_LINEARITY
name SLDO Linearity
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.011
associateChild None
code SLDO_NOM_INPUT_CURRENT
name Nominal Input Current
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 6.25
associateChild None
code SLDO_VDDA
name VDDA
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.21
associateChild None
code SLDO_VDDD
name VDDD
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.19
associateChild None
code SLDO_VINA
name VinA
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.514
associateChild None
code SLDO_VINA_VIND
name SLDO VinA VinD
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value -0.01
associateChild None
code SLDO_VIND
name VinD
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.52
associateChild None
code SLDO_VI_OFFSET
name SLDO VI Offset
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0.983
associateChild None
code SLDO_VI_SLOPE
name SLDO VI Slope
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0.085
associateChild None
code SLDO_VOFFS
name Voffs
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 0.991
associateChild None

cts

2026-03-06T19:24:57.906Z

sys

cts	2026-03-06T19:24:57.906Z
mts	2026-03-06T19:25:05.149Z
rev	2

defects

comments

None

attachments

code

eb69a8fc4212d042d8ed632058d814fc

dateTime

2026-03-06T19:24:58.208Z

title

TestRun_69ab2a09f29e2a5bf96037c4_Attachment_Pack.zip

description

/home/data/viewer/static/cache/thumbnail/TestRun_69ab2a09f29e2a5bf96037c4_Attachment_Pack.zip

contentType

None

type

eos

url

https://eosatlas.cern.ch/eos/atlas/atlascerngroupdisk/det-itk/prod-db/e/b/6/eb69a8fc4212d042d8ed632058d814fc?authz=zteos64:MDAwMDAyZjh4nO2Rr0sEURDHuRMNgiAGg5ZBDBr2duftj9sdEMSoWETTceHtzttzOd237L0rCiaj6Ti4qE2LTWyC_4AgWEyCgslmFzwPg8FscsKED9_5Ml--k6_VyUo5fd5_vpuYG89Mu-CF6kGxVBHbttIdW5o9-b0TVeatUncLzjptm5WxhnK7KDVbHNvKju3AVnEQyTBNPIGCHU9wqDhwheOHHKKXJuuLYcLsh46wBAauhZiiFfupa0kvTh2sRz6LaOu-0tjUOWzKEjAAjAiRRB2EI4ImdDMm9DAIsTH6twmtL-I69cZB0QSTscoNlVqbmod-5HsuCQ_rqw2idDjkYw0xqEVhDZ0m5HJf0cgHOCcYxjHULmMfZFEQ7OqOod8PWe_LLKcfpKU0QafLmhwwpUwUgc5jtSv3UpqB5Y2Lq9mH_tn1zsrguTI1f_S2cPmx9n7cO3x5Goz1Tuf-m_iTJuDx5vZk4hMviOwv

urlCernbox

https://cernbox.cern.ch/files/spaces/eos/atlas/atlascerngroupdisk/det-itk/prod-db/e/b/6/eb69a8fc4212d042d8ed632058d814fc

filename

eb69a8fc4212d042d8ed632058d814fc

user

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

code

676b34d50c76243b1a441d7dfc4def36

dateTime

2026-03-06T19:25:05.085Z

title

RAW

description

RAW

contentType

text/plain

type

file

binaryStoreg02

True

filename

data

user

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

components

code

state

stateTs

stateUserIdentity

dummy

completed

completedTs

completedUserIdentity

trashed

trashedTs

trashedUserIdentity

serialNumber

alternativeIdentifier

ancestorMap

project

subproject

componentType

type

properties

testedAtStage

institution

660fbe6eec873d00354e2282

ec360c34749304490171db891f7ad618

ready

2024-04-05T09:03:42.647Z

5310-2637-1

False

None

False

None

20UPGFC0146073

None

parent

component

683ecb8a6945881eaa97e1cf

code

08ee8f2e83f7b663c4591c7a4e56d406

state

ready

stateTs

2025-06-03T10:16:42.834Z

stateUserIdentity

23-6780-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGB43200440

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	BARE_MODULE
name	Bare Module

type

code	QUAD_BARE_MODULE
name	Quad bare module

testedAtStage

code	MODULE/PARYLENE_UNMASKING
name	Parylene Unmasking

highestLevelParent

component

689ce97f328b0ce1c715da7c

code

791fe0a930b5cd616a1dd9604d399d16

state

ready

stateTs

2025-08-13T19:37:35.936Z

stateUserIdentity

1294-8027-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGM24211640

alternativeIdentifier

ANL_ITkPix_139

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	MODULE
name	Module

type

code	OUTER_SYSTEM_QUAD_MODULE
name	Outer system quad module

testedAtStage

code	MODULE/PARYLENE_UNMASKING
name	Parylene Unmasking

code	P
name	Pixels

code	PG
name	Pixel general

code	FE_CHIP
name	Front-end Chip

code	ITKPIX_V2
name	ITkpix_V2

code	name	dataType	required	default	value
TARGET_IREF_TRIM	Target Iref trim	integer	False	False	5
TARGET_IREF_TRIM_VERSION	Target Iref trim version	string	False	False	1

code	MODULE/POST_PARYLENE_WARM
name	Post-Parylene Warm
order	15
initial	False
final	False

code	GL
name	Glasgow University

Current Stage: Post-Parylene Cold

Test Type	Local Result
ADC Calibration (ADC_CALIBRATION)	No TestRun!
Analog Readback (ANALOG_READBACK)	No TestRun!
VCAL Calibration (VCAL_CALIBRATION)	No TestRun!
Low Power Mode (LP_MODE)	No TestRun!
Data Transmission (DATA_TRANSMISSION)	No TestRun!
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No TestRun!
Undershunt Protection (UNDERSHUNT_PROTECTION)	No TestRun!
SLDO (SLDO)	No TestRun!
Minimal Health Test (MIN_HEALTH_TEST)	No TestRun!
Tuning (TUNING)	No TestRun!
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No TestRun!
Injection Capacitance (INJECTION_CAPACITANCE)	No TestRun!

Candidate TestRuns of this Stage

LDB ID	TestRun Code	QC Passed	Inspector	Measurement Date	Analysis Date	Analysis Version	Tags	QC Registration
69ab28…9218a4	LP_MODE	Pass	DanielAceves	3 weeks ago	3 weeks ago	2.8.0rc1	No tags	Selected
69ab29…921a69	PIXEL_FAILURE_ANALYSIS	Pass	DanielAceves	N/A	3 weeks ago	2.8.0rc1	No tags	Selected
69ab28…921975	TUNING	Pass	DanielAceves	N/A	3 weeks ago	2.8.0rc1	No tags	Selected
69ab28…921930	MIN_HEALTH_TEST	Pass	DanielAceves	N/A	3 weeks ago	2.8.0rc1	No tags	Selected
69ab28…921858	INJECTION_CAPACITANCE	Pass	DanielAceves	3 weeks ago	3 weeks ago	2.8.0rc1	No tags	Selected
69ab28…921814	DATA_TRANSMISSION	Pass	DanielAceves	3 weeks ago	3 weeks ago	2.8.0rc1	No tags	Selected
69ab28…9217bc	VCAL_CALIBRATION	Pass	DanielAceves	3 weeks ago	3 weeks ago	2.8.0rc1	No tags	Selected
69ab28…921768	SLDO	Pass	DanielAceves	3 weeks ago	3 weeks ago	2.8.0rc1	No tags	Selected
69ab28…9216d0	ANALOG_READBACK	Pass	DanielAceves	3 weeks ago	3 weeks ago	2.8.0rc1	No tags	Selected
69ab28…921674	ADC_CALIBRATION	Pass	DanielAceves	3 weeks ago	3 weeks ago	2.8.0rc1	No tags	Selected

Past QC Stages and Results

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Cold (MODULE/INITIAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Warm (MODULE/INITIAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wire Bonding (MODULE/WIREBONDING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Test	Local Result	ProdDB Record
Analog Readback (ANALOG_READBACK)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

Test	Local Result	ProdDB Record
Electrical FE chip tests (FECHIP_TEST)	Registered	Registered

LocalDB Test ID	Stage	Test Name	Inspector	Measurement Date	Analysis Date	Tags	QC Registration
69ab28…9218a4	MODULE/POST_PARYLENE_WARM	LP_MODE	DanielAceves	3 weeks ago	3 weeks ago	No tags	Selected
69ab29…921a69	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	DanielAceves	N/A	3 weeks ago	No tags	Selected
69ab28…921975	MODULE/POST_PARYLENE_WARM	TUNING	DanielAceves	N/A	3 weeks ago	No tags	Selected
69ab28…921930	MODULE/POST_PARYLENE_WARM	MIN_HEALTH_TEST	DanielAceves	N/A	3 weeks ago	No tags	Selected
69ab28…921858	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	DanielAceves	3 weeks ago	3 weeks ago	No tags	Selected
69ab28…921814	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	DanielAceves	3 weeks ago	3 weeks ago	No tags	Selected
69ab28…9217bc	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	DanielAceves	3 weeks ago	3 weeks ago	No tags	Selected
69ab28…921768	MODULE/POST_PARYLENE_WARM	SLDO	DanielAceves	3 weeks ago	3 weeks ago	No tags	Selected
69ab28…9216d0	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	DanielAceves	3 weeks ago	3 weeks ago	No tags	Selected
69ab28…921674	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	DanielAceves	3 weeks ago	3 weeks ago	No tags	Selected
68e7f9…914300	MODULE/INITIAL_WARM	PIXEL_FAILURE_ANALYSIS	Simpson,Liana Rae	N/A	6 months ago	No tags	Selected
68e7e9…91414c	MODULE/INITIAL_WARM	TUNING	Simpson,Liana Rae	N/A	6 months ago	No tags	Selected
68e7e9…914095	MODULE/INITIAL_WARM	MIN_HEALTH_TEST	Simpson,Liana Rae	N/A	6 months ago	No tags	Selected
68e587…912a27	MODULE/INITIAL_WARM	INJECTION_CAPACITANCE	Simpson,Liana Rae	6 months ago	6 months ago	No tags	Selected
68e586…9129ff	MODULE/INITIAL_WARM	DATA_TRANSMISSION	Simpson,Liana Rae	6 months ago	6 months ago	No tags	Selected
68e587…912a57	MODULE/INITIAL_WARM	LP_MODE	Simpson,Liana Rae	6 months ago	6 months ago	No tags	Selected
68e586…9129c3	MODULE/INITIAL_WARM	VCAL_CALIBRATION	Simpson,Liana Rae	6 months ago	6 months ago	No tags	Selected
68e585…91298b	MODULE/INITIAL_WARM	SLDO	Simpson,Liana Rae	6 months ago	6 months ago	No tags	Selected
68e582…91290f	MODULE/INITIAL_WARM	ANALOG_READBACK	Simpson,Liana Rae	6 months ago	6 months ago	No tags	Selected
68e57b…9128ce	MODULE/INITIAL_WARM	ADC_CALIBRATION	Simpson,Liana Rae	6 months ago	6 months ago	No tags	Selected
660fbf…4e3826	TESTONWAFER	FECHIP_TEST	DimaManeuski	N/A	a year ago	No tags	Selected

Stage	Tests
TESTONWAFER	Electrical FE chip tests (FECHIP_TEST)
HYBRIDISATION
UNUSABLE
BAREMODULEASSEMBLY
BAREMODULERECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK)
MODULE/INIT
MODULE/ASSEMBLY
MODULE/WIREBONDING	ADC Calibration (ADC_CALIBRATION) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO) Low Power Mode (LP_MODE) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/INITIAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/QC_CROSSCHECK	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/INITIAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_MASKING	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Low Power Mode (LP_MODE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_COATING
MODULE/PARYLENE_UNMASKING	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE)
MODULE/WIREBOND_PROTECTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) Low Power Mode (LP_MODE) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/POST_PARYLENE_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE)
MODULE/POST_PARYLENE_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/THERMAL_CYCLES	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Cold startup (COLD_STARTUP)
MODULE/LONG_TERM_STABILITY_TEST	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Undershunt Protection (UNDERSHUNT_PROTECTION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Data Transmission (DATA_TRANSMISSION) Cold startup (COLD_STARTUP)
MODULE/FINAL_METROLOGY	Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE) Analog Readback (ANALOG_READBACK)
MODULE/QC_STATUS
MODULE/UNHAPPY	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/NOTCONSIDEREDINYIELDS	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Undershunt Protection (UNDERSHUNT_PROTECTION) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/GRAVEYARD
MODULE/COMPLETE
MODULE/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION) Tuning (TUNING)
MODULE/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
LLS/PRE_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Low Power Mode (LP_MODE) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/PRE_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/INIT
OB_LOADED_MODULE_CELL/ASSEMBLY
OB_LOADED_MODULE_CELL/WIREBOND_PROTECTION
OB_LOADED_MODULE_CELL/THERMAL_CYCLES
OB_LOADED_MODULE_CELL/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/THERMAL_COLD
OB_LOADED_MODULE_CELL/THERMAL_WARM
OB_LOADED_MODULE_CELL/ENVELOPE_CHECK
OB_LOADED_MODULE_CELL/QC_STATUS
OB_LOADED_MODULE_CELL/UNHAPPY
OB_LOADED_MODULE_CELL/COMPLETE
OB_LOADED_MODULE_CELL/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO)
OB_LOADED_MODULE_CELL/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
OB_LOADED_MODULE_CELL/PIGTAIL_INSERTION
TEST_AFTER_LOADED_LOCAL_SUPPORT_ASSEMBLY	OB:Loaded local support QC electrical connectivity (OBLoadedLocalSupportQC_ElectricalConnectivity) OB:Loaded local support QC electrical performance (OBLoadedLocalSupportQC_ElectricalPerformance) OB:Loaded local support reception at the integration site (OBLoadedLocalSupport_IntegrationSite) OB:Loaded local support QC electrical low power (OBLoadedLocalSupport_QCElectricalLowPower)
TEST_JM_OEC_FE

20UPGFC0146073

MODULE/POST_PARYLENE_COLD

Component Information

Wafer

Properties

Comments

Test: SLDO QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Results

Attachments

RAW Results Record

ProductionDB Record

Current Stage: Post-Parylene Cold

Candidate TestRuns of this Stage

Past QC Stages and Results

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Initial Cold (MODULE/INITIAL_COLD)

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Initial Warm (MODULE/INITIAL_WARM)

Wire Bonding (MODULE/WIREBONDING)

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

All Registered QC Tests

Check QC Flow

Back to top page of this component
