Serial Number	20UPGFC0142972
ProdDB ID	8ab8ff…e895ab
LocalDB ID	660ddf8aec873d003545e773
Component Type	fe_chip
Parents	20UPGM23210890 20UPGB43200152
Children	No match.
Flags

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Key	Data
QC Passed	True
Date	8 months ago
component ObjectId	660ddf8aec873d003545e773
Stage	MODULE/POST_PARYLENE_COLD
Test Type	LP_MODE
Institute ObjectId
User Name	CarlaSbarra
ObjectId of this record	67f519d66a4161a3ffd2d3d2
ObjectId of RAW record	67f519d56a4161a3ffd2d3cb
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.4.1rc0
MEASUREMENT_DATE	2025-04-08T10:33:09.000+00:00
MEASUREMENT_DURATION	233
MEASUREMENT_VERSION	2.3.0
YARR_VERSION	v1.5.2-319-g7fdbc94b
LP_DIGITAL_FAIL	218
LP_IINA	0.22
LP_IIND	0.31
LP_ISHUNTA	0.0607
LP_ISHUNTD	0.0975
LP_VINA	1.445
LP_VIND	1.448
LP_VOFFS	1.265

Filename	Contents
output.log	Download
0x22e7c.log	Download
