20UPGFC0142972

MODULE/TAB_CUTTING

Component Information

Serial Number	20UPGFC0142972
ProdDB ID	8ab8ff…e895ab
LocalDB ID	660ddf8aec873d003545e773
Component Type	fe_chip
Parents	20UPGM23210890 20UPGB43200152
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: MIN_HEALTH_TEST QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	8 months ago
component ObjectId	660ddf8aec873d003545e773
Stage	MODULE/POST_PARYLENE_WARM
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	AnnaRaquel Petri
ObjectId of this record	67ed80d3057fcb7f72800f23
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.4.1
MEASUREMENT_DATE	2025-04-02T16:13:51.000+00:00
MEASUREMENT_DURATION	453
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.3
MIN_HEALTH_BAD_ANALOG	1
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_COLUMN_DISABLED	3072
MIN_HEALTH_DEAD_ANALOG	3
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_HIGH_ENC	3
MIN_HEALTH_HIGH_ENC_INDEPENDENT	3
MIN_HEALTH_NOISE_MEAN	105.23
MIN_HEALTH_NOISE_SIGMA	10.69
MIN_HEALTH_THRESHOLD_FAILED_FITS	4
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	3080
MIN_HEALTH_THRESHOLD_MEAN	1450.57
MIN_HEALTH_THRESHOLD_SIGMA	43.26
MIN_HEALTH_TOT_MEAN	8.27
MIN_HEALTH_TOT_SIGMA	1.88

Attachments

Filename	Contents
output.log	Download
0x22e7c.log	Download
20UPGFC0142972_MODULE__POST_PARYLENE_WARM_MIN-HEALTH-TEST.zip	Download
