20UPGFC0142740

MODULE/QC_STATUS

Component Information

Serial Number	20UPGFC0142740
ProdDB ID	0d8e47…80c6ee
LocalDB ID	660dd139ec873d003545c9a7
Component Type	fe_chip
Parents	20UPGM23211222 20UPGB43200113
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/PARYLENE_UNMASKING)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	10 months ago
component ObjectId	660dd139ec873d003545c9a7
Stage	MODULE/PARYLENE_UNMASKING
Test Type	TUNING
Institute ObjectId
User Name	Iconomidou-FayardLydia
ObjectId of this record	685cf1e366f64a4671aff8a8
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.1
MEASUREMENT_DATE	2025-06-10T09:15:40.000+00:00
MEASUREMENT_DURATION	960
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.4
TUNING_TUNED_NOISE_95_HIGH	121.776
TUNING_TUNED_NOISE_95_LOW	81.599
TUNING_TUNED_NOISE_MEAN	100.882
TUNING_TUNED_NOISE_SIGMA	10.718
TUNING_TUNED_TDAC_MEAN	-1.4
TUNING_TUNED_TDAC_SIGMA	4.024
TUNING_TUNED_THRESHOLD_95_HIGH	1561.358
TUNING_TUNED_THRESHOLD_95_LOW	1429.628
TUNING_TUNED_THRESHOLD_FAILED_FITS	1
TUNING_TUNED_THRESHOLD_MEAN	1497.7
TUNING_TUNED_THRESHOLD_SIGMA	35
TUNING_TUNED_TOT_95_HIGH	10.11
TUNING_TUNED_TOT_95_LOW	5.1
TUNING_TUNED_TOT_MEAN	7.4
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	119.8
TUNING_UNTUNED_NOISE_95_LOW	80.528
TUNING_UNTUNED_NOISE_MEAN	99.472
TUNING_UNTUNED_NOISE_SIGMA	10.983
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2852.105
TUNING_UNTUNED_THRESHOLD_95_LOW	1630.421
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	71
TUNING_UNTUNED_THRESHOLD_MEAN	2211.925
TUNING_UNTUNED_THRESHOLD_SIGMA	310

Attachments

Filename	Contents
0x22d94_L2_warm.json	Download
output.log	Download
0x22d94.log	Download
20UPGFC0142740_MODULE__PARYLENE_UNMASKING_TUNING.zip	Download
