20UPGFC0142742

MODULE/QC_STATUS

Component Information

Serial Number	20UPGFC0142742
ProdDB ID	cb248f…29a116
LocalDB ID	660dd1342fc9f200350c2662
Component Type	fe_chip
Parents	20UPGM23211222 20UPGB43200113
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	9 months ago
component ObjectId	660dd1342fc9f200350c2662
Stage	MODULE/FINAL_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	Iconomidou-FayardLydia
ObjectId of this record	685baf84e3b49673000de40f
ObjectId of RAW record	685baf7fe3b49673000de3ec
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.1
MEASUREMENT_DATE	2025-06-25T06:56:13.000+00:00
MEASUREMENT_DURATION	738
MEASUREMENT_VERSION	2.4.1
YARR_VERSION	v1.5.4
AR_IREF_TRIM	10
AR_IREF	4e-06
AR_GADC	0.808
AR_NOMINAL_SETTINGS	[4e-06, 8.56e-05, 4.57e-05, 4e-06, 3.86e-05, 1.97e-05, 0, 3.78e-05, 7.09e-05, -999, 0, 0, 4.67e-05, 6.35e-05, 5.11e-05, 8.35e-05, 7.11e-05, 7.51e-05, 8.25e-05, 8.35e-05, 7.29e-05, 4.77e-05, 4.76e-05, 7.24e-05, 4.61e-05, 4.68e-05, -999, -999, 0.6193481, 0.048977, 0.8699628, 0.2388315, 0.8082932, -999, -999, 0.8145962, 1.1879962, 0.11266, 0.1089926, 0.1782746, 0.0376597, 0.0388509, 0.1820107, 0.1863514, 0.1843547, 0.6249378, -999, 0.6236344, -999, 0.5868395, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0172102, 0.4591767, 1.9888688, 1.4919128, 1.1921746, 0.5894332, 0.9818652, 1.4945916, 1.2111834, 0.5990735]
AR_ROSC_MAX_RESIDUAL	[3.7750951514903086, 5.867180657816103, 3.2751975124951853, 5.7684861189133105, 2.64782804941672, 4.423646355810218, 2.8739739020387316, 4.842125315645355, 5.488507533189281, 5.388240089325595, 6.384055027267291, 6.454174033817709, 5.240268500046028, 5.320186090962738, 6.036882853563047, 6.339912325984433, 4.536252834515269, 4.508382797477522, 5.152251074774533, 4.985152971936133, 3.98496917882205, 3.980073530363232, 5.3633444876898135, 5.243524407007508, 3.236283823027615, 3.0545154995877692, 3.604436631704232, 3.6331579319585336, 3.9476249123650864, 3.759360243899698, 6.286478367686597, 7.140845950870084, 5.474723514722724, 5.676549949688328, 4.876818719352109, 4.8324424042722995, 4.889964269906439, 4.87585045616941, 4.878133100155958, 4.946764329567234, 5.081308293106873, 5.008164545365957]
AR_ROSC_OFFSET	[-410.0039370016092, -619.31432743312, -437.44954513184615, -642.6245303470225, -521.9744316527265, -897.5411739141815, -656.9630517674465, -951.1533820659565, -664.4860823078639, -662.6619109350855, -789.372781473271, -777.4435075699918, -708.5256820252873, -702.7389319009117, -800.4972286428089, -793.8425413325658, -898.5164717577468, -891.435031117818, -1062.5536525947637, -1061.7849624248477, -926.69534629606, -922.0688487236927, -1122.5709347299562, -1120.6716464353656, -514.0650892197582, -516.1866713996518, -642.1958608374676, -630.8063956709667, -620.5766755561602, -625.7925362635652, -520.7797269515055, -516.6248460163524, -581.6766455471784, -619.9759023313009, -1022.4698427967613, -1019.4091848196039, -1030.2053311668465, -1021.7029660248844, -1020.2021358537245, -1023.1051008281668, -1023.8143282301379, -1021.9564146633909]
AR_ROSC_SLOPE	[748.2251129956263, 1140.9727056764723, 749.7637867954656, 1149.975853561753, 808.7646771411838, 1390.1702095606336, 963.0734870060544, 1428.931160840296, 1167.8659351714475, 1168.4079361128702, 1356.399552087193, 1356.6135597602652, 1200.5990543519542, 1195.0910838098307, 1365.5335833066013, 1366.4081789997706, 1376.5286316311663, 1369.0165346440926, 1628.7444425298938, 1621.9167631522457, 1364.5715528526691, 1356.5900917594972, 1680.5721955400709, 1682.1865350399312, 835.0707971307904, 830.8259147923303, 1018.8022155086807, 1010.8304838692442, 1009.0699800515488, 1012.7359566541215, 1144.9646828876157, 1192.5155376223663, 1116.8444751886084, 1190.8587750976444, 1556.070437648433, 1558.4513675974567, 1574.3512418552687, 1557.758856011537, 1562.2007614549455, 1564.314602572443, 1557.404176281542, 1559.7870933266715]
AR_TEMP_ACB	35.533
AR_TEMP_ASLDO	36.171
AR_TEMP_DSLDO	38.408
AR_TEMP_EXT	20.602
AR_TEMP_NF_ACB	1.258
AR_TEMP_NF_ASLDO	1.259
AR_TEMP_NF_BOTTOM	-999
AR_TEMP_NF_DSLDO	1.258
AR_TEMP_NF_TOP	-999
AR_TEMP_NTC	21.835
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_POLY_TOP	-999
AR_VCALDAC	0.815
AR_VDDA_SATURATION	-1
AR_VDDA_TRIM	7
AR_VDDA_VS_TRIM	[1.018, 1.045, 1.071, 1.096, 1.116, 1.142, 1.167, 1.192, 1.227, 1.252, 1.278, 1.302, 1.321, 1.347, 1.371, 1.398]
AR_VDDD_SATURATION	-1
AR_VDDD_TRIM	7
AR_VDDD_VS_TRIM	[1.041, 1.066, 1.09, 1.116, 1.135, 1.162, 1.187, 1.212, 1.238, 1.262, 1.287, 1.313, 1.336, 1.361, 1.386, 1.389]
AR_VREFCORE	0.459
AR_VREFOVP	1.989

Attachments

Filename	Contents
output.log	Download
0x22d96.log	Download

RAW Results Record

Download RAW

_id

685baf7fe3b49673000de3ec

raw

serialNumber

testType

runNumber

subtestType

results

stage

component

dbVersion

address

sys

20UPGFC0142742

ANALOG_READBACK

685baf6a5b64cc6f27902980

AR_VMEAS

property

YARR_VERSION	v1.5.4
ANALOG_READBACK_MEASUREMENT_VERSION	2.4.1

comment

Measurements

Vmux0

X	False
Unit	V
Values	0.8255034

Vmux3

X	False
Unit	V
Values	0.4245083

Vmux4

X	False
Unit	V
Values	0.6112083

Vmux5

X	False
Unit	V
Values	0.1298702

Vmux6

X	False
Unit	V
Values	0.1262028

Vmux7

X	False
Unit	V
Values	0.1954848

Vmux8

X	False
Unit	V
Values	0.05486988

Vmux9

X	False
Unit	V
Values	0.05606106

Vmux10

X	False
Unit	V
Values	0.1992209

Vmux11

X	False
Unit	V
Values	0.2035616

Vmux12

X	False
Unit	V
Values	0.2015649

Vmux13

X	False
Unit	V
Values	0.642148

Vmux15

X	False
Unit	V
Values	0.6408446

Vmux17

X	False
Unit	V
Values	0.6040497

Vmux31

X	False
Unit	V
Values	0.4763869

Vmux32

X	False
Unit	V
Values	0.6144681

Vmux33

X	False
Unit	V
Values	0.3901884

Vmux34

X	False
Unit	V
Values	0.6132975

Vmux35

X	False
Unit	V
Values	0.6066434

Vmux36

X	False
Unit	V
Values	0.2626765

Vmux37

X	False
Unit	V
Values	0.3908581

Vmux38

X	False
Unit	V
Values	0.6228019

Vmux39

X	False
Unit	V
Values	0.6162837

Vmux63

X	False
Unit	V
Values	0.01441229

Vmux30

X	False
Unit	V
Values	0.01721019

Imux0

X	False
Unit	V
Values	0.05484469

Imux1

X	False
Unit	V
Values	0.8709526

Imux2

X	False
Unit	V
Values	0.4716672

Imux3

X	False
Unit	V
Values	0.05443117

Imux4

X	False
Unit	V
Values	0.4004087

Imux5

X	False
Unit	V
Values	0.2120389

Imux6

X	False
Unit	V
Values	0.01474285

Imux7

X	False
Unit	V
Values	0.392841

Imux8

X	False
Unit	V
Values	0.723685

Imux10

X	False
Unit	V
Values	0.01474332

Imux11

X	False
Unit	V
Values	0.01473646

Imux12

X	False
Unit	V
Values	0.4819477

Imux13

X	False
Unit	V
Values	0.6499687

Imux14

X	False
Unit	V
Values	0.5258412

Imux15

X	False
Unit	V
Values	0.8494568

Imux16

X	False
Unit	V
Values	0.725304

Imux17

X	False
Unit	V
Values	0.7659162

Imux18

X	False
Unit	V
Values	0.8398056

Imux19

X	False
Unit	V
Values	0.4769381

Imux20

X	False
Unit	V
Values	0.7441125

Imux21

X	False
Unit	V
Values	0.4912623

Imux22

X	False
Unit	V
Values	0.490282

Imux23

X	False
Unit	V
Values	0.7390745

Imux24

X	False
Unit	V
Values	0.4753052

Imux25

X	False
Unit	V
Values	0.482885

Imux28

X	False
Unit	V
Values	0.309523

Imux29

X	False
Unit	V
Values	0.03742246

Imux30

X	False
Unit	V
Values	0.4277156

Imux31

X	False
Unit	V
Values	0.1249803

Imux63

X	False
Unit	V
Values	0.01476063

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	260
DiffTh1M	260
DiffTh1R	260
DiffTh2	50
DiffVff	98
EfuseConfig	3855
EfuseReadData0	38410
EfuseReadData1	8749
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	900
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	38285
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	7
SldoTrimD	7
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	12.0 0.188 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	6.87
IrefTrim	10
KSenseInA	21011.777
KSenseInD	21066.771
KSenseShuntA	21612.115
KSenseShuntD	21668.68
KShuntA	989.396
KShuntD	960.688
Name	0x22d96
NfACB	1.2575808
NfASLDO	1.2591662
NfDSLDO	1.2582949
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-3.0 0.2

SoftwareType

ChipID

Name

0x22d96

Institution

IJCLAB

ModuleSN

20UPGM23211222

TimeStart

1750834573

TimeEnd

1750835311

useCalibAdc

False

DCSdata

MODULE/FINAL_WARM

660dd1342fc9f200350c2662

1.01

64657cef8d79bac1f3f0057e

mts	2025-06-25 08:12:47.957000
cts	2025-06-25 08:12:47.957000
rev	0

20UPGFC0142742

ANALOG_READBACK

685baf6a5b64cc6f27902981

AR_TEMP

property

YARR_VERSION	v1.5.4
ANALOG_READBACK_MEASUREMENT_VERSION	2.4.1

comment

Measurements

Vmux2

X	False
Unit	V
Values	0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891 0.1303891

Vmux30

X	False
Unit	V
Values	0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121 0.01714121

Imux9

X	False
Unit	V
Values	0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159 0.1151159

Imux63

X	False
Unit	V
Values	0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905 0.01473905

Vmux14

X	False
Unit	V
Values	0.229395 0.2293211 0.229216 0.2300806 0.230284 0.2297175 0.2289589 0.229344 0.2294115 0.2305078 0.2295989 0.2299152 0.2299086 0.2299329 0.2293212 0.2297416 0.3206092 0.3205256 0.3205041 0.3204408 0.3204104 0.3205773 0.3208512 0.3207447 0.3204592 0.3204291 0.3206978 0.3206678 0.3206484 0.3203214 0.32051 0.3206796

Vmux16

X	False
Unit	V
Values	0.2269078 0.2278173 0.227498 0.2263376 0.2268613 0.2290568 0.2290604 0.2280039 0.227096 0.2273454 0.228268 0.2267453 0.2266267 0.2271564 0.2261899 0.2271877 0.3189418 0.3188479 0.3188441 0.3188766 0.318938 0.3189425 0.3188586 0.3188368 0.3187213 0.3188083 0.3189751 0.3188904 0.3188141 0.3189514 0.3189527 0.3188834

Vmux18

X	False
Unit	V
Values	0.2341761 0.2338675 0.2340724 0.2329927 0.2346435 0.2341688 0.2323737 0.2332022 0.232807 0.233642 0.2336324 0.2341472 0.2351123 0.2326421 0.2340196 0.2340654 0.3244289 0.3243378 0.3242081 0.3245411 0.3243336 0.3241681 0.3242187 0.3244245 0.3245552 0.3244381 0.3243212 0.3244204 0.324185 0.3242803 0.3242107 0.3240861

MonSensSldoAnaSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoDigSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensAcbSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoAnaDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensSldoDigDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensAcbDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

TExtExtNTC

X	False
Unit	C
Values	20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035 20.60161781311035

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	260
DiffTh1M	260
DiffTh1R	260
DiffTh2	50
DiffVff	98
EfuseConfig	3855
EfuseReadData0	38410
EfuseReadData1	8749
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	900
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	38285
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	7
SldoTrimD	7
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	12.0 0.188 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	6.87
IrefTrim	10
KSenseInA	21011.777
KSenseInD	21066.771
KSenseShuntA	21612.115
KSenseShuntD	21668.68
KShuntA	989.396
KShuntD	960.688
Name	0x22d96
NfACB	1.2575808
NfASLDO	1.2591662
NfDSLDO	1.2582949
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-3.0 0.2

SoftwareType

ChipID

Name

0x22d96

Institution

IJCLAB

ModuleSN

20UPGM23211222

TimeStart

1750837772

TimeEnd

1750839146

useCalibAdc

False

DCSdata

MODULE/FINAL_WARM

660dd1342fc9f200350c2662

1.01

64657cef8d79bac1f3f0057e

mts	2025-06-25 08:12:47.957000
cts	2025-06-25 08:12:47.957000
rev	0

20UPGFC0142742

ANALOG_READBACK

685baf6a5b64cc6f27902982

AR_VDD

property

YARR_VERSION	v1.5.4
ANALOG_READBACK_MEASUREMENT_VERSION	2.4.1

comment

Measurements

Vmux34

X	False
Unit	V
Values	0.5263142 0.539414 0.5526997 0.5652787 0.5750462 0.5883775 0.6005606 0.6133169 0.6306182 0.6430222 0.6558991 0.6679764 0.6775247 0.6904123 0.702806 0.7161205

Vmux38

X	False
Unit	V
Values	0.537837 0.5503883 0.5621814 0.5750686 0.5847705 0.5982884 0.6104233 0.6229136 0.6359228 0.6481967 0.6606216 0.6738444 0.6850338 0.6977068 0.7101079 0.7118449

Vmux30

X	False
Unit	V
Values	0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616 0.01714616

Vmux33

X	False
Unit	V
Values	0.3897697 0.3898779 0.3899628 0.3899532 0.3899785 0.390028 0.3900162 0.3901348 0.3901111 0.3899587 0.389823 0.389659 0.3893133 0.3887775 0.3880263 0.3861052

Vmux37

X	False
Unit	V
Values	0.3908248 0.390922 0.3909725 0.3909972 0.3908808 0.390885 0.3908943 0.3908807 0.3907732 0.3904564 0.3901548 0.3894345 0.3885703 0.3866862 0.3839575 0.383232

Imux63

X	False
Unit	V
Values	0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243 0.01474243

Imux28

X	False
Unit	V
Values	0.3082117 0.308372 0.3087107 0.3089053 0.3090275 0.3092517 0.3093279 0.3095228 0.3095554 0.3094456 0.309528 0.309148 0.3087308 0.3078176 0.3060494 0.3020849

Imux29

X	False
Unit	V
Values	0.05604114 0.05226342 0.04915872 0.04584821 0.04403474 0.04155097 0.03919791 0.03728599 0.03531984 0.03446615 0.03456275 0.03622527 0.04007878 0.04939961 0.0678821 0.1096649

Imux30

X	False
Unit	V
Values	0.4261334 0.4268861 0.4271854 0.4275843 0.4276193 0.4278199 0.427758 0.4274822 0.4272808 0.4263327 0.4247635 0.4221184 0.4189096 0.4119609 0.4010076 0.3982637

Imux31

X	False
Unit	V
Values	0.1668896 0.1600761 0.1538891 0.147627 0.1421414 0.1359314 0.1301337 0.1246327 0.1206549 0.1183053 0.1193117 0.1258739 0.1370375 0.1635541 0.2105791 0.2243386

SldoTrimA

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

SldoTrimD

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

ROSC0

X	False
Unit	MHz
Values	362.533 384.133 404.0 425.0 441.4 461.6 481.067 501.2 519.667 538.6 556.333 574.667 589.533 607.533 621.333 622.8

ROSC1

X	False
Unit	MHz
Values	558.4 591.667 622.133 653.8 679.0 710.0 739.467 770.267 798.467 827.267 854.733 882.133 904.867 932.133 953.267 955.467

ROSC2

X	False
Unit	MHz
Values	337.333 358.867 378.667 399.2 415.733 435.933 454.867 474.733 493.533 512.267 530.667 549.0 563.933 582.2 597.733 597.733

ROSC3

X	False
Unit	MHz
Values	544.4 578.067 608.933 640.667 666.0 697.133 726.6 757.467 786.267 815.067 842.867 870.867 893.533 921.133 942.6 944.8

ROSC4

X	False
Unit	MHz
Values	316.067 338.533 358.533 380.133 397.333 418.8 439.067 461.067 481.4 501.867 521.8 542.067 558.8 578.867 594.733 596.267

ROSC5

X	False
Unit	MHz
Values	543.533 581.067 616.067 653.133 682.667 719.2 754.8 791.8 826.933 862.4 896.533 931.533 959.867 994.467 1022.2 1024.93

ROSC6

X	False
Unit	MHz
Values	341.667 367.867 391.933 417.0 437.4 462.933 487.733 513.2 537.267 562.0 585.6 610.267 629.867 654.133 673.133 675.133

ROSC7

X	False
Unit	MHz
Values	529.733 568.4 604.467 642.667 673.2 710.933 747.6 785.667 821.6 857.867 893.133 928.933 958.4 994.067 1021.67 1024.0

ROSC8

X	False
Unit	MHz
Values	542.267 575.667 606.533 638.2 664.6 695.667 725.333 756.733 785.867 815.867 843.733 873.067 895.533 924.333 945.8 947.733

ROSC9

X	False
Unit	MHz
Values	544.467 578.067 609.2 640.867 667.0 698.267 727.933 759.0 788.133 818.4 846.0 875.533 897.733 926.733 948.4 951.0

ROSC10

X	False
Unit	MHz
Values	612.133 650.867 686.933 723.733 754.2 790.467 824.933 861.2 895.067 929.933 962.067 996.267 1022.87 1056.07 1080.93 1082.87

ROSC11

X	False
Unit	MHz
Values	624.067 662.933 699.067 735.733 766.533 802.733 837.333 873.733 907.267 942.133 974.467 1008.47 1034.73 1068.07 1092.8 1095.53

ROSC12

X	False
Unit	MHz
Values	532.667 566.933 598.2 630.667 657.667 689.533 720.2 751.867 781.933 812.933 841.467 871.8 895.0 925.467 946.933 950.0

ROSC13

X	False
Unit	MHz
Values	532.933 566.733 598.133 630.067 657.267 688.667 719.2 751.0 780.8 811.867 840.267 870.933 893.733 923.8 945.4 947.2

ROSC14

X	False
Unit	MHz
Values	611.067 649.867 686.067 722.733 753.267 789.533 824.667 860.667 894.733 930.0 962.267 997.4 1023.53 1057.47 1082.87 1085.27

ROSC15

X	False
Unit	MHz
Values	618.267 657.267 693.4 730.467 761.0 797.4 832.267 868.667 902.667 938.0 970.467 1005.4 1031.67 1065.67 1090.13 1092.27

ROSC16

X	False
Unit	MHz
Values	528.4 566.0 600.267 636.6 666.667 702.333 737.2 773.267 808.6 844.733 877.667 913.533 941.067 975.867 1002.53 1003.67

ROSC17

X	False
Unit	MHz
Values	527.667 564.933 599.0 635.133 664.933 701.267 735.733 771.867 806.067 842.067 875.067 910.667 937.8 972.667 998.867 1000.87

ROSC18

X	False
Unit	MHz
Values	626.333 670.067 711.467 753.467 789.267 831.8 872.867 915.8 956.6 999.533 1038.67 1081.2 1113.87 1155.93 1187.53 1188.2

ROSC19

X	False
Unit	MHz
Values	620.267 664.0 704.2 746.333 782.2 824.533 865.8 908.6 949.067 991.533 1030.47 1072.93 1105.27 1147.0 1178.07 1180.93

ROSC20

X	False
Unit	MHz
Values	489.133 525.067 559.333 594.6 624.733 660.067 694.6 730.733 764.933 800.667 833.467 869.267 896.6 931.467 958.4 960.333

ROSC21

X	False
Unit	MHz
Values	485.067 521.267 555.133 590.4 620.467 655.6 689.867 725.8 760.0 795.067 827.867 862.933 890.6 925.133 951.4 954.533

ROSC22

X	False
Unit	MHz
Values	620.0 665.2 707.4 751.333 788.2 831.8 874.6 919.133 961.0 1005.47 1046.2 1089.13 1122.93 1165.87 1198.2 1200.73

ROSC23

X	False
Unit	MHz
Values	623.6 669.0 711.067 754.933 791.933 835.733 878.4 922.933 964.867 1009.53 1049.4 1093.33 1126.93 1169.8 1202.27 1205.47

ROSC24

X	False
Unit	MHz
Values	350.6 373.333 394.8 417.267 435.933 457.733 479.133 501.267 522.067 543.867 563.867 585.133 601.467 622.533 638.4 639.6

ROSC25

X	False
Unit	MHz
Values	344.067 367.133 388.2 410.467 428.933 450.667 471.933 493.4 514.667 536.067 555.867 577.333 593.933 614.8 630.733 631.733

ROSC26

X	False
Unit	MHz
Values	413.267 441.0 467.0 493.933 516.6 543.2 568.933 595.933 621.4 648.267 672.6 698.867 719.0 744.667 763.8 766.2

ROSC27

X	False
Unit	MHz
Values	415.933 443.933 470.0 496.533 518.933 545.267 571.067 597.867 622.867 649.4 673.467 699.933 719.733 745.2 764.333 766.333

ROSC28

X	False
Unit	MHz
Values	423.867 451.867 478.133 504.6 527.4 553.867 579.333 606.267 631.6 657.667 681.933 707.733 727.467 753.0 771.867 773.4

ROSC29

X	False
Unit	MHz
Values	422.667 450.8 476.8 503.667 526.333 552.8 578.533 605.4 630.533 657.0 681.0 707.0 727.2 752.8 772.333 773.467

ROSC30

X	False
Unit	MHz
Values	660.267 693.667 725.133 756.733 782.933 813.733 843.133 873.533 901.933 931.333 958.333 986.8 1008.53 1036.33 1056.87 1058.53

ROSC31

X	False
Unit	MHz
Values	712.533 747.733 780.8 813.533 841.667 873.6 904.6 936.133 965.933 996.4 1024.33 1053.93 1076.47 1105.0 1125.73 1127.0

ROSC32

X	False
Unit	MHz
Values	572.267 604.0 633.8 663.867 689.333 718.867 747.733 777.6 805.733 834.467 860.533 889.067 910.467 937.733 957.667 959.667

ROSC33

X	False
Unit	MHz
Values	610.733 644.533 675.867 708.4 735.133 766.8 797.333 829.067 858.933 889.667 917.933 948.467 970.867 1000.2 1021.93 1023.47

ROSC34

X	False
Unit	MHz
Values	591.067 632.867 671.933 712.667 746.8 787.333 826.733 867.8 906.6 947.6 985.267 1025.87 1056.6 1096.4 1126.0 1129.33

ROSC35

X	False
Unit	MHz
Values	596.6 638.467 677.733 718.4 752.533 793.067 832.533 873.8 912.933 953.467 991.267 1031.93 1062.53 1102.93 1132.47 1135.8

ROSC36

X	False
Unit	MHz
Values	602.2 644.467 684.333 725.267 759.8 800.933 840.867 882.2 921.8 963.0 1000.8 1042.2 1073.0 1113.53 1143.2 1147.47

ROSC37

X	False
Unit	MHz
Values	593.4 635.533 674.933 715.333 749.467 789.867 829.4 870.533 909.6 950.4 988.133 1028.73 1059.47 1099.87 1129.53 1132.0

ROSC38

X	False
Unit	MHz
Values	599.867 641.533 681.133 721.733 755.867 796.6 836.133 877.467 916.733 957.533 995.333 1036.2 1067.13 1107.13 1137.13 1139.67

ROSC39

X	False
Unit	MHz
Values	598.933 641.0 680.4 721.267 755.467 796.2 835.533 877.267 916.733 957.067 995.4 1036.07 1067.07 1107.2 1136.8 1139.73

ROSC40

X	False
Unit	MHz
Values	591.067 632.867 671.867 712.867 747.0 787.467 826.667 868.067 907.2 948.2 986.133 1026.4 1057.07 1097.2 1126.47 1128.93

ROSC41

X	False
Unit	MHz
Values	595.467 637.267 676.667 717.4 751.067 792.067 831.333 873.133 912.133 952.933 990.533 1031.33 1062.13 1102.47 1131.73 1134.2

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	260
DiffTh1M	260
DiffTh1R	260
DiffTh2	50
DiffVff	98
EfuseConfig	3855
EfuseReadData0	38410
EfuseReadData1	8749
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	900
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	38285
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	7
SldoTrimD	7
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	12.0 0.188 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	6.87
IrefTrim	10
KSenseInA	21011.777
KSenseInD	21066.771
KSenseShuntA	21612.115
KSenseShuntD	21668.68
KShuntA	989.396
KShuntD	960.688
Name	0x22d96
NfACB	1.2575808
NfASLDO	1.2591662
NfDSLDO	1.2582949
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-3.0 0.2

SoftwareType

ChipID

Name

0x22d96

Institution

IJCLAB

ModuleSN

20UPGM23211222

TimeStart

1750835311

TimeEnd

1750837771

useCalibAdc

False

DCSdata

MODULE/FINAL_WARM

660dd1342fc9f200350c2662

1.01

64657cef8d79bac1f3f0057e

mts	2025-06-25 08:12:47.957000
cts	2025-06-25 08:12:47.957000
rev	0

20UPGFC0142742

ANALOG_READBACK

685baf6a5b64cc6f27902983

AR_REGISTER

property

YARR_VERSION	v1.5.4
ANALOG_READBACK_MEASUREMENT_VERSION	2.4.1

comment

Measurements

IrefTrimSense

X	False
Unit	-
Values	10.0

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	260
DiffTh1M	260
DiffTh1R	260
DiffTh2	50
DiffVff	98
EfuseConfig	3855
EfuseReadData0	38410
EfuseReadData1	8749
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	900
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	38285
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	7
SldoTrimD	7
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	12.0 0.188 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	6.87
IrefTrim	10
KSenseInA	21011.777
KSenseInD	21066.771
KSenseShuntA	21612.115
KSenseShuntD	21668.68
KShuntA	989.396
KShuntD	960.688
Name	0x22d96
NfACB	1.2575808
NfASLDO	1.2591662
NfDSLDO	1.2582949
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-3.0 0.2

SoftwareType

ChipID

Name

0x22d96

Institution

IJCLAB

ModuleSN

20UPGM23211222

TimeStart

1750837771

TimeEnd

1750837772

DCSdata

MODULE/FINAL_WARM

660dd1342fc9f200350c2662

1.01

64657cef8d79bac1f3f0057e

mts	2025-06-25 08:12:47.957000
cts	2025-06-25 08:12:47.957000
rev	0

rawHash

17b35107e4389190653e52a197cf3a4e

stage

MODULE/FINAL_WARM

ProductionDB Record

Expand ProductionDB Record

6863af4c2cb2a5e981b0bb55

state

ready

stateTs

2025-07-01T09:50:04.289Z

stateUserIdentity

24-7729-1

date

2025-06-25T08:12:00.000Z

testType

id	6393a07c15838700361eebef
code	ANALOG_READBACK
name	Analog Readback
state	active

institution

id	5d372a3becb4750009835557
code	IJCLAB
name	Laboratoire de Physique des 2 Infinis Irène Joliot-Curie (IJCLab)

user

id	5d42f9eb1fd678000a409728
userIdentity	24-7729-1
firstName	Iconomidou-Fayard
middleName	None
lastName	Lydia

runNumber

685baf84e3b49673000de40f

passed

True

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	Analog Readback Analysis Version	string	None	True	2.6.1	None	None
MEASUREMENT_DATE	Date measurement performed	datetime	None	False	2025-06-25T06:56:13.000+00:00	None	None
MEASUREMENT_DURATION	Measurement duration	integer	None	False	738	None	None
MEASUREMENT_VERSION	Measurement version	string	None	False	2.4.1	None	None
YARR_VERSION	Yarr Version	string	None	False	v1.5.4	None	None

results

code AR_IREF_TRIM
name Wirebonded Iref trim on ITkPix v2 chip
order 23
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 10
associateChild None
code AR_IREF
name AR_IREF (A)
order 24
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 4e-06
associateChild None
code AR_GADC
name AR_GADC (V)
order 25
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.808
associateChild None

code	AR_NOMINAL_SETTINGS
name	Analog readback at nominal settings
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	4e-06 8.56e-05 4.57e-05 4e-06 3.86e-05 1.97e-05 0 3.78e-05 7.09e-05 -999 0 0 4.67e-05 6.35e-05 5.11e-05 8.35e-05 7.11e-05 7.51e-05 8.25e-05 8.35e-05 7.29e-05 4.77e-05 4.76e-05 7.24e-05 4.61e-05 4.68e-05 -999 -999 0.6193481 0.048977 0.8699628 0.2388315 0.8082932 -999 -999 0.8145962 1.1879962 0.11266 0.1089926 0.1782746 0.0376597 0.0388509 0.1820107 0.1863514 0.1843547 0.6249378 -999 0.6236344 -999 0.5868395 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 0.0172102 0.4591767 1.9888688 1.4919128 1.1921746 0.5894332 0.9818652 1.4945916 1.2111834 0.5990735
associateChild	None

code	AR_ROSC_MAX_RESIDUAL
name	Ring Oscillator Max Residual
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	3.7750951514903086 5.867180657816103 3.2751975124951853 5.7684861189133105 2.64782804941672 4.423646355810218 2.8739739020387316 4.842125315645355 5.488507533189281 5.388240089325595 6.384055027267291 6.454174033817709 5.240268500046028 5.320186090962738 6.036882853563047 6.339912325984433 4.536252834515269 4.508382797477522 5.152251074774533 4.985152971936133 3.98496917882205 3.980073530363232 5.3633444876898135 5.243524407007508 3.236283823027615 3.0545154995877692 3.604436631704232 3.6331579319585336 3.9476249123650864 3.759360243899698 6.286478367686597 7.140845950870084 5.474723514722724 5.676549949688328 4.876818719352109 4.8324424042722995 4.889964269906439 4.87585045616941 4.878133100155958 4.946764329567234 5.081308293106873 5.008164545365957
associateChild	None

code	AR_ROSC_OFFSET
name	Ring Oscillator Offset
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	-410.0039370016092 -619.31432743312 -437.44954513184615 -642.6245303470225 -521.9744316527265 -897.5411739141815 -656.9630517674465 -951.1533820659565 -664.4860823078639 -662.6619109350855 -789.372781473271 -777.4435075699918 -708.5256820252873 -702.7389319009117 -800.4972286428089 -793.8425413325658 -898.5164717577468 -891.435031117818 -1062.5536525947637 -1061.7849624248477 -926.69534629606 -922.0688487236927 -1122.5709347299562 -1120.6716464353656 -514.0650892197582 -516.1866713996518 -642.1958608374676 -630.8063956709667 -620.5766755561602 -625.7925362635652 -520.7797269515055 -516.6248460163524 -581.6766455471784 -619.9759023313009 -1022.4698427967613 -1019.4091848196039 -1030.2053311668465 -1021.7029660248844 -1020.2021358537245 -1023.1051008281668 -1023.8143282301379 -1021.9564146633909
associateChild	None

code	AR_ROSC_SLOPE
name	Ring Oscillator Slope
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	748.2251129956263 1140.9727056764723 749.7637867954656 1149.975853561753 808.7646771411838 1390.1702095606336 963.0734870060544 1428.931160840296 1167.8659351714475 1168.4079361128702 1356.399552087193 1356.6135597602652 1200.5990543519542 1195.0910838098307 1365.5335833066013 1366.4081789997706 1376.5286316311663 1369.0165346440926 1628.7444425298938 1621.9167631522457 1364.5715528526691 1356.5900917594972 1680.5721955400709 1682.1865350399312 835.0707971307904 830.8259147923303 1018.8022155086807 1010.8304838692442 1009.0699800515488 1012.7359566541215 1144.9646828876157 1192.5155376223663 1116.8444751886084 1190.8587750976444 1556.070437648433 1558.4513675974567 1574.3512418552687 1557.758856011537 1562.2007614549455 1564.314602572443 1557.404176281542 1559.7870933266715
associateChild	None

code AR_TEMP_ACB
name Temperature ACB
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 35.533
associateChild None
code AR_TEMP_ASLDO
name Temperature Ana SLDO
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 36.171
associateChild None
code AR_TEMP_DSLDO
name Temperature Dig SLDO
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 38.408
associateChild None
code AR_TEMP_EXT
name Control temperature (external NTC from the FE)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 20.602
associateChild None
code AR_TEMP_NF_ACB
name Temperature calibration constant (ACB)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.258
associateChild None
code AR_TEMP_NF_ASLDO
name Temperature calibration constant (ana SLDO)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.259
associateChild None
code AR_TEMP_NF_BOTTOM
name Temperature calibration constant (poly bottom)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_NF_DSLDO
name Temperature calibration constant (dig SLDO)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.258
associateChild None
code AR_TEMP_NF_TOP
name Temperature calibration constant (poly top)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_NTC
name Temperature NTC
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 21.835
associateChild None
code AR_TEMP_POLY_BOTTOM
name Temperature poly bottom
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_POLY_TOP
name Temperature poly top
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_VCALDAC
name AR_VCALDAC (V)
order 26
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.815
associateChild None
code AR_VDDA_SATURATION
name VDDA saturation trim value
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -1
associateChild None
code AR_VDDA_TRIM
name VDDA Trim
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 7
associateChild None

code	AR_VDDA_VS_TRIM
name	VDDA vs trim
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	1.018 1.045 1.071 1.096 1.116 1.142 1.167 1.192 1.227 1.252 1.278 1.302 1.321 1.347 1.371 1.398
associateChild	None

code AR_VDDD_SATURATION
name VDDD saturation trim value
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -1
associateChild None
code AR_VDDD_TRIM
name VDDD Trim
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 7
associateChild None

code	AR_VDDD_VS_TRIM
name	VDDD vs trim
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	1.041 1.066 1.09 1.116 1.135 1.162 1.187 1.212 1.238 1.262 1.287 1.313 1.336 1.361 1.386 1.389
associateChild	None

code AR_VREFCORE
name AR_VREFCORE (V)
order 27
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.459
associateChild None
code AR_VREFOVP
name AR_VREFOVP (V)
order 28
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 1.989
associateChild None

cts

2025-07-01T09:50:04.290Z

sys

cts	2025-07-01T09:50:04.290Z
mts	2025-07-01T09:50:07.385Z
rev	2

defects

comments

None

attachments

code

bddd61cf770ef74c4c5f3e13f2e5accf

dateTime

2025-07-01T09:50:04.637Z

title

TestRun_6863af4c2cb2a5e981b0bb55_Attachment_Pack.zip

description

/home/data/viewer/static/cache/thumbnail/TestRun_6863af4c2cb2a5e981b0bb55_Attachment_Pack.zip

contentType

None

type

eos

url

https://eosatlas.cern.ch/eos/atlas/atlascerngroupdisk/det-itk/prod-db/b/d/d/bddd61cf770ef74c4c5f3e13f2e5accf?authz=zteos64:MDAwMDAyZjZ4nO1RLUsEURRlBQ0GEaPpIiKW2XnvzZs3szcZxGBcbcuC73MdVucNs2-LCCaDWmziTxCT1gWTUfBHqMFiE6OuYjCYTd4LNxzOOdzDmX6cmG7Us6ev53dT85NF6FdmYWKvWm6wzdj6QSzDjvy-2tZlr_bDyhSDfmxsiMb0uKq9iYyKVWzGq4wxgmqXZcS6jGuuU5dYmjhmU6m1W18kLNfCJDoiiUoiSh2NWglTkeTKEZq1RMZa7ftGZ0MGWLMKIANCkHHkBBhhogvDwiDlVOS08_VvF3qfSEKyzl7VhVAYWwasvQ9NnuZcCBQiz1c6iG48mNImpaLZypuUdKGUuxa_bMCUCOM0Afu1SkFWFcK2HwT8XWj8rixK_IH0rEcYDI1HAqGW2iL4UtltueNwDo6O90eOjV7SW3E9Q9pb5uqZv7fjs9WDkyX18HY5_1_EXxQBh08XN40Py8XtTQ%3d%3d

urlCernbox

https://cernbox.cern.ch/files/spaces/eos/atlas/atlascerngroupdisk/det-itk/prod-db/b/d/d/bddd61cf770ef74c4c5f3e13f2e5accf

filename

bddd61cf770ef74c4c5f3e13f2e5accf

user

id	5d42f9eb1fd678000a409728
userIdentity	24-7729-1
firstName	Iconomidou-Fayard
middleName	None
lastName	Lydia

code

fb63b630b97ad0a662b19504bc351c04

dateTime

2025-07-01T09:50:05.705Z

title

RAW

description

RAW

contentType

text/plain

type

file

binaryStoreg02

True

filename

data

user

id	5d42f9eb1fd678000a409728
userIdentity	24-7729-1
firstName	Iconomidou-Fayard
middleName	None
lastName	Lydia

components

code

state

stateTs

stateUserIdentity

dummy

completed

completedTs

completedUserIdentity

trashed

trashedTs

trashedUserIdentity

serialNumber

alternativeIdentifier

ancestorMap

project

subproject

componentType

type

properties

testedAtStage

institution

660dd1342fc9f200350c2662

cb248f33e295dac0cd3e8f23c629a116

ready

2024-04-03T21:59:16.150Z

5310-2637-1

False

None

False

None

20UPGFC0142742

None

parent

component

6787cdf538efa70a43c85cac

code

8f822b727c2da06893b7c1ff5f2c695b

state

ready

stateTs

2025-01-15T15:02:13.083Z

stateUserIdentity

23-6780-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGB43200113

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	BARE_MODULE
name	Bare Module

type

code	QUAD_BARE_MODULE
name	Quad bare module

testedAtStage

code	MODULE/FINAL_COLD
name	Final Cold

highestLevelParent

component

67bed29d5cfcdd14473055e2

code

977e46ac3d8f2613c6b051509ae72593

state

ready

stateTs

2025-02-26T08:36:45.248Z

stateUserIdentity

4951-6346-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGM23211222

alternativeIdentifier

Paris1003

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	MODULE
name	Module

type

code	OUTER_SYSTEM_QUAD_MODULE
name	Outer system quad module

testedAtStage

code	MODULE/FINAL_COLD
name	Final Cold

code	P
name	Pixels

code	PG
name	Pixel general

code	FE_CHIP
name	Front-end Chip

code	ITKPIX_V2
name	ITkpix_V2

None

code	MODULE/FINAL_WARM
name	Final Warm
order	19
initial	False
final	False

code	GL
name	Glasgow University

Current Stage: Ranking of the module

No tests are allocated for this stage.

Past QC Stages and Results

Final flatness measurement (MODULE/FINAL_METROLOGY)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Final Cold (MODULE/FINAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Cold startup (COLD_STARTUP)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Final Warm (MODULE/FINAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Long Term Stability Test (MODULE/LONG_TERM_STABILITY_TEST)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Thermal Cycles (MODULE/THERMAL_CYCLES)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Cold startup (COLD_STARTUP)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Post-Parylene Cold (MODULE/POST_PARYLENE_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	Registered	Registered
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Cold (MODULE/INITIAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Warm (MODULE/INITIAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wire Bonding (MODULE/WIREBONDING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Test	Local Result	ProdDB Record
Analog Readback (ANALOG_READBACK)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

Test	Local Result	ProdDB Record
Electrical FE chip tests (FECHIP_TEST)	Registered	Registered

LocalDB Test ID	Stage	Test Name	Inspector	Measurement Date	Analysis Date	Tags	QC Registration
685bba…b285a1	MODULE/FINAL_WARM	INJECTION_CAPACITANCE	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685bbc…8a0c97	MODULE/FINAL_WARM	LP_MODE	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685c02…8a2510	MODULE/FINAL_WARM	TUNING	Iconomidou-FayardLydia	N/A	9 months ago	No tags	Selected
685d27…65af7a	MODULE/FINAL_WARM	PIXEL_FAILURE_ANALYSIS	Iconomidou-FayardLydia	N/A	9 months ago	No tags	Selected
685c02…325308	MODULE/FINAL_WARM	MIN_HEALTH_TEST	Iconomidou-FayardLydia	N/A	9 months ago	No tags	Selected
685bbc…b4b108	MODULE/FINAL_WARM	DATA_TRANSMISSION	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685bb7…324d68	MODULE/FINAL_WARM	SLDO	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685baf…0de40f	MODULE/FINAL_WARM	ANALOG_READBACK	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685ab8…2c97e5	MODULE/FINAL_WARM	ADC_CALIBRATION	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685d49…b4e049	MODULE/FINAL_COLD	DATA_TRANSMISSION	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
6863a6…e492b5	MODULE/FINAL_COLD	PIXEL_FAILURE_ANALYSIS	Iconomidou-FayardLydia	N/A	9 months ago	No tags	Selected
6863a6…da2374	MODULE/FINAL_COLD	MIN_HEALTH_TEST	Iconomidou-FayardLydia	N/A	9 months ago	No tags	Selected
6863a6…8a6d42	MODULE/FINAL_COLD	TUNING	Iconomidou-FayardLydia	N/A	9 months ago	No tags	Selected
685d49…5cd481	MODULE/FINAL_COLD	LP_MODE	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685d47…5cd458	MODULE/FINAL_COLD	INJECTION_CAPACITANCE	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685d46…b4dfc8	MODULE/FINAL_COLD	VCAL_CALIBRATION	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685d44…44ac4e	MODULE/FINAL_COLD	SLDO	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685d3d…b4ddcd	MODULE/FINAL_COLD	ANALOG_READBACK	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685d2c…affbf7	MODULE/FINAL_COLD	ADC_CALIBRATION	Iconomidou-FayardLydia	10 months ago	9 months ago	No tags	Selected
685cf1…aff837	MODULE/PARYLENE_UNMASKING	TUNING	Iconomidou-FayardLydia	N/A	10 months ago	No tags	Selected
68481e…548239	MODULE/PARYLENE_UNMASKING	PIXEL_FAILURE_ANALYSIS	Iconomidou-FayardLydia	N/A	10 months ago	No tags	Selected
6847ff…548172	MODULE/PARYLENE_UNMASKING	MIN_HEALTH_TEST	Iconomidou-FayardLydia	N/A	10 months ago	No tags	Selected
67ee42…bd3e26	MODULE/INITIAL_COLD	DATA_TRANSMISSION	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ee42…fed348	MODULE/INITIAL_COLD	LP_MODE	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ee5c…bd45cd	MODULE/INITIAL_COLD	PIXEL_FAILURE_ANALYSIS	Iconomidou-FayardLydia	N/A	a year ago	No tags	Selected
67ee4f…fed394	MODULE/INITIAL_COLD	MIN_HEALTH_TEST	Iconomidou-FayardLydia	N/A	a year ago	No tags	Selected
67ee57…847355	MODULE/INITIAL_COLD	TUNING	Iconomidou-FayardLydia	N/A	a year ago	No tags	Selected
67ee3c…846e6b	MODULE/INITIAL_COLD	INJECTION_CAPACITANCE	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ee3b…846e37	MODULE/INITIAL_COLD	VCAL_CALIBRATION	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ee39…fed324	MODULE/INITIAL_COLD	SLDO	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ed64…fed2f0	MODULE/INITIAL_COLD	ANALOG_READBACK	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ed57…222e07	MODULE/INITIAL_COLD	ADC_CALIBRATION	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ebdc…222ab4	MODULE/INITIAL_WARM	PIXEL_FAILURE_ANALYSIS	Iconomidou-FayardLydia	N/A	a year ago	No tags	Selected
67ebdc…bd3c40	MODULE/INITIAL_WARM	TUNING	Iconomidou-FayardLydia	N/A	a year ago	No tags	Selected
67ebd3…f24930	MODULE/INITIAL_WARM	MIN_HEALTH_TEST	Iconomidou-FayardLydia	N/A	a year ago	No tags	Selected
67ebcc…bd3b48	MODULE/INITIAL_WARM	INJECTION_CAPACITANCE	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ebce…bd3b9b	MODULE/INITIAL_WARM	DATA_TRANSMISSION	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ebce…bd3b6c	MODULE/INITIAL_WARM	LP_MODE	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ebcb…bd3b08	MODULE/INITIAL_WARM	VCAL_CALIBRATION	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ebc9…bd3ab9	MODULE/INITIAL_WARM	SLDO	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ebc4…f11cac	MODULE/INITIAL_WARM	ANALOG_READBACK	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
67ebb7…8468a6	MODULE/INITIAL_WARM	ADC_CALIBRATION	Iconomidou-FayardLydia	a year ago	a year ago	No tags	Selected
660dd2…0c3a2a	TESTONWAFER	FECHIP_TEST	DimaManeuski	N/A	a year ago	No tags	Selected

Stage	Tests
TESTONWAFER	Electrical FE chip tests (FECHIP_TEST)
HYBRIDISATION
UNUSABLE
BAREMODULEASSEMBLY
BAREMODULERECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK)
MODULE/INIT
MODULE/ASSEMBLY
MODULE/WIREBONDING	ADC Calibration (ADC_CALIBRATION) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO) Low Power Mode (LP_MODE) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/INITIAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/QC_CROSSCHECK	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/INITIAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_MASKING	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Low Power Mode (LP_MODE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_COATING
MODULE/PARYLENE_UNMASKING	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE)
MODULE/WIREBOND_PROTECTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) Low Power Mode (LP_MODE) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/POST_PARYLENE_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE)
MODULE/POST_PARYLENE_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/THERMAL_CYCLES	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Cold startup (COLD_STARTUP)
MODULE/LONG_TERM_STABILITY_TEST	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Undershunt Protection (UNDERSHUNT_PROTECTION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Data Transmission (DATA_TRANSMISSION) Cold startup (COLD_STARTUP)
MODULE/FINAL_METROLOGY	Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE) Analog Readback (ANALOG_READBACK)
MODULE/QC_STATUS
MODULE/UNHAPPY	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/NOTCONSIDEREDINYIELDS	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Undershunt Protection (UNDERSHUNT_PROTECTION) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/GRAVEYARD
MODULE/COMPLETE
MODULE/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION) Tuning (TUNING)
MODULE/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
LLS/PRE_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Low Power Mode (LP_MODE) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/PRE_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/INIT
OB_LOADED_MODULE_CELL/ASSEMBLY
OB_LOADED_MODULE_CELL/WIREBOND_PROTECTION
OB_LOADED_MODULE_CELL/THERMAL_CYCLES
OB_LOADED_MODULE_CELL/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/THERMAL_COLD
OB_LOADED_MODULE_CELL/THERMAL_WARM
OB_LOADED_MODULE_CELL/ENVELOPE_CHECK
OB_LOADED_MODULE_CELL/QC_STATUS
OB_LOADED_MODULE_CELL/UNHAPPY
OB_LOADED_MODULE_CELL/COMPLETE
OB_LOADED_MODULE_CELL/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO)
OB_LOADED_MODULE_CELL/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
OB_LOADED_MODULE_CELL/PIGTAIL_INSERTION
TEST_AFTER_LOADED_LOCAL_SUPPORT_ASSEMBLY	OB:Loaded local support QC electrical connectivity (OBLoadedLocalSupportQC_ElectricalConnectivity) OB:Loaded local support QC electrical performance (OBLoadedLocalSupportQC_ElectricalPerformance) OB:Loaded local support reception at the integration site (OBLoadedLocalSupport_IntegrationSite) OB:Loaded local support QC electrical low power (OBLoadedLocalSupport_QCElectricalLowPower)
TEST_JM_OEC_FE

20UPGFC0142742

MODULE/QC_STATUS

Component Information

Wafer

Properties

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Results

Attachments

RAW Results Record

ProductionDB Record

Current Stage: Ranking of the module

Past QC Stages and Results

Final flatness measurement (MODULE/FINAL_METROLOGY)

Final Cold (MODULE/FINAL_COLD)

Final Warm (MODULE/FINAL_WARM)

Long Term Stability Test (MODULE/LONG_TERM_STABILITY_TEST)

Thermal Cycles (MODULE/THERMAL_CYCLES)

Post-Parylene Cold (MODULE/POST_PARYLENE_COLD)

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Initial Cold (MODULE/INITIAL_COLD)

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Initial Warm (MODULE/INITIAL_WARM)

Wire Bonding (MODULE/WIREBONDING)

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

All Registered QC Tests

Check QC Flow

Back to top page of this component
