20UPGFC0142730

MODULE/QC_STATUS

Component Information

Serial Number	20UPGFC0142730
ProdDB ID	566e30…7a19ec
LocalDB ID	660dd11f2fc9f200350c263c
Component Type	fe_chip
Parents	20UPGM23211222 20UPGB43200113
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: MIN_HEALTH_TEST QC Passed

(Stage: MODULE/INITIAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	660dd11f2fc9f200350c263c
Stage	MODULE/INITIAL_COLD
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	Iconomidou-FayardLydia
ObjectId of this record	67ee4f05843858b56efed361
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.4.1
MEASUREMENT_DATE	2025-04-03T08:12:45.000+00:00
MEASUREMENT_DURATION	486
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.2-408-gee61268
MIN_HEALTH_BAD_ANALOG	11
MIN_HEALTH_BAD_DIGITAL	11
MIN_HEALTH_COLUMN_DISABLED	0
MIN_HEALTH_DEAD_ANALOG	6
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_HIGH_ENC	3
MIN_HEALTH_HIGH_ENC_INDEPENDENT	3
MIN_HEALTH_NOISE_MEAN	88.35
MIN_HEALTH_NOISE_SIGMA	10.44
MIN_HEALTH_THRESHOLD_FAILED_FITS	132
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	159
MIN_HEALTH_THRESHOLD_MEAN	1997.84
MIN_HEALTH_THRESHOLD_SIGMA	342.65
MIN_HEALTH_TOT_MEAN	11.3
MIN_HEALTH_TOT_SIGMA	2.39

Attachments

Filename	Contents
output.log	Download
0x22d8a.log	Download
20UPGFC0142730_MODULE__INITIAL_COLD_MIN-HEALTH-TEST.zip	Download
