20UPGFC0142389

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142389
ProdDB ID	20ebf3…aeffce
LocalDB ID	660dc80aec873d003545b054
Component Type	fe_chip
Parents	20UPGM23210863 20UPGB43200173
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	660dc80aec873d003545b054
Stage	MODULE/FINAL_COLD
Test Type	TUNING
Institute ObjectId
User Name	GiordonStark
ObjectId of this record	68df1eff95403e048c93f138
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-10-03T00:30:01.000+00:00
MEASUREMENT_DURATION	1071
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	120.027
TUNING_TUNED_NOISE_95_LOW	77.061
TUNING_TUNED_NOISE_MEAN	97.649
TUNING_TUNED_NOISE_SIGMA	11.601
TUNING_TUNED_TDAC_MEAN	-1.1
TUNING_TUNED_TDAC_SIGMA	4.621
TUNING_TUNED_THRESHOLD_95_HIGH	1565.782
TUNING_TUNED_THRESHOLD_95_LOW	1428.26
TUNING_TUNED_THRESHOLD_FAILED_FITS	1
TUNING_TUNED_THRESHOLD_MEAN	1499.6
TUNING_TUNED_THRESHOLD_SIGMA	38
TUNING_TUNED_TOT_95_HIGH	10.97
TUNING_TUNED_TOT_95_LOW	5
TUNING_TUNED_TOT_MEAN	7.4
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	118.271
TUNING_UNTUNED_NOISE_95_LOW	76.113
TUNING_UNTUNED_NOISE_MEAN	96.127
TUNING_UNTUNED_NOISE_SIGMA	11.884
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	3255.844
TUNING_UNTUNED_THRESHOLD_95_LOW	1726.012
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	188
TUNING_UNTUNED_THRESHOLD_MEAN	2434.754
TUNING_UNTUNED_THRESHOLD_SIGMA	388

Attachments

Filename	Contents
0x22c35_L2_cold.json	Download
0x22c35.log	Download
output.log	Download
20UPGFC0142389_MODULE__FINAL_COLD_TUNING.zip	Download

ProductionDB Record

Expand ProductionDB Record
