20UPGFC0142265

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142265
ProdDB ID	52545a…df9b37
LocalDB ID	660d7ceeec873d00354510bf
Component Type	fe_chip
Parents	20UPGM23210545 20UPGB43200165
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	660d7ceeec873d00354510bf
Stage	MODULE/FINAL_COLD
Test Type	TUNING
Institute ObjectId
User Name	SamuelRoberts
ObjectId of this record	68cdda2e4620977c2530f8d4
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-09-19T22:13:49.000+00:00
MEASUREMENT_DURATION	876
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	113.21
TUNING_TUNED_NOISE_95_LOW	60.49
TUNING_TUNED_NOISE_MEAN	90.116
TUNING_TUNED_NOISE_SIGMA	17.497
TUNING_TUNED_TDAC_MEAN	-0.7
TUNING_TUNED_TDAC_SIGMA	4.656
TUNING_TUNED_THRESHOLD_95_HIGH	1567.054
TUNING_TUNED_THRESHOLD_95_LOW	1427.631
TUNING_TUNED_THRESHOLD_FAILED_FITS	106
TUNING_TUNED_THRESHOLD_MEAN	1500.9
TUNING_TUNED_THRESHOLD_SIGMA	39
TUNING_TUNED_TOT_95_HIGH	11.12
TUNING_TUNED_TOT_95_LOW	5
TUNING_TUNED_TOT_MEAN	7.5
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	110.805
TUNING_UNTUNED_NOISE_95_LOW	71.589
TUNING_UNTUNED_NOISE_MEAN	90.003
TUNING_UNTUNED_NOISE_SIGMA	10.872
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2760.61
TUNING_UNTUNED_THRESHOLD_95_LOW	1344.922
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	153
TUNING_UNTUNED_THRESHOLD_MEAN	1999.208
TUNING_UNTUNED_THRESHOLD_SIGMA	358

Attachments

Filename	Contents
0x22bb9_L2_cold.json	Download
output.log	Download
0x22bb9.log	Download
20UPGFC0142265_MODULE__FINAL_COLD_TUNING.zip	Download
