20UPGFC0142265

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142265
ProdDB ID	52545a…df9b37
LocalDB ID	660d7ceeec873d00354510bf
Component Type	fe_chip
Parents	20UPGM23210545 20UPGB43200165
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/INITIAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	4 months ago
component ObjectId	660d7ceeec873d00354510bf
Stage	MODULE/INITIAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	Simpson,Liana Rae
ObjectId of this record	689270a08428c598c032bb2c
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-08-05T19:13:41.000+00:00
MEASUREMENT_DURATION	679
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	122.524
TUNING_TUNED_NOISE_95_LOW	82.339
TUNING_TUNED_NOISE_MEAN	101.602
TUNING_TUNED_NOISE_SIGMA	11.384
TUNING_TUNED_TDAC_MEAN	-1
TUNING_TUNED_TDAC_SIGMA	4.161
TUNING_TUNED_THRESHOLD_95_HIGH	1565.623
TUNING_TUNED_THRESHOLD_95_LOW	1431.21
TUNING_TUNED_THRESHOLD_FAILED_FITS	100
TUNING_TUNED_THRESHOLD_MEAN	1501.2
TUNING_TUNED_THRESHOLD_SIGMA	36
TUNING_TUNED_TOT_95_HIGH	9.95
TUNING_TUNED_TOT_95_LOW	5
TUNING_TUNED_TOT_MEAN	7.2
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	122.542
TUNING_UNTUNED_NOISE_95_LOW	83.13
TUNING_UNTUNED_NOISE_MEAN	101.88
TUNING_UNTUNED_NOISE_SIGMA	10.428
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2313.24
TUNING_UNTUNED_THRESHOLD_95_LOW	1108.839
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	111
TUNING_UNTUNED_THRESHOLD_MEAN	1689.873
TUNING_UNTUNED_THRESHOLD_SIGMA	306

Attachments

Filename	Contents
0x22bb9_L2_warm.json	Download
output.log	Download
0x22bb9.log	Download
20UPGFC0142265_MODULE__INITIAL_WARM_TUNING.zip	Download
