20UPGFC0142265

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142265
ProdDB ID	52545a…df9b37
LocalDB ID	660d7ceeec873d00354510bf
Component Type	fe_chip
Parents	20UPGM23210545 20UPGB43200165
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/INITIAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	4 months ago
component ObjectId	660d7ceeec873d00354510bf
Stage	MODULE/INITIAL_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	Simpson,Liana Rae
ObjectId of this record	68926df18428c598c032b94d
ObjectId of RAW record	68926dee8428c598c032b92a
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-08-05T17:18:53.000+00:00
MEASUREMENT_DURATION	233
MEASUREMENT_VERSION	2.6.0
YARR_VERSION	v1.5.5
AR_IREF_TRIM	4
AR_IREF	3.6e-06
AR_GADC	0.754
AR_NOMINAL_SETTINGS	[3.6e-06, 7.99e-05, 4.54e-05, 3.8e-06, 3.67e-05, 1.89e-05, 0, 3.57e-05, 6.72e-05, -999, 0, 0, 4.21e-05, 6.22e-05, 4.67e-05, 8.03e-05, 6.05e-05, 7.41e-05, 8.21e-05, 8.03e-05, 5.78e-05, 4.41e-05, 4.34e-05, 6.14e-05, 4.43e-05, 4.34e-05, -999, -999, 0.6306933, 0.0953568, 0.9099669, 0.3125276, 0.7539843, -999, -999, 0.7573843, 1.1860287, 0.1088316, 0.1031612, 0.0370624, 0.0334447, 0.0367387, 0.2279588, 0.2089953, 0.2266021, 0.6282408, -999, 0.6257551, -999, 0.5894299, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0180872, 0.4659592, 2.0080635, 1.4789455, 1.1900549, 0.591452, 0.9690827, 1.4847411, 1.1740485, 0.5730996]
AR_ROSC_MAX_RESIDUAL	[2.6653805497232583, 4.38329992241148, 2.4285270590728993, 4.161967676411533, 1.1610741759772045, 1.9558022837018438, 1.068916819469226, 1.904606048066649, 3.6897418901139174, 3.7546887686103987, 4.361810671054994, 4.379671654873653, 3.341017893910592, 3.1128650355251875, 3.98526456541119, 4.098135796297834, 1.9653154397066874, 2.0138456517358247, 2.072132405714256, 1.9900475368341506, 1.6759875919879914, 1.6208956797130618, 2.0723550302733216, 2.2892064456622654, 1.681797046098354, 1.7282948338586706, 1.8037031288400875, 1.8799657728975097, 2.1274464924068353, 2.105649232559988, 5.222667292110151, 5.758458022846293, 3.4969189708568233, 3.8665622075896096, 1.9445226652935372, 2.074335492210942, 2.0850029467756253, 1.9423637660067676, 1.9225062702758757, 1.9976289851538247, 2.0463951472076123, 2.00269463282023]
AR_ROSC_OFFSET	[-466.113245406795, -717.1536920080223, -471.4043630203092, -731.6195672688549, -548.1150373398978, -945.7881248325982, -683.0423858506582, -999.6850935484832, -748.9658749899505, -736.1536362940103, -871.541303804069, -870.6812137945785, -775.2887226148738, -776.4670710713217, -893.690076879346, -883.120429554325, -931.8474584231898, -927.8217717157396, -1112.666115822412, -1106.2922918909624, -965.8649062800596, -950.4509425260103, -1173.8668692026483, -1181.3745348324603, -561.2836031033978, -554.1190259531229, -684.8648262725518, -679.1751655044462, -671.9467730825929, -674.6644330719128, -608.3899000856335, -635.4841647956846, -656.4085864511976, -695.7238495440195, -1064.3994394674517, -1064.2219545528303, -1071.814333739124, -1069.344628933028, -1068.6510842524676, -1063.80918771979, -1068.6336256101563, -1063.02225463443]
AR_ROSC_SLOPE	[781.4796750471069, 1215.5613217165765, 775.918103344344, 1223.9789358150817, 828.4464367328496, 1420.3327565267998, 982.2953110826612, 1459.7549590914437, 1214.584203704188, 1211.9684236288397, 1421.8574969536428, 1422.0864813306332, 1239.0728912017955, 1228.2903142520786, 1430.9516748615824, 1428.823407025882, 1405.1907177440323, 1392.560730524629, 1658.1322337409329, 1649.7766775669272, 1388.5632147216586, 1367.6238654255028, 1706.5722882120901, 1729.0530262719267, 869.1132621306182, 863.1296124900348, 1050.1559252504574, 1042.6941559891231, 1041.3156443309902, 1048.8932617009534, 1202.6599770336727, 1279.5692648126173, 1167.70047636931, 1249.592742526577, 1583.1527208848436, 1593.8555491211182, 1602.344563766821, 1591.7023744691426, 1589.4029754289659, 1590.0029994858457, 1596.8697435538036, 1592.780246298883]
AR_TEMP_ACB	32.11
AR_TEMP_ASLDO	32.549
AR_TEMP_DSLDO	31.157
AR_TEMP_EXT	19.69
AR_TEMP_NF_ACB	1.259
AR_TEMP_NF_ASLDO	1.26
AR_TEMP_NF_BOTTOM	-999
AR_TEMP_NF_DSLDO	1.259
AR_TEMP_NF_TOP	-999
AR_TEMP_NTC	20.232
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_POLY_TOP	-999
AR_VCALDAC	0.757
AR_VDDA_SATURATION	-1
AR_VDDA_TRIM	10
AR_VDDA_VS_TRIM	[0.963, 0.986, 1.011, 1.033, 1.054, 1.076, 1.101, 1.122, 1.146, 1.168, 1.191, 1.214, 1.234, 1.257, 1.28, 1.302]
AR_VDDD_SATURATION	-1
AR_VDDD_TRIM	10
AR_VDDD_VS_TRIM	[0.958, 0.982, 1.008, 1.031, 1.054, 1.078, 1.102, 1.125, 1.151, 1.175, 1.199, 1.223, 1.247, 1.272, 1.297, 1.322]
AR_VREFCORE	0.466
AR_VREFOVP	2.008

Attachments

Filename	Contents
output.log	Download
0x22bb9.log	Download

RAW Results Record

Download RAW

_id

68926dee8428c598c032b92a

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0142265

ANALOG_READBACK

6892447fbeca6df029bb97ad

DCSdata

SensorVoltage	-120.0
SensorCurrent	7.429999999999999e-07
ModuleNTC	20.44

Measurements

Vmux0

X	False
Unit	V
Values	0.7720715

Vmux3

X	False
Unit	V
Values	0.3967794

Vmux4

X	False
Unit	V
Values	0.6111016

Vmux5

X	False
Unit	V
Values	0.1269188

Vmux6

X	False
Unit	V
Values	0.1212484

Vmux7

X	False
Unit	V
Values	0.05514964

Vmux8

X	False
Unit	V
Values	0.05153191

Vmux9

X	False
Unit	V
Values	0.05482593

Vmux10

X	False
Unit	V
Values	0.246046

Vmux11

X	False
Unit	V
Values	0.2270825

Vmux12

X	False
Unit	V
Values	0.2446893

Vmux13

X	False
Unit	V
Values	0.646328

Vmux15

X	False
Unit	V
Values	0.6438423

Vmux17

X	False
Unit	V
Values	0.6075171

Vmux31

X	False
Unit	V
Values	0.4840464

Vmux32

X	False
Unit	V
Values	0.6211093

Vmux33

X	False
Unit	V
Values	0.3878236

Vmux34

X	False
Unit	V
Values	0.6131147

Vmux35

X	False
Unit	V
Values	0.6095392

Vmux36

X	False
Unit	V
Values	0.2603579

Vmux37

X	False
Unit	V
Values	0.3892725

Vmux38

X	False
Unit	V
Values	0.6051115

Vmux39

X	False
Unit	V
Values	0.5911868

Vmux63

X	False
Unit	V
Values	0.06627437

Vmux30

X	False
Unit	V
Values	0.01808723

Imux0

X	False
Unit	V
Values	0.052098

Imux1

X	False
Unit	V
Values	0.8152995

Imux2

X	False
Unit	V
Values	0.4702857

Imux3

X	False
Unit	V
Values	0.05358233

Imux4

X	False
Unit	V
Values	0.3829113

Imux5

X	False
Unit	V
Values	0.2046049

Imux6

X	False
Unit	V
Values	0.01581893

Imux7

X	False
Unit	V
Values	0.3726314

Imux8

X	False
Unit	V
Values	0.6875599

Imux10

X	False
Unit	V
Values	0.01583963

Imux11

X	False
Unit	V
Values	0.01584135

Imux12

X	False
Unit	V
Values	0.4364936

Imux13

X	False
Unit	V
Values	0.6374799

Imux14

X	False
Unit	V
Values	0.4828455

Imux15

X	False
Unit	V
Values	0.8189253

Imux16

X	False
Unit	V
Values	0.6212692

Imux17

X	False
Unit	V
Values	0.7566517

Imux18

X	False
Unit	V
Values	0.836356

Imux19

X	False
Unit	V
Values	0.4427071

Imux20

X	False
Unit	V
Values	0.5936149

Imux21

X	False
Unit	V
Values	0.457214

Imux22

X	False
Unit	V
Values	0.4500125

Imux23

X	False
Unit	V
Values	0.630154

Imux24

X	False
Unit	V
Values	0.4589948

Imux25

X	False
Unit	V
Values	0.4501887

Imux28

X	False
Unit	V
Values	0.3169594

Imux29

X	False
Unit	V
Values	0.06007244

Imux30

X	False
Unit	V
Values	0.4301121

Imux31

X	False
Unit	V
Values	0.1541465

Imux63

X	False
Unit	V
Values	0.01580488

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	47366
EfuseReadData1	8747
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	0
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	10
SldoTrimD	9
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	11.0 0.173 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.618
IrefTrim	4
KSenseInA	20942.514
KSenseInD	21963.578
KSenseShuntA	21541.0
KSenseShuntD	22591.0
KShuntA	997.758
KShuntD	988.427
Name	0x22bb9
NfACB	1.2587185
NfASLDO	1.2598469
NfDSLDO	1.2594613
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	10.256 0.188

SoftwareType

ChipID

Name

0x22bb9

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM23210545

TimeStart

1754414333

TimeEnd

1754414566

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.6.0

AR_VMEAS

MODULE/INITIAL_WARM

660d7ceeec873d00354510bf

1.01

64657cef8d79bac1f3f00578

mts	2025-08-05 20:47:41.999000
cts	2025-08-05 20:47:41.999000
rev	0

20UPGFC0142265

ANALOG_READBACK

6892447fbeca6df029bb97ae

DCSdata

SensorVoltage	-120.0
SensorCurrent	6.389999999999999e-07
ModuleNTC	19.78

Measurements

Vmux2

X	False
Unit	V
Values	0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715 0.1334715

Vmux30

X	False
Unit	V
Values	0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682 0.01804682

Imux9

X	False
Unit	V
Values	0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869 0.111869

Imux63

X	False
Unit	V
Values	0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843 0.01577843

Vmux14

X	False
Unit	V
Values	0.2309751 0.2320853 0.2313618 0.230618 0.2310948 0.2294845 0.2300538 0.2303184 0.2299744 0.2298546 0.2317739 0.231152 0.2315291 0.2296322 0.2298422 0.2306092 0.3198639 0.3198017 0.3199143 0.3200695 0.3201867 0.3203737 0.320474 0.3205152 0.3206639 0.3207573 0.3207181 0.3208285 0.320896 0.3211236 0.3211689 0.3211688

Vmux16

X	False
Unit	V
Values	0.2312631 0.2313638 0.230785 0.2311983 0.2312806 0.2300908 0.2311162 0.2308434 0.2312583 0.2314438 0.2308608 0.2327117 0.2307674 0.2322058 0.2313146 0.2310667 0.3210676 0.3210762 0.3211909 0.3211117 0.3210176 0.3210333 0.3208626 0.320777 0.320647 0.3205285 0.3204766 0.3202581 0.3203152 0.3201496 0.3201433 0.3200961

Vmux18

X	False
Unit	V
Values	0.2342307 0.232871 0.2339885 0.2339978 0.2339966 0.2321381 0.2328789 0.2331689 0.233594 0.2334229 0.2326371 0.2333208 0.2321306 0.2326144 0.2329937 0.2320207 0.3221221 0.3221996 0.3222205 0.3223223 0.3224201 0.3226043 0.3226838 0.3228003 0.3228452 0.3229597 0.3230833 0.3231118 0.3232911 0.3233204 0.3233775 0.3234579

MonSensSldoAnaSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoDigSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensAcbSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoAnaDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensSldoDigDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensAcbDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

TExtExtNTC

X	False
Unit	C
Values	19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69 19.69

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	47366
EfuseReadData1	8747
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	0
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	10
SldoTrimD	9
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	11.0 0.173 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.618
IrefTrim	4
KSenseInA	20942.514
KSenseInD	21963.578
KSenseShuntA	21541.0
KSenseShuntD	22591.0
KShuntA	997.758
KShuntD	988.427
Name	0x22bb9
NfACB	1.2587185
NfASLDO	1.2598469
NfDSLDO	1.2594613
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	10.256 0.188

SoftwareType

ChipID

Name

0x22bb9

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM23210545

TimeStart

1754415824

TimeEnd

1754416255

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.6.0

AR_TEMP

MODULE/INITIAL_WARM

660d7ceeec873d00354510bf

1.01

64657cef8d79bac1f3f00578

mts	2025-08-05 20:47:41.999000
cts	2025-08-05 20:47:41.999000
rev	0

20UPGFC0142265

ANALOG_READBACK

6892447fbeca6df029bb97af

DCSdata

SensorVoltage	-120.0
SensorCurrent	6.47e-07
ModuleNTC	19.75

Measurements

Vmux34

X	False
Unit	V
Values	0.4994219 0.510956 0.5236693 0.5345415 0.5448173 0.5561725 0.5684502 0.5790862 0.5909113 0.6018168 0.6135735 0.6248035 0.6349552 0.6463853 0.6578865 0.6689306

Vmux38

X	False
Unit	V
Values	0.4970374 0.5089201 0.5217549 0.5332658 0.545218 0.5569606 0.5691792 0.5806484 0.5932935 0.6053194 0.617569 0.629283 0.6413438 0.6538935 0.6663748 0.6789375

Vmux30

X	False
Unit	V
Values	0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904 0.01799904

Vmux33

X	False
Unit	V
Values	0.387503 0.3877352 0.3877601 0.3878861 0.3878621 0.3878974 0.3878714 0.3879427 0.3878691 0.3879002 0.3879065 0.3878705 0.3879071 0.3877655 0.3876304 0.3873685

Vmux37

X	False
Unit	V
Values	0.3893046 0.3893518 0.3894064 0.3894552 0.3894664 0.3894682 0.3894256 0.3893618 0.389281 0.3892058 0.3892818 0.3890637 0.3890104 0.3885365 0.387881 0.3868826

Imux63

X	False
Unit	V
Values	0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315 0.0157315

Imux28

X	False
Unit	V
Values	0.3140949 0.314883 0.3155198 0.3158772 0.3161195 0.3163114 0.3164699 0.3166662 0.3166853 0.3167743 0.3169406 0.3169323 0.3169302 0.31682 0.3166152 0.3162719

Imux29

X	False
Unit	V
Values	0.08640214 0.08199837 0.07814859 0.07505103 0.07301298 0.0702497 0.06789397 0.06580602 0.06381174 0.06192487 0.06043842 0.059152 0.05830059 0.05811195 0.0592382 0.06203911

Imux30

X	False
Unit	V
Values	0.4231797 0.4251323 0.4267978 0.4278782 0.4287242 0.4292855 0.4296612 0.4299293 0.4301516 0.4302687 0.430153 0.4296385 0.4289309 0.4273161 0.4248086 0.4206637

Imux31

X	False
Unit	V
Values	0.2091746 0.2029069 0.1965342 0.1902656 0.1841261 0.1779979 0.1719827 0.1662066 0.1603736 0.1547934 0.1495448 0.1457865 0.1437646 0.1446475 0.1504417 0.1647962

SldoTrimA

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

SldoTrimD

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

ROSC0

X	False
Unit	MHz
Values	278.6 298.8 319.067 338.8 358.733 378.2 397.667 416.2 435.733 454.6 473.6 490.733 509.133 527.267 544.133 561.067

ROSC1

X	False
Unit	MHz
Values	440.667 472.533 503.867 535.267 565.933 596.067 626.667 655.467 685.867 715.133 744.933 771.4 799.667 827.8 854.333 879.933

ROSC2

X	False
Unit	MHz
Values	268.333 288.333 308.133 328.067 347.6 366.6 385.933 404.333 423.8 442.533 461.6 478.667 496.667 514.8 531.933 549.0

ROSC3

X	False
Unit	MHz
Values	434.667 466.533 498.133 529.333 560.333 590.467 621.267 650.2 680.733 710.4 740.4 767.333 795.467 824.2 850.933 877.067

ROSC4

X	False
Unit	MHz
Values	245.0 265.067 285.0 305.2 325.133 345.2 365.467 385.067 405.867 426.2 446.8 465.733 485.6 506.0 524.867 543.933

ROSC5

X	False
Unit	MHz
Values	414.2 448.2 482.6 517.0 551.4 585.6 620.867 653.933 689.667 724.8 760.267 792.0 826.4 861.2 894.0 926.6

ROSC6

X	False
Unit	MHz
Values	258.6 281.667 305.133 328.333 352.133 375.467 399.867 422.867 447.667 471.733 496.267 518.733 542.667 567.067 589.867 612.667

ROSC7

X	False
Unit	MHz
Values	398.467 433.333 468.4 503.733 539.067 573.867 609.867 644.4 681.0 716.867 753.467 786.467 821.867 857.533 891.733 924.667

ROSC8

X	False
Unit	MHz
Values	409.6 440.867 471.733 502.067 532.4 562.2 592.067 621.933 652.4 681.667 711.267 738.6 767.133 795.267 821.533 848.0

ROSC9

X	False
Unit	MHz
Values	419.667 451.133 481.733 512.133 542.667 572.133 602.067 632.0 662.733 691.4 720.933 748.133 776.733 804.2 830.8 857.6

ROSC10

X	False
Unit	MHz
Values	484.467 521.333 557.4 593.067 628.6 663.267 698.467 733.4 769.333 803.333 838.2 869.867 902.933 935.667 966.8 998.333

ROSC11

X	False
Unit	MHz
Values	485.6 522.267 558.533 594.067 629.667 664.6 699.667 734.467 770.267 804.6 839.2 871.133 904.333 936.533 968.067 999.4

ROSC12

X	False
Unit	MHz
Values	407.333 439.2 470.133 500.867 531.667 562.0 592.467 622.667 654.2 683.867 713.867 742.067 771.267 799.8 827.533 854.867

ROSC13

X	False
Unit	MHz
Values	396.2 427.667 458.267 488.667 519.0 548.867 579.333 609.067 640.267 669.733 699.733 727.667 756.467 785.0 812.6 839.933

ROSC14

X	False
Unit	MHz
Values	471.733 508.6 544.867 580.0 615.867 650.667 685.867 720.933 757.267 791.533 826.6 858.4 892.2 925.467 957.2 988.6

ROSC15

X	False
Unit	MHz
Values	480.0 516.867 553.0 588.733 624.133 659.267 694.2 729.267 765.4 800.0 834.667 866.267 900.2 933.067 964.533 996.533

ROSC16

X	False
Unit	MHz
Values	413.8 447.933 481.4 515.4 549.2 582.733 616.467 651.267 686.6 720.933 755.867 787.867 821.933 855.533 888.133 920.8

ROSC17

X	False
Unit	MHz
Values	405.733 439.267 472.867 506.133 539.733 573.6 606.733 640.933 676.267 710.0 745.0 776.8 810.067 843.333 875.6 908.067

ROSC18

X	False
Unit	MHz
Values	475.667 515.733 555.467 594.867 634.8 674.6 714.2 754.733 796.6 837.267 879.0 916.467 956.667 996.467 1035.07 1074.27

ROSC19

X	False
Unit	MHz
Values	474.2 513.867 553.467 592.667 632.333 672.0 711.467 751.733 793.2 833.6 874.8 912.6 952.867 992.4 1030.73 1069.67

ROSC20

X	False
Unit	MHz
Values	365.133 398.133 431.2 464.067 497.2 530.333 563.6 597.467 632.467 666.933 701.733 733.467 767.333 800.667 833.2 865.667

ROSC21

X	False
Unit	MHz
Values	360.533 393.133 425.4 457.667 490.533 523.467 556.133 589.4 623.6 657.533 691.867 723.2 756.6 789.467 821.6 853.533

ROSC22

X	False
Unit	MHz
Values	461.533 502.533 542.867 583.533 624.333 665.4 706.4 747.667 790.533 832.8 875.667 914.533 956.2 997.2 1037.27 1076.87

ROSC23

X	False
Unit	MHz
Values	475.0 516.6 557.933 599.067 640.733 682.267 724.0 766.0 809.533 851.867 895.267 934.667 976.867 1018.33 1058.33 1098.4

ROSC24

X	False
Unit	MHz
Values	269.6 291.267 312.667 334.067 355.2 376.067 397.267 418.467 440.133 461.467 482.8 502.8 523.667 543.933 563.6 583.467

ROSC25

X	False
Unit	MHz
Values	271.067 292.533 313.8 334.933 355.867 377.0 397.6 419.067 440.8 461.467 482.867 502.6 523.4 543.4 563.067 582.6

ROSC26

X	False
Unit	MHz
Values	319.6 345.533 371.067 396.867 422.333 447.733 473.2 498.733 525.267 550.8 576.667 600.533 625.467 650.667 674.667 699.0

ROSC27

X	False
Unit	MHz
Values	317.933 343.933 369.4 394.867 420.067 445.267 470.6 496.133 522.6 547.533 573.733 597.067 622.067 646.8 670.533 694.667

ROSC28

X	False
Unit	MHz
Values	323.133 349.4 375.267 400.533 426.067 451.467 476.933 502.267 528.267 553.2 579.267 602.8 627.733 652.267 675.667 699.467

ROSC29

X	False
Unit	MHz
Values	328.2 354.467 380.0 405.4 431.133 456.467 482.133 507.933 534.4 559.733 586.067 609.2 634.333 659.133 682.933 706.8

ROSC30

X	False
Unit	MHz
Values	535.333 568.0 599.667 630.467 661.267 691.467 721.133 750.933 781.333 809.8 838.8 865.2 892.533 919.533 944.667 970.533

ROSC31

X	False
Unit	MHz
Values	581.133 615.667 649.667 682.733 715.6 747.733 779.067 811.067 843.2 873.6 904.667 932.267 961.4 990.0 1016.87 1043.93

ROSC32

X	False
Unit	MHz
Values	457.533 487.6 517.2 546.4 575.4 604.067 632.467 661.533 691.0 719.133 747.867 773.4 801.133 827.867 853.467 879.267

ROSC33

X	False
Unit	MHz
Values	496.133 528.4 560.067 591.333 622.467 653.267 683.933 714.8 746.267 776.467 806.933 834.6 863.933 892.6 920.0 947.333

ROSC34

X	False
Unit	MHz
Values	452.0 490.533 528.4 566.067 603.933 641.867 680.0 718.667 758.6 796.933 836.8 872.933 911.533 949.8 986.267 1023.53

ROSC35

X	False
Unit	MHz
Values	462.533 500.8 539.267 577.067 615.4 653.533 692.0 731.4 771.4 810.067 849.733 886.267 925.333 963.2 1000.0 1037.73

ROSC36

X	False
Unit	MHz
Values	462.933 501.467 540.0 578.533 616.933 655.4 693.667 733.2 773.533 812.4 852.333 889.0 928.2 966.8 1003.27 1041.27

ROSC37

X	False
Unit	MHz
Values	455.533 493.933 531.933 570.0 607.667 646.2 684.333 723.533 763.6 802.133 841.933 878.467 917.133 955.667 992.467 1030.0

ROSC38

X	False
Unit	MHz
Values	454.067 492.267 530.6 568.2 606.0 644.533 682.533 721.333 761.533 799.933 839.6 876.6 915.067 953.8 990.133 1027.53

ROSC39

X	False
Unit	MHz
Values	459.333 497.733 535.8 573.933 611.733 649.6 688.067 727.0 766.867 805.667 845.4 882.4 920.8 959.067 995.733 1033.0

ROSC40

X	False
Unit	MHz
Values	461.2 499.467 537.733 576.067 614.267 652.467 690.8 729.733 769.8 809.267 848.933 886.0 924.467 963.067 999.6 1037.2

ROSC41

X	False
Unit	MHz
Values	462.933 501.333 539.4 577.333 615.667 653.333 691.667 730.667 770.933 809.933 849.533 886.4 925.133 963.533 999.933 1037.6

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	47366
EfuseReadData1	8747
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	0
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	10
SldoTrimD	9
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	11.0 0.173 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.618
IrefTrim	4
KSenseInA	20942.514
KSenseInD	21963.578
KSenseShuntA	21541.0
KSenseShuntD	22591.0
KShuntA	997.758
KShuntD	988.427
Name	0x22bb9
NfACB	1.2587185
NfASLDO	1.2598469
NfDSLDO	1.2594613
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	10.256 0.188

SoftwareType

ChipID

Name

0x22bb9

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM23210545

TimeStart

1754414566

TimeEnd

1754415824

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.6.0

AR_VDD

MODULE/INITIAL_WARM

660d7ceeec873d00354510bf

1.01

64657cef8d79bac1f3f00578

mts	2025-08-05 20:47:41.999000
cts	2025-08-05 20:47:41.999000
rev	0

20UPGFC0142265

ANALOG_READBACK

6892447fbeca6df029bb97b0

DCSdata

Measurements

IrefTrimSense

X	False
Unit	-
Values	4.0

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	47366
EfuseReadData1	8747
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	0
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	10
SldoTrimD	9
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	11.0 0.173 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.618
IrefTrim	4
KSenseInA	20942.514
KSenseInD	21963.578
KSenseShuntA	21541.0
KSenseShuntD	22591.0
KShuntA	997.758
KShuntD	988.427
Name	0x22bb9
NfACB	1.2587185
NfASLDO	1.2598469
NfDSLDO	1.2594613
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	10.256 0.188

SoftwareType

ChipID

Name

0x22bb9

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM23210545

TimeStart

1754415824

TimeEnd

1754415824

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.6.0

AR_REGISTER

MODULE/INITIAL_WARM

660d7ceeec873d00354510bf

1.01

64657cef8d79bac1f3f00578

mts	2025-08-05 20:47:41.999000
cts	2025-08-05 20:47:41.999000
rev	0

rawHash

76cd53ea72436c1ffa3af52ca50c6a7a

stage

MODULE/INITIAL_WARM

ProductionDB Record

Expand ProductionDB Record

689274568330138a06056b88

state

ready

stateTs

2025-08-05T21:15:02.302Z

stateUserIdentity

1294-8027-1

date

2025-08-05T20:47:00.000Z

testType

id	6393a07c15838700361eebef
code	ANALOG_READBACK
name	Analog Readback
state	active

institution

id	5d318624df98f200097386d5
code	ANL
name	Argonne National Laboratory

user

id	6797ca0f2ffbf908f24868f9
userIdentity	1294-8027-1
firstName	Simpson,
middleName
lastName	Liana Rae

runNumber

68926df18428c598c032b94d

passed

True

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	Analog Readback Analysis Version	string	None	True	2.6.4	None	None
MEASUREMENT_DATE	Date measurement performed	datetime	None	False	2025-08-05T17:18:53.000+00:00	None	None
MEASUREMENT_DURATION	Measurement duration	integer	None	False	233	None	None
MEASUREMENT_VERSION	Measurement version	string	None	False	2.6.0	None	None
YARR_VERSION	Yarr Version	string	None	False	v1.5.5	None	None

results

code AR_IREF_TRIM
name Wirebonded Iref trim on ITkPix v2 chip
order 23
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 4
associateChild None
code AR_IREF
name AR_IREF (A)
order 24
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 3.6e-06
associateChild None
code AR_GADC
name AR_GADC (V)
order 25
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.754
associateChild None

code	AR_NOMINAL_SETTINGS
name	Analog readback at nominal settings
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	3.6e-06 7.99e-05 4.54e-05 3.8e-06 3.67e-05 1.89e-05 0 3.57e-05 6.72e-05 -999 0 0 4.21e-05 6.22e-05 4.67e-05 8.03e-05 6.05e-05 7.41e-05 8.21e-05 8.03e-05 5.78e-05 4.41e-05 4.34e-05 6.14e-05 4.43e-05 4.34e-05 -999 -999 0.6306933 0.0953568 0.9099669 0.3125276 0.7539843 -999 -999 0.7573843 1.1860287 0.1088316 0.1031612 0.0370624 0.0334447 0.0367387 0.2279588 0.2089953 0.2266021 0.6282408 -999 0.6257551 -999 0.5894299 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 0.0180872 0.4659592 2.0080635 1.4789455 1.1900549 0.591452 0.9690827 1.4847411 1.1740485 0.5730996
associateChild	None

code	AR_ROSC_MAX_RESIDUAL
name	Ring Oscillator Max Residual
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	2.6653805497232583 4.38329992241148 2.4285270590728993 4.161967676411533 1.1610741759772045 1.9558022837018438 1.068916819469226 1.904606048066649 3.6897418901139174 3.7546887686103987 4.361810671054994 4.379671654873653 3.341017893910592 3.1128650355251875 3.98526456541119 4.098135796297834 1.9653154397066874 2.0138456517358247 2.072132405714256 1.9900475368341506 1.6759875919879914 1.6208956797130618 2.0723550302733216 2.2892064456622654 1.681797046098354 1.7282948338586706 1.8037031288400875 1.8799657728975097 2.1274464924068353 2.105649232559988 5.222667292110151 5.758458022846293 3.4969189708568233 3.8665622075896096 1.9445226652935372 2.074335492210942 2.0850029467756253 1.9423637660067676 1.9225062702758757 1.9976289851538247 2.0463951472076123 2.00269463282023
associateChild	None

code	AR_ROSC_OFFSET
name	Ring Oscillator Offset
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	-466.113245406795 -717.1536920080223 -471.4043630203092 -731.6195672688549 -548.1150373398978 -945.7881248325982 -683.0423858506582 -999.6850935484832 -748.9658749899505 -736.1536362940103 -871.541303804069 -870.6812137945785 -775.2887226148738 -776.4670710713217 -893.690076879346 -883.120429554325 -931.8474584231898 -927.8217717157396 -1112.666115822412 -1106.2922918909624 -965.8649062800596 -950.4509425260103 -1173.8668692026483 -1181.3745348324603 -561.2836031033978 -554.1190259531229 -684.8648262725518 -679.1751655044462 -671.9467730825929 -674.6644330719128 -608.3899000856335 -635.4841647956846 -656.4085864511976 -695.7238495440195 -1064.3994394674517 -1064.2219545528303 -1071.814333739124 -1069.344628933028 -1068.6510842524676 -1063.80918771979 -1068.6336256101563 -1063.02225463443
associateChild	None

code	AR_ROSC_SLOPE
name	Ring Oscillator Slope
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	781.4796750471069 1215.5613217165765 775.918103344344 1223.9789358150817 828.4464367328496 1420.3327565267998 982.2953110826612 1459.7549590914437 1214.584203704188 1211.9684236288397 1421.8574969536428 1422.0864813306332 1239.0728912017955 1228.2903142520786 1430.9516748615824 1428.823407025882 1405.1907177440323 1392.560730524629 1658.1322337409329 1649.7766775669272 1388.5632147216586 1367.6238654255028 1706.5722882120901 1729.0530262719267 869.1132621306182 863.1296124900348 1050.1559252504574 1042.6941559891231 1041.3156443309902 1048.8932617009534 1202.6599770336727 1279.5692648126173 1167.70047636931 1249.592742526577 1583.1527208848436 1593.8555491211182 1602.344563766821 1591.7023744691426 1589.4029754289659 1590.0029994858457 1596.8697435538036 1592.780246298883
associateChild	None

code AR_TEMP_ACB
name Temperature ACB
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 32.11
associateChild None
code AR_TEMP_ASLDO
name Temperature Ana SLDO
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 32.549
associateChild None
code AR_TEMP_DSLDO
name Temperature Dig SLDO
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 31.157
associateChild None
code AR_TEMP_EXT
name Control temperature (external NTC from the FE)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 19.69
associateChild None
code AR_TEMP_NF_ACB
name Temperature calibration constant (ACB)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.259
associateChild None
code AR_TEMP_NF_ASLDO
name Temperature calibration constant (ana SLDO)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.26
associateChild None
code AR_TEMP_NF_BOTTOM
name Temperature calibration constant (poly bottom)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_NF_DSLDO
name Temperature calibration constant (dig SLDO)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.259
associateChild None
code AR_TEMP_NF_TOP
name Temperature calibration constant (poly top)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_NTC
name Temperature NTC
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 20.232
associateChild None
code AR_TEMP_POLY_BOTTOM
name Temperature poly bottom
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_POLY_TOP
name Temperature poly top
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_VCALDAC
name AR_VCALDAC (V)
order 26
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.757
associateChild None
code AR_VDDA_SATURATION
name VDDA saturation trim value
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -1
associateChild None
code AR_VDDA_TRIM
name VDDA Trim
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 10
associateChild None

code	AR_VDDA_VS_TRIM
name	VDDA vs trim
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	0.963 0.986 1.011 1.033 1.054 1.076 1.101 1.122 1.146 1.168 1.191 1.214 1.234 1.257 1.28 1.302
associateChild	None

code AR_VDDD_SATURATION
name VDDD saturation trim value
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -1
associateChild None
code AR_VDDD_TRIM
name VDDD Trim
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 10
associateChild None

code	AR_VDDD_VS_TRIM
name	VDDD vs trim
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	0.958 0.982 1.008 1.031 1.054 1.078 1.102 1.125 1.151 1.175 1.199 1.223 1.247 1.272 1.297 1.322
associateChild	None

code AR_VREFCORE
name AR_VREFCORE (V)
order 27
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.466
associateChild None
code AR_VREFOVP
name AR_VREFOVP (V)
order 28
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 2.008
associateChild None

cts

2025-08-05T21:15:02.302Z

sys

cts	2025-08-05T21:15:02.302Z
mts	2025-08-05T21:15:20.266Z
rev	2

defects

comments

None

attachments

code

4b19f4558ade83d02afabb488b6960f0

dateTime

2025-08-05T21:15:02.709Z

title

TestRun_689274568330138a06056b88_Attachment_Pack.zip

description

/home/data/viewer/static/cache/thumbnail/TestRun_689274568330138a06056b88_Attachment_Pack.zip

contentType

None

type

eos

url

https://eosatlas.cern.ch/eos/atlas/atlascerngroupdisk/det-itk/prod-db/4/b/1/4b19f4558ade83d02afabb488b6960f0?authz=zteos64:MDAwMDAyYjZ4nO1QPUvDUBS1QkU6ieBSES7FwcF8vJekTe_k5KCC0DUE-l7eSxva5oXkdamDiz9AcPFv6ODiJkJBl-LmooOLm1tnY3FwcHT0Dmc49557Dqd2v1yr5GsPbx_TlXo10YNMNJYn2U6FOpZUhcX0kH1jJPO0l6txJpJiYAmpjfLcynIlDMEt1-IWOdj2OHOJE0mDE2obhMS2wds2N5jLY5u02s0WbXdmlWA_T-A40kBdoA5SH4kP1KZeCONEIHFJ0yfBIk4IvS_GsVvBJAtBJ0KmGnOltOn7pHQpd9R19wLEuBz0iElI02z7JrFDSNlI4uIPiBShTKtxkHMPWJYh9FWh8XehUCOWpPiD6UmFUIyFQht0ziKJoFIu-2wY4zpsXS2dPd5sdl_n05fV7u3J7LTzVD-8PEp3r-eNC2ej_l_0XxQN7-fPd9VPrTDZrA%3d%3d

urlCernbox

https://cernbox.cern.ch/files/spaces/eos/atlas/atlascerngroupdisk/det-itk/prod-db/4/b/1/4b19f4558ade83d02afabb488b6960f0

filename

4b19f4558ade83d02afabb488b6960f0

user

id	6797ca0f2ffbf908f24868f9
userIdentity	1294-8027-1
firstName	Simpson,
middleName
lastName	Liana Rae

code

136360b4829b8847445be2bedf5b49a4

dateTime

2025-08-05T21:15:20.177Z

title

RAW

description

RAW

contentType

text/plain

type

file

binaryStoreg02

True

filename

data

user

id	6797ca0f2ffbf908f24868f9
userIdentity	1294-8027-1
firstName	Simpson,
middleName
lastName	Liana Rae

components

code

state

stateTs

stateUserIdentity

dummy

completed

completedTs

completedUserIdentity

trashed

trashedTs

trashedUserIdentity

serialNumber

alternativeIdentifier

ancestorMap

project

subproject

componentType

type

properties

testedAtStage

institution

660d7ceeec873d00354510bf

52545a83071e565d7a9f3f529fdf9b37

ready

2024-04-03T15:59:42.830Z

5310-2637-1

False

None

False

None

20UPGFC0142265

None

parent

component

67c71484ccae83c989e5da93

code

17a1ae56a2bda662bc5a700587bf4652

state

ready

stateTs

2025-03-04T14:56:04.974Z

stateUserIdentity

23-6780-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGB43200165

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	BARE_MODULE
name	Bare Module

type

code	QUAD_BARE_MODULE
name	Quad bare module

testedAtStage

code	MODULE/WIREBONDING
name	Wire Bonding

highestLevelParent

component

68507ed36734e5702671eb39

code

5ab7d00db6bab33f4a9fb0473020c931

state

ready

stateTs

2025-06-16T20:30:11.235Z

stateUserIdentity

1294-8027-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGM23210545

alternativeIdentifier

ANL_ITkPix_90

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	MODULE
name	Module

type

code	OUTER_SYSTEM_QUAD_MODULE
name	Outer system quad module

testedAtStage

code	MODULE/WIREBONDING
name	Wire Bonding

code	P
name	Pixels

code	PG
name	Pixel general

code	FE_CHIP
name	Front-end Chip

code	ITKPIX_V2
name	ITkpix_V2

None

code	MODULE/INITIAL_WARM
name	Initial Warm
order	8
initial	False
final	False

code	GL
name	Glasgow University

Current Stage: Final flatness measurement

Test Type	Local Result
Data Transmission (DATA_TRANSMISSION)	No TestRun!
ADC Calibration (ADC_CALIBRATION)	No TestRun!
VCAL Calibration (VCAL_CALIBRATION)	No TestRun!
SLDO (SLDO)	No TestRun!
Injection Capacitance (INJECTION_CAPACITANCE)	No TestRun!
Minimal Health Test (MIN_HEALTH_TEST)	No TestRun!
Tuning (TUNING)	No TestRun!
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No TestRun!
Analog Readback (ANALOG_READBACK)	No TestRun!

Candidate TestRuns of this Stage

LDB ID	TestRun Code	QC Passed	Inspector	Measurement Date	Analysis Date	Analysis Version	Tags	QC Registration
689270…32bc37	PIXEL_FAILURE_ANALYSIS	Pass	Simpson,Liana Rae	N/A	4 months ago	2.6.4	No tags	Selected
689270…32bb2c	TUNING	Pass	Simpson,Liana Rae	N/A	4 months ago	2.6.4	No tags	Selected
689270…32bab2	MIN_HEALTH_TEST	Pass	Simpson,Liana Rae	N/A	4 months ago	2.6.4	No tags	Selected
68926e…32ba35	INJECTION_CAPACITANCE	Pass	Simpson,Liana Rae	4 months ago	4 months ago	2.6.4	No tags	Selected
68926e…32ba05	DATA_TRANSMISSION	Pass	Simpson,Liana Rae	4 months ago	4 months ago	2.6.4	No tags	Selected
68926e…32ba5d	LP_MODE	Pass	Simpson,Liana Rae	4 months ago	4 months ago	2.6.4	No tags	Selected
68926e…32b9d9	VCAL_CALIBRATION	Pass	Simpson,Liana Rae	4 months ago	4 months ago	2.6.4	No tags	Selected
68926d…32b999	SLDO	Pass	Simpson,Liana Rae	4 months ago	4 months ago	2.6.4	No tags	Selected
68926d…32b94d	ANALOG_READBACK	Pass	Simpson,Liana Rae	4 months ago	4 months ago	2.6.4	No tags	Selected
68926d…32b8d5	ADC_CALIBRATION	Pass	Simpson,Liana Rae	4 months ago	4 months ago	2.6.4	No tags	Selected

Past QC Stages and Results

Final Cold (MODULE/FINAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Cold startup (COLD_STARTUP)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Final Warm (MODULE/FINAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Long Term Stability Test (MODULE/LONG_TERM_STABILITY_TEST)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Thermal Cycles (MODULE/THERMAL_CYCLES)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Cold startup (COLD_STARTUP)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Post-Parylene Cold (MODULE/POST_PARYLENE_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Cold (MODULE/INITIAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Warm (MODULE/INITIAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wire Bonding (MODULE/WIREBONDING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Test	Local Result	ProdDB Record
Analog Readback (ANALOG_READBACK)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

Test	Local Result	ProdDB Record
Electrical FE chip tests (FECHIP_TEST)	Registered	Registered

LocalDB Test ID	Stage	Test Name	Inspector	Measurement Date	Analysis Date	Tags	QC Registration
68cdb2…30f789	MODULE/FINAL_COLD	DATA_TRANSMISSION	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cde5…30f96c	MODULE/FINAL_COLD	PIXEL_FAILURE_ANALYSIS	SamuelRoberts	N/A	2 months ago	No tags	Selected
68cdd5…30f80e	MODULE/FINAL_COLD	MIN_HEALTH_TEST	SamuelRoberts	N/A	2 months ago	No tags	Selected
68cdda…30f8d4	MODULE/FINAL_COLD	TUNING	SamuelRoberts	N/A	2 months ago	No tags	Selected
68cdb1…30f761	MODULE/FINAL_COLD	INJECTION_CAPACITANCE	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cdb0…30f729	MODULE/FINAL_COLD	VCAL_CALIBRATION	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cdad…30f6e8	MODULE/FINAL_COLD	SLDO	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cda5…30f69c	MODULE/FINAL_COLD	ANALOG_READBACK	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cc99…30f5cb	MODULE/FINAL_COLD	ADC_CALIBRATION	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cc84…30f2e5	MODULE/FINAL_WARM	INJECTION_CAPACITANCE	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cc86…30f31b	MODULE/FINAL_WARM	LP_MODE	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cc8d…30f4af	MODULE/FINAL_WARM	TUNING	SamuelRoberts	N/A	2 months ago	No tags	Selected
68cc91…30f560	MODULE/FINAL_WARM	PIXEL_FAILURE_ANALYSIS	SamuelRoberts	N/A	2 months ago	No tags	Selected
68cc88…30f3bf	MODULE/FINAL_WARM	MIN_HEALTH_TEST	SamuelRoberts	N/A	2 months ago	No tags	Selected
68cc86…30f350	MODULE/FINAL_WARM	DATA_TRANSMISSION	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cc82…30f269	MODULE/FINAL_WARM	VCAL_CALIBRATION	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cc6b…30f20a	MODULE/FINAL_WARM	SLDO	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cc63…30f19b	MODULE/FINAL_WARM	ANALOG_READBACK	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68cc50…30f0f6	MODULE/FINAL_WARM	ADC_CALIBRATION	SamuelRoberts	3 months ago	2 months ago	No tags	Selected
68a767…be90a6	MODULE/POST_PARYLENE_WARM	LP_MODE	SamuelRoberts	4 months ago	2 months ago	No tags	Selected
68a77a…be92e9	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	SamuelRoberts	N/A	2 months ago	No tags	Selected
68a776…be921a	MODULE/POST_PARYLENE_WARM	TUNING	SamuelRoberts	N/A	2 months ago	No tags	Selected
68a76b…be9161	MODULE/POST_PARYLENE_WARM	MIN_HEALTH_TEST	SamuelRoberts	N/A	2 months ago	No tags	Selected
68a751…be904c	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	SamuelRoberts	4 months ago	2 months ago	No tags	Selected
68a767…be90db	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	SamuelRoberts	4 months ago	2 months ago	No tags	Selected
68a65e…be8ff8	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	SamuelRoberts	4 months ago	2 months ago	No tags	Selected
68a65a…be8f9c	MODULE/POST_PARYLENE_WARM	SLDO	SamuelRoberts	4 months ago	2 months ago	No tags	Selected
68a651…be8f30	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	SamuelRoberts	4 months ago	2 months ago	No tags	Selected
68a627…be8dd4	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	SamuelRoberts	4 months ago	2 months ago	No tags	Selected
689270…32bc37	MODULE/INITIAL_WARM	PIXEL_FAILURE_ANALYSIS	Simpson,Liana Rae	N/A	4 months ago	No tags	Selected
689270…32bb2c	MODULE/INITIAL_WARM	TUNING	Simpson,Liana Rae	N/A	4 months ago	No tags	Selected
689270…32bab2	MODULE/INITIAL_WARM	MIN_HEALTH_TEST	Simpson,Liana Rae	N/A	4 months ago	No tags	Selected
68926e…32ba35	MODULE/INITIAL_WARM	INJECTION_CAPACITANCE	Simpson,Liana Rae	4 months ago	4 months ago	No tags	Selected
68926e…32ba05	MODULE/INITIAL_WARM	DATA_TRANSMISSION	Simpson,Liana Rae	4 months ago	4 months ago	No tags	Selected
68926e…32ba5d	MODULE/INITIAL_WARM	LP_MODE	Simpson,Liana Rae	4 months ago	4 months ago	No tags	Selected
68926e…32b9d9	MODULE/INITIAL_WARM	VCAL_CALIBRATION	Simpson,Liana Rae	4 months ago	4 months ago	No tags	Selected
68926d…32b999	MODULE/INITIAL_WARM	SLDO	Simpson,Liana Rae	4 months ago	4 months ago	No tags	Selected
68926d…32b94d	MODULE/INITIAL_WARM	ANALOG_READBACK	Simpson,Liana Rae	4 months ago	4 months ago	No tags	Selected
68926d…32b8d5	MODULE/INITIAL_WARM	ADC_CALIBRATION	Simpson,Liana Rae	4 months ago	4 months ago	No tags	Selected
660d7e…452db1	TESTONWAFER	FECHIP_TEST	DimaManeuski	N/A	a year ago	No tags	Selected

Stage	Tests
TESTONWAFER	Electrical FE chip tests (FECHIP_TEST)
HYBRIDISATION
UNUSABLE
BAREMODULEASSEMBLY
BAREMODULERECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK)
MODULE/INIT
MODULE/ASSEMBLY
MODULE/WIREBONDING	ADC Calibration (ADC_CALIBRATION) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO) Low Power Mode (LP_MODE) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/INITIAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/QC_CROSSCHECK	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/INITIAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_MASKING	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Low Power Mode (LP_MODE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_COATING
MODULE/PARYLENE_UNMASKING	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE)
MODULE/WIREBOND_PROTECTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) Low Power Mode (LP_MODE) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/POST_PARYLENE_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE)
MODULE/POST_PARYLENE_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/THERMAL_CYCLES	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Cold startup (COLD_STARTUP)
MODULE/LONG_TERM_STABILITY_TEST	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Undershunt Protection (UNDERSHUNT_PROTECTION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Data Transmission (DATA_TRANSMISSION) Cold startup (COLD_STARTUP)
MODULE/FINAL_METROLOGY	Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE) Analog Readback (ANALOG_READBACK)
MODULE/QC_STATUS
MODULE/UNHAPPY	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/NOTCONSIDEREDINYIELDS	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Undershunt Protection (UNDERSHUNT_PROTECTION) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/GRAVEYARD
MODULE/COMPLETE
MODULE/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION) Tuning (TUNING)
MODULE/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
LLS/PRE_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Low Power Mode (LP_MODE) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/PRE_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/INIT
OB_LOADED_MODULE_CELL/ASSEMBLY
OB_LOADED_MODULE_CELL/THERMAL_CYCLES
OB_LOADED_MODULE_CELL/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/THERMAL_COLD
OB_LOADED_MODULE_CELL/THERMAL_WARM
OB_LOADED_MODULE_CELL/ENVELOPE_CHECK
OB_LOADED_MODULE_CELL/QC_STATUS
OB_LOADED_MODULE_CELL/UNHAPPY
OB_LOADED_MODULE_CELL/COMPLETE
OB_LOADED_MODULE_CELL/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO)
OB_LOADED_MODULE_CELL/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
OB_LOADED_MODULE_CELL/PIGTAIL_INSERTION
TEST_AFTER_LOADED_LOCAL_SUPPORT_ASSEMBLY	OB:Loaded local support QC electrical connectivity (OBLoadedLocalSupportQC_ElectricalConnectivity) OB:Loaded local support QC electrical performance (OBLoadedLocalSupportQC_ElectricalPerformance) OB:Loaded local support reception at the integration site (OBLoadedLocalSupport_IntegrationSite) OB:Loaded local support QC electrical low power (OBLoadedLocalSupport_QCElectricalLowPower)
TEST_JM_OEC_FE

20UPGFC0142265

MODULE/FINAL_METROLOGY

Component Information

Wafer

Properties

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/INITIAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Results

Attachments

RAW Results Record

ProductionDB Record

Current Stage: Final flatness measurement

Candidate TestRuns of this Stage

Past QC Stages and Results

Final Cold (MODULE/FINAL_COLD)

Final Warm (MODULE/FINAL_WARM)

Long Term Stability Test (MODULE/LONG_TERM_STABILITY_TEST)

Thermal Cycles (MODULE/THERMAL_CYCLES)

Post-Parylene Cold (MODULE/POST_PARYLENE_COLD)

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Initial Cold (MODULE/INITIAL_COLD)

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Initial Warm (MODULE/INITIAL_WARM)

Wire Bonding (MODULE/WIREBONDING)

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

All Registered QC Tests

Check QC Flow

Back to top page of this component
