20UPGFC0142219

MODULE/FINAL_METROLOGY

Component Information

Serial Number	20UPGFC0142219
ProdDB ID	60b329…e999d4
LocalDB ID	660d7cb7ec873d0035450ff9
Component Type	fe_chip
Parents	20UPGM23210545 20UPGB43200165
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: SLDO QC Passed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	660d7cb7ec873d0035450ff9
Stage	MODULE/FINAL_COLD
Test Type	SLDO
Institute ObjectId
User Name	SamuelRoberts
ObjectId of this record	68cdad274620977c2530f6db
ObjectId of RAW record	68cdad254620977c2530f6d0
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-09-19T18:48:32.000+00:00
MEASUREMENT_DURATION	1891
MEASUREMENT_VERSION	2.6.0
YARR_VERSION	v1.5.5
SLDO_ANALOG_OVERHEAD	0.182
SLDO_D_MIN_IIN	4.809
SLDO_A_MIN_IIN	5.377
SLDO_D_SLOPE	0.148
SLDO_A_SLOPE	0.105
SLDO_D_OFFSET	-0.587
SLDO_A_OFFSET	-0.559
SLDO_A_CHI2	0
SLDO_DIGITAL_OVERHEAD	0.568
SLDO_D_CHI2	0
SLDO_IINA	0.645
SLDO_IIND	0.941
SLDO_IREF	3.8323899999999993
SLDO_ISHUNTA	0.099
SLDO_ISHUNTD	0.341
SLDO_LINEARITY	0.009
SLDO_NOM_INPUT_CURRENT	6.25
SLDO_VDDA	1.21
SLDO_VDDD	1.2
SLDO_VINA	1.483
SLDO_VINA_VIND	0
SLDO_VIND	1.486
SLDO_VI_OFFSET	0.949
SLDO_VI_SLOPE	0.086
SLDO_VOFFS	0.957

Attachments

Filename	Contents
output.log	Download

RAW Results Record

Download RAW

_id

68cdad254620977c2530f6d0

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0142219

SLDO

68cdace3a9b783303eb9640a

DCSdata

SensorVoltage	120.01
SensorCurrent	2e-09
ModuleNTC	-14.977264404296875

Measurements

Temperature

X	False
Unit	C
Values	-15.009796142578125 -14.98895263671875 -15.01904296875 -15.007598876953125 -14.985931396484375 -15.0087890625 -14.97552490234375 -15.0140380859375 -14.987548828125 -15.018798828125

SetCurrent

X	False
Unit	A
Values	7.6 7.433333333333333 7.266666666666666 7.1 6.933333333333333 6.766666666666667 6.6 6.433333333333333 6.266666666666667 6.1

Current

X	True
Unit	A
Values	7.601 7.434 7.267 7.101 6.934 6.767 6.601 6.434 6.267 6.101

Vmux30

X	False
Unit	V
Values	0.0190218 0.0184734 0.0180638 0.0176543 0.0172442 0.0168369 0.0164292 0.0160212 0.0156123 0.0152151

Vmux33

X	False
Unit	V
Values	0.418112 0.41432 0.410312 0.406443 0.402448 0.398534 0.394411 0.390353 0.386386 0.382478

Vmux37

X	False
Unit	V
Values	0.418924 0.415112 0.411125 0.407187 0.403157 0.399222 0.395225 0.391082 0.387191 0.383171

Vmux34

X	False
Unit	V
Values	0.625269 0.625151 0.622888 0.623598 0.623155 0.622635 0.622386 0.621358 0.621126 0.621645

Vmux38

X	False
Unit	V
Values	0.617454 0.618303 0.616621 0.616366 0.615066 0.615155 0.614258 0.613238 0.613115 0.613082

Vmux36

X	False
Unit	V
Values	0.258239 0.257897 0.257379 0.256932 0.256626 0.256098 0.2558 0.255287 0.2549 0.254593

Vmux32

X	False
Unit	V
Values	0.600236 0.59972 0.599056 0.598428 0.598094 0.597417 0.596803 0.596265 0.595853 0.595241

Imux0

X	False
Unit	V
Values	0.0550321 0.0546155 0.054244 0.0538292 0.0534234 0.0530712 0.0526794 0.0522654 0.0519189 0.0515075

Imux28

X	False
Unit	V
Values	0.386402 0.377854 0.369328 0.360726 0.351951 0.343471 0.334746 0.326058 0.317323 0.308565

Imux29

X	False
Unit	V
Values	0.125881 0.117558 0.109539 0.101187 0.0923959 0.0843016 0.075917 0.0678874 0.059127 0.0507805

Imux30

X	False
Unit	V
Values	0.54184 0.53 0.518176 0.506509 0.494675 0.482688 0.470738 0.45843 0.44639 0.434065

Imux31

X	False
Unit	V
Values	0.25807 0.246733 0.23521 0.223528 0.211754 0.200339 0.188772 0.177666 0.165968 0.154589

Imux63

X	False
Unit	V
Values	0.0167352 0.0163414 0.0159455 0.0155533 0.0151588 0.0147647 0.0143778 0.0139837 0.013595 0.0132028

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AuroraActiveLanes	1
CdrClkSel	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
SerEnTap	1
SerInvTap	1
MonitorEnable	1
MonitorI	63
MonitorV	32
ServiceBlockEn	1
ServiceBlockPeriod	50
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffVff	60
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
SerEnLane	15
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
SldoTrimA	9
SldoTrimD	11

Parameter

ADCcalPar	13.0 0.182 10000.0
InjCap	7.583
KSenseInA	21232.506
KSenseInD	21739.146
Name	0x22b8b
ChipId	13
NfDSLDO	1.2587007989115966
NfASLDO	1.2585865247974397
NfACB	1.2577580374698007
VcalPar	13.257 0.195
IrefTrim	8
KSenseShuntA	21839.0
KSenseShuntD	22360.0
KShuntA	1001.508
KShuntD	999.014

SoftwareType

ChipID

Name

0x22b8b

Institution

UCSC

ModuleSN

20UPGM23210545

AverageTemperature

-15.001602172851562

BOMCode

TimeStart

1758307712

TimeEnd

1758309603

comment

property

YARR_VERSION	v1.5.5
SLDO_MEASUREMENT_VERSION	2.6.0

MODULE/FINAL_COLD

660d7cb7ec873d0035450ff9

1.01

64657cef8d79bac1f3f00556

mts	2025-09-19 19:21:09.103000
cts	2025-09-19 19:21:09.103000
rev	0

rawHash

eb29c7913427a668736efba64cae7d8d

stage

MODULE/FINAL_COLD
